TREMEC TCET17765 TKX 5-Speed Transmission Ford 2.87 1st/.68 OD

#91029049

TREMEC TCET17765 TKX 5-Speed Transmission Ford 2.87 1st/.68 OD

Name: TREMEC TCET17765 TKX 5-Speed Transmission Ford 2.87 1st/.68 OD
Brand: TREMEC
SKU: 91029049
Price: 2895 USD
Availability: InStock
Rating: 5 (5 reviews)

5 Reviews

2 Questions

2.87 first gear with 0.68 overdrive for strong acceleration and highway cruising
600 lb-ft torque capacity with high-RPM shifting up to 7,500+ RPM
Compact, end-loaded design fits most tunnels with little to no modification

1ST / Overdrive Gear:

2.87/.68

2.87/.813.27/.72

$2,895.00

/each

In Stock

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle and engine to verify Fitment

Select Vehicle

Select Engine

Product Summary

TKX, 5-Speed Transmission Speeds, 600 ft./lbs. Torque

2.87 first gear with 0.68 overdrive for strong acceleration and highway cruising

600 lb-ft torque capacity with high-RPM shifting up to 7,500+ RPM

Compact, end-loaded design fits most tunnels with little to no modification

Three selectable shifter locations for maximum installation flexibility

Multi-cone synchronizers with hybrid bronze/carbon rings for smooth shifts

See more details

Warranty Information

For any warranty issues with TREMEC transmissions, please contact TREMEC directly. TREMEC provides a Product Support Form to be filled out and submitted to them, after which TREMEC will contact you directly to complete the warranty process.

TKX Service Manual

TREMEC Transmission Limited Warranty (PDF)

TREMEC Product Support Form (Link to TREMEC's Website)

Speedway Motors cannot facilitate the return of defective Tremec products as they have requested to handle these directly with the consumer. For defective product support and Return Authorization, please contact Tremec at +1 (800) 401-9866 (USA) or by ema

KEY SPECS

MFG. Part #

TCET17765

Brand

TREMEC

Transmission Speeds

5-Speed

Input Shaft Spline Count

Input Shaft Diameter

1.125"

GENERAL

Torque

600 ft./lbs.

Output Shaft Spline Diameter

1.375"

Output Shaft Spline Count

Case Material

Aluminum

First Gear Ratio

2.87:1

Gear Ratio (2nd)

1.89:1

Gear Ratio (3rd)

1.28:1

Gear Ratio (4th)

1.00:1

Gear Ratio (5th)

0.68:1

Bellhousing Included

Yoke Included

GTIN Code

041969292068

Shifter Included

Gear Ratio (Reverse)

2.56:1

Sold in Quantity

Each

Yoke Style

Slip On

Shifter Style

Linkage operated
