#1061330
AFCO Non-Adjustable Alum. Coil-Over Shock Kit, 3 Inch Stroke, 9 Inch Comp.
- Each shock is hand built and dyno tested before it is shipped
- Comes supplied with two 5/8" I.D. polyurethane bushings
- Kit includes AFCO Mirror Finish coilover springs in the rate of your choice
$558.99
/kit
In Stock
Quantity
Need Help? Call to Order
Add to a list
Share
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
- Each shock is hand built and dyno tested before it is shipped
- Comes supplied with two 5/8" I.D. polyurethane bushings
- Kit includes AFCO Mirror Finish coilover springs in the rate of your choice
- Shocks have superior fixed valving that will give you a better ride and improve handling
- Both the upper and lower shock mounts have a 5/8" bushing
Key Specs
| Position | Universal |
| Spring Rate | Select Stroke and Rate |
| Mounted Length | 10.75" |
| Shock Adjustability | Non-Adjustable |
| Shock Type | Twin Tube |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyDetails
Details
AFCO has been building racing shocks for over 20 years and are now applying their technology to street rod shocks. These aluminum coilover shock kits have superior FIXED valving that will give you a better ride and improve handling.
- 3 Inch Stroke
- 9 Inch Compression
- 12 Inch Extension
- Each shock is hand built and dyno tested
- Supplied with two 5/8" I.D. polyurethane bushings
- Includes AFCO Mirror Finish coilover springs in the rate of your choice
- Kit includes (2) shocks, (2) springs, and (2) coil-over hardware kits
Guides & Documents
Warranty Information
Click for details
Warranty Information
Click for details
Speedway Motors cannot facilitate the return of defective Afco products as they have requested to handle these directly with the consumer. For defective product support and Return Authorization, please contact Afco at +1 (800)-632-2320.
Specifications
Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | Select Stroke and Rate to see |
| Brand | AFCO |
| Position | Universal |
| Spring Rate | Select Stroke and Rate to see |
| Mounted Length | 10.75" |
| Shock Adjustability | Non-Adjustable |
| Shock Type | Twin Tube |
| Shock Body Material | Aluminum |
| Shock Stroke | 3.00 |
| Upper Shock Mount | 5/8 Inch Bushing |
| Lower Shock Mount | 5/8 Inch Bushing |
| Height Adjustable | Yes |
| Finish | Chrome |
| GENERAL | |
| Compressed Length Range | 9.00" to 9.99" |
| Compressed Length | 9" |
| Extended Length Range | 12.00" to 12.99" |
| Extended Length | 12" |
| Spring Length | 7 Inch |
| Mounted Length Range | 10 3/4" - 11 1/4" |
| Coilover Kit Included | Yes |
| Coilover Springs Included | Yes |
| Inside Diameter | 0.63" |
| Sold in Quantity | Kit |
| Adjustable | No |
