D154 P/S PARK BRAKE KIT DR

$490 Off

D154 P/S PARK BRAKE KIT DR
Wilwood

|

#UP229167

D154 P/S PARK BRAKE KIT DR

  • Open Box
  • Item is in like-new condition. Original packaging may be damaged or missing. Please review the description for additional details
See More

$769.49

/each

In Stock

$1,259.93

Save $490.44

Order soon, only 1 left in stock!

Item is in like-new condition. Original packaging may be damaged or missing. Please review the description for additional details.

Buy it brand new for $1,164.31

Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

GM 8.875 Inch 12-Bolt Car, Rear Position, Powder Coated

  • Open Box
  • Item is in like-new condition. Original packaging may be damaged or missing. Please review the description for additional details
See more details

Key Specs

Garage Sale TypeOpen Box
PositionRear
Wheel Bolt Pattern (in.)5x4.75 in.
Wheel Bolt Pattern (mm)5x120.65 mm
Rotor Diameter12.19 Inch
See more specs

Need To Know

Need help?

855.313.9176
View the Help Center

Ineligible for Return

Contains items that cannot be returned

Wilwood 140-12215-D Details

Garage Sale Product

This is Garage Sale priced because it is a factory shipped open box item and returned that we don't carry in house.

NO WARRANTY, NO RETURNS ON GARAGE SALE ITEMS

D154 Pro-Series rear disc kits provides a complete solution for popular muscle car rear axles that require a parking brake. Forged D154 dual piston calipers, 12.19" one-piece drum/rotors, and high friction pads provide optimized and balanced braking for all types of custom performance street/strip and show machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. D154 rear caliper kits offer a complimentary match to vehicles using Wilwood D52 or D154 calipers on OE spindles. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance.

Charts

Specs

Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

Wilwood 140-12215-D Specifications

KEY SPECS
MFG. Part #140-12215-D
BrandWilwood
Garage Sale TypeOpen Box
PositionRear
Wheel Bolt Pattern (in.)5x4.75 in.
Wheel Bolt Pattern (mm)5x120.65 mm
Rotor Diameter12.19 Inch
Rotor TypeVented
Caliper PistonsTwo
Caliper FinishPowder Coated
Parking Brake ProvisionYes
Minimum Recommended Wheel Diameter16 Inch
Rotor ShapeRound
Hardware IncludedYes
Rotor StyleDrilled & Slotted
Front Rotor IncludedNo
Front Caliper IncludedNo
Rear Caliper IncludedYes
Front Spindles IncludedNo
Master Cylinder IncludedNo
Brake Booster IncludedNo
Brake Hoses IncludedYes
Rear Rotor IncludedYes
ColorBlack
Bolt Pattern5 on 4.5" | 4.75"
GENERAL
Rotor Thickness0.81"
Offset2.75"
Axle Flange Offset2.75"
Mount TypeFloating
Total Piston Area1.98 sq. in.
Piston TypeStainless
Pad Area8.7 sq. in.
Pad Volume2.9 cu. in.
Brake Pad CompoundBP-10
Caliper TypeFloating
Rotor FinishBlack E-Coat
Rotor Material TypeIron
Vane Count32 Straight Vane
BeddedNo
BalancedNo
Brake Lines IncludedNo
Caliper ColorBlack
Caliper Material TypeForged Aluminum
