AFCO 1937-39 Ford Aluminum Radiator, Ford Engine
AFCO 1937-39 Ford Aluminum Radiator, Ford Engine

AFCO 1937-39 Ford Aluminum Radiator, Ford Engine

37-39 Ford, Single Pass Radiator Style, Downflow Radiator Flow Direction, Aluminum

0 Reviews | 0 Answered Questions
Factory Shipped
Ships FREE
Select your vehicle to verify fitment.
Select Vehicle
AFCO 1937-39 Ford Aluminum Radiator, Ford Engine
AFCO 1937-39 Ford Aluminum Radiator, Ford Engine
AFCO 1937-39 Ford Aluminum Radiator, Ford Engine
X
AFCO 1937-39 Ford Aluminum Radiator, Ford Engine
Zoomed In Image
Part # 10681142
Starting from
$699.99
each
Call to Order
Add to Buildlist
Compare
Details
Reviews
Q&A
Videos & Articles

Details

Radiator Style:
Single Pass
Radiator Flow Direction:
Downflow
Material Type:
Aluminum
Inlet Location:
Upper passenger side
Outlet Location:
Lower driver side
Row Quantity:
2
Tube Size:
1.00"
Overall Width Range:
16.00" to 16.99"
Overall Width:
16.50"
Overall Height Range:
27.00" to 27.99"
Overall Height:
27.00"
Overall Thickness:
4.00"
Core Width Range:
16.00" to 16.99"
Core Width:
16.50"
Core Height Range:
22.00" to 22.99"
Core Height:
22.375"
Core Thickness:
2.25"
Finish:
Select Finish/Trans Cooler/Fan/shroud Finish to see
Cooling Fan:
Select Finish/Trans Cooler/Fan/shroud Finish to see
Transmission Cooler:
No
Shroud Included:
Select Finish/Trans Cooler/Fan/shroud Finish to see
Inlet Size:
1.50
Amperage:
17.7 amps
Shroud finish:
Select Finish/Trans Cooler/Fan/shroud Finish to see
Color:
Black
Fan Included:
Select Finish/Trans Cooler/Fan/shroud Finish to see
Fan Diameter:
16 Inch
CFM:
2170 CFM
Blade Material:
Plastic
Shroud Color:
Black
CFM Range:
2,100-2,199 CFM
MFG. Part #:
Select Finish/Trans Cooler/Fan/shroud Finish to see
Sold in Quantity:
Each

Info

When it comes to the cooling performance of these radiators, they are second to none. AFCO Aluminum radiators allow your car to remain at a constant temperature, which means that power delivery is more consistent. The uniformity of an all-aluminum construction radiator allows for the best pound for pound heat transfer characteristics.

  • 100% Aluminum construction (no epoxy)
  • Furnace brazed core
  • Tanks are made of .080” 3003 aluminum for strength and durability
  • TIG welded by skilled craftsmen in the USA
  • Factory pressure-tested
  • Filler necks feature screw-in bleed – won't crack or leak with age

NOTE: Due to the modified nature of these vehicles, some radiators will require a minimum of drilling, etc. to mount.

Learn more about how radiators work and selecting the proper radiator for your vehicle by reading our tech article. Radiator Cooling Performance.



Application

Fits:

  • 1937 Ford
  • 1938 Ford
  • 1939 Ford Std

Notes

When selecting Finish and Fan Shroud Finish, here are the abbreviations:

Finish

    S = Satin
    B = Black
    P = Polished

Fan Shroud Finish

    NA = No Fan and Shroud
    SS = Single Fan, Satin
    SP = Single Fan, Polished
    SB = Single Fan, Black
    DS = Dual Fan, Satin
    DP = Dual Fan, Polished
    DB = Dual Fan, Black

Specs


Charts

1937-1939 Ford Radiator Installation Instructions (PDF)

Notes

1/4" NPT fittings for transmission cooler. 1/4" NPT fitting for drain plug. 2.00" wide mounting feet on both sides. 2.00" wide mounting flanges on both sides.

Important Messages

  • This item ships directly from the manufacturer. It may take an additional 17 business days for AFCO to ship this item.
  • Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
  • This item ships via Ground Shipping only. Expedited and Air shipping options are not available.
Some parts are not legal for use in California or other states with similar laws/regulations
