Dominator Cut-to-Fit Radiator Shroud

Specs
Material Type:
Plastic
Overall Height:
21.00
Overall Width:
23.50
Sold in Quantity:
Each
Finish:
Natural
Hole Diameter:
19.00
Depth:
3.00
Material Thickness:
.07
Cooling Fan:
Single
Notes
Hole can be cut up to a 19.00" diameter.
Dominator Cut-to-Fit Radiator Shroud
Dominator Cut-to-Fit Radiator Shroud
Dominator Cut-to-Fit Radiator Shroud

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

This universal radiator shroud is made from tough high-impact plastic to withstand today's rigorous racing. Mounting brackets will need to be fabricated for each application.

  • 23-3/8" W x 20-7/8" L x 2-7/8" T
  • Accommodates up to a 19" diameter fan
  • Keeps motor cool during a long night of racing

Learn more about the importance of using a fan and shroud with our radiators by reading our tech article. Radiator Cooling Performance.

Customer Reviews

Rated 4 out of 5 by 2 reviewers.
RATING BREAKDOWN
2 reviews
5 Stars
1
4 Stars
0
3 Stars
1
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

DCWMotorsports
seekonk speedway
Product Rating

great shroud for electric fan

June 28, 2014
after cutting off the flange we mounted this directly to our radiator using fan mounting push tabs, after mounting our old electric fan to it we now have suction thru the front grill that pulls a piece of cardboard into it, without this shroud the fan would barely pull a piece of paper directly at the radiator
Pros:
  • Easy to work with
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Rick Bradt
Verified Purchaser
El Cajon, CA
Product Rating

Just OK

March 10, 2012
Found that it needs to be deeper. 1"-3" away from the fan.
Pros:
  • Lightweight
No, I would not recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

3 questions : 4 answers

electric fan is this shroud ok to mount a electric fan motor to? I want to install a 16" fan to a aluminum radiator

2 answers
TerryBolin
Neosho, MO, USA
March 01, 2014

electric fan is this shroud ok to mount a electric fan motor to? I want to install a 16" fan to a aluminum radiator

Answers

June 29, 2014
DCWMotorsports
yes it worked great for me, it was easy for us to do it with a little trimming and using the fan mounting kit to mount shroud to radiator
March 03, 2014
EricM
This shroud was intended to be used as a mechanical fan shroud but it would be possible to mount an electric fan to it as well. The issue you may run into is the depth of this shroud 2 7/8" so it will sit your electric fan nearly 3" closer to the engine.

Will this fit a 24" ALLSTAR double pass radiator where the hoses on are on 1 side? with a 19" Blade?

1 answers
FIREBALL8
Waverly, OH 45690, USA
January 03, 2013

Will this fit a 24" ALLSTAR double pass radiator where the hoses on are on 1 side? with a 19" Blade?

Answers

January 03, 2013
Jason
This shroud is 23.50" wide by 21" tall. The hole for fan can be cut up to 19" in diameter. This is designed for a standard radiator but you could modify for a double pass radiator.

I NEED A SCHROUD FOR 1966 GTO WITH AUTOMATIC & 389

1 answers
RED DOG
HANLONTOWN, IOWA
August 07, 2011

I NEED A SCHROUD FOR 1966 GTO WITH AUTOMATIC & 389

Answers

August 11, 2011
John
This shroud stems from our circle track racing applications and is not specific for any year. It will require cutting for fan opening and fabricating the mounting brackets. We have some other possibilities in our race catalog for aluminum shrouds that require the necessary fab work and tig welding. For an OEM style shroud you may want to contact HO Pontiac in California for availability. We do offer aluminum radiators for your application under part number 80298N in a cross flow version for superior cooling. Together with an electric fan will sufficiently cool the 389.
Page 1 of 1
