1947-54 Chevy Truck Frame Mount Power Brake Pedal Assembly, Black
1947-54 Chevy Truck Frame Mount Power Brake Pedal Assembly, Black
Speedway Motors

|

#91664064

1947-54 Chevy Truck Frame Mount Power Brake Pedal Assembly, Black

  • Chevy Truck 1947-1954 Frame Mount Under Floor Unit
  • 7" Dual Diaphragm Booster Powder Coated Black
  • Aluminum Cast Iron Dual Bail Master Cylinder Disc / Drum
See More

$373.99

/kit

In Stock


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Frame Position, Disc/Drum Brake System Type

  • Chevy Truck 1947-1954 Frame Mount Under Floor Unit
  • 7" Dual Diaphragm Booster Powder Coated Black
  • Aluminum Cast Iron Dual Bail Master Cylinder Disc / Drum
  • Frame mount pedal assembly powder coated black w/ brake pedal
  • Non Adjustable proportion valve included
See more details

Key Specs

MFG. Part #91664064
BrandSpeedway Motors
Brake System TypeDisc/Drum
Reservoir TypeIntegral
See more specs

Need To Know

Need help?

855.313.9176
View the Help Center

Quick and Easy Returns

Return Policy

Speedway Motors 91664064 Details

Need better stopping power on your 1947-1954 Chevy Truck? This is the unit you need. Powder coated black pedal with pedal pad and a 7" dual power brake booster will fit right in place. Works for automatic transmissions only. All powder coated black with non cororsive materials so you don't have to worry about rust down the road.

Chevy Truck 1947-54 Frame Mount Under Floor Unit

  • 7" Dual Diaphragm Booster Powder Coated Black
  • Cast Aluminum Master Cylinder Disc/ Drum
  • Frame Mount Pedal Assembly Powder Coated Black w/ Brake Pedal
  • A Blue 2PSI and Red 10PSI Residual Pressure Valves are Included

**This is for disc/drum and drum/drum application.

Charts

Speedway Motors 91664064 Specifications

KEY SPECS
MFG. Part #91664064
BrandSpeedway Motors
Brake System TypeDisc/Drum
Reservoir TypeIntegral
GENERAL
PositionFrame
Master Cylinder Mount TypeReverse
Pedals IncludedBrake
Master Cylinder Count1
Outlet CountTandem
Outlet Fitting3/8"-24 IFF
Outlet Fitting 23/8"-24 IFF
Master Cylinder MaterialAluminum
FinishPowder Coated
Brake Booster IncludedYes
Balance BarNo
Sold in QuantityKit
Brake Booster TypeVacuum Diaphragm Dual
Brake Booster Diameter7 Inch

Ratings & Reviews

4.3

3 Reviews

Overall Assessment

Customers appreciate the product's ease of installation, underlining its practicality. However, there is some criticism regarding the material quality; issues with the powder coat arriving chipped were reported. Despite this, some customers express satisfaction and willingness to repurchase, indicating its usability and competitive attributes.

Write A Review

4.3

3 reviews

5

2

4

0

3

1

2

0

1

0

Filter by Ratings

I would buy this product again.

5.0

2 years ago

JK

Peoria Il

Verified

We are using it on a 1948 Chevy 1 ton, converting to disc brakes.

Would Recommend

No instructions cheap powder coat

3.0

5 years ago

joe

ca

Verified

No instructions cheap powder coat Cheap Powder coat was chipped when i pulled it out of the box I was not happy about that

Would Not Recommend

I would buy it again

5.0

5 years ago

Jim 47 chevy

Dallas, tx

Verified

Was easy to install

Would Recommend

Showing 3 of 3 reviews

Questions & Answers

4 Questions • 4 Answers

pedal ratio

by timothy

• 2 years ago

1 answer

View Answer

I want a set up like this but for disc to disc for my 1950 Chevy do you have one or Can I change the perporsion valve. 91664054 part number

by Dave

• 7 years ago

1 answer

View Answer

Important note! There is a small pin/spud that needs to be inserted into the back of the piston area of the master cylinder, before the booster is connected!!! It was found in a very small celephane bag along with 2 screw in hole plugs. Watch this Speedway video for more info: https://youtu.be/W3N0kSwvkQA The video is posted near the bottom of this page on the left

by Jeff

• 8 years ago

1 answer

View Answer

Hi, Part # 91664064:- States 1947 - 1954, But could it be made to fit a 1946 3/4 Ton Chevy Stake Bed, which is currently single circuit / Hydrovac...Drum / Drum. There no pedals or cross members to foul, as its all be removed to fit a 200R4 / V8....How many of the (residual valves) do you need is it one front & one back? Also if it will fit a 46, which is best this one or the Part # 91664060, / which would be cheapest on shipping? Many thanks Ray

by Sam8lug

• 8 years ago

1 answer

View Answer

4 of 4 questions shown
