#9108889
$468.99
/kit
In Stock
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Front Position, 11 Inch Rotor Diameter, Natural
Comes as a Kit
View Kit Components
| MFG. Part # | 9108889 |
| Position | Front |
| Wheel Bolt Pattern (in.) | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x120.65 mm |
| Rotor Diameter | 11 Inch |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyIn the 60’s and early 70’s, drum brakes were generally considered to be just fine for safely halting a muscle car in traffic. Disc brakes were a luxurious, extra-cost option that often only ended up under performance packages like the Super Sport or Z/28. But as time has marched on, we’ve grown accustomed to our late models with electronically assisted disc brakes on all four corners that will stop on a dime. Meanwhile, a trip across town in that old drum brake equipped Chevelle, Nova, or Camaro is an exercise in constant vigilance and planning ahead for a panic stop. It’s almost enough to take the fun out of the drive.
It doesn’t take much to drastically improve on the 19th century design of those drum brakes, especially in the front. A simple, inexpensive front disc brake upgrade using OE-style components can make a night and day difference when compared to those old, fading drums. That’s where this kit fits in. While there are bigger, more trick brake kits out there, the Speedway Motors ’64-’74 GM Car Front Disc Brake Kits comes with everything you need to ditch the drums and add a disc kit to keep your GM A/F/X body car safe in modern traffic at a price that doesn’t break the piggy bank.
Finding the right spindle to swap your GM car to disc brakes can be tricky. Original drum brake spindles require that the upper threaded boss not only have over a half inch machined from it, but the hole also typically has to be drilled and tapped deeper. It’s hard to get this right, and on top of that, non-Chevy A bodies like Cutlass, GTO, and Skylark often have different sized holes in the spindles, which further complicates the swap. The OEM-style disc brake spindles that are included in this kit take all the machine work and guess work out of the equation. They’re designed to work with this kit and your 1964-72 GM A-Body, 1967-69 GM F-Body and 1968-74 X-Body, making the conversion a true bolt-on. These are stock height spindles, so they won’t change the look or handling of your car.
In addition to the spindles, this brake kit comes complete with everything needed to complete the install. That means bearings, seals, brackets, hardware, 11” rotors with 5 on 4-3/4” bolt pattern, ’69-’77 GM calipers, pads, and hoses are all included, saving you all the trips to the parts store to hunt down the nickel and dime parts that can make an install like this a hassle.
This kit fits 1964-72 GM A-Body, 1967-69 GM F-Body and 1968-74 X-Body using the included stock height spindles. If you’re after a dropped stance and improved handling, we recommend using our Speedway Motors G-Comp spindles and this brake kit without the stock spindles, part # 910-31958 or 910-31958D for drilled and slotted rotors.
We also recommend using our brake booster/master cylinder combo, part # 910-31978 with this front disc brake kit. Stock single reservoir 4-wheel drum brake master cylinders don’t have the capacity to supply the proper amount of pressure for front disc brakes. This master and booster kit also includes an adjustable proportioning valve to offer adjustment of the rear line pressure, allowing you to balance the front and rear brakes.
Also note that this kit will NOT work with 14” diameter wheels. There’s just not enough room for these 11” rotors and OE calipers inside a 14” wheel, so 15” or larger wheels that were designed to work with disc brakes must be used.
Application
This kit fits 1964-72 GM A-body, 1967-69 GM F-body, and 1968-74 X-body using the included stock disc brake spindles.
Charts
Installation Instructions (PDF)
Brake Pad Brand Guide (JPG)
Guides & Documents
| KEY SPECS | |
|---|---|
| MFG. Part # | 9108889 |
| Brand | Speedway Motors |
| Position | Front |
| Wheel Bolt Pattern (in.) | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x120.65 mm |
| Rotor Diameter | 11 Inch |
| Rotor Type | Vented |
| Caliper Pistons | One |
| Caliper Finish | Natural |
| Parking Brake Provision | No |
| Minimum Recommended Wheel Diameter | 15 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Plain Face |
| Spindle Type | Factory Disc Spindle |
| Front Rotor Included | Yes |
| Front Rotor Diameter | 11 Inch |
| Front Caliper Included | Yes |
| Rear Caliper Included | No |
| Front Spindles Included | Yes |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | Yes |
| Rear Rotor Included | No |
| Bolt Pattern | 5 on 4.75" |
| Finish | Natural |
| Color | Natural |
| Front Caliper Finish | Natural |
| Front Caliper Piston Quantity | 1 |
| GENERAL | |
| Sold in Quantity | Kit |
| Rotor Thickness | 1.05" |
| Stud Diameter | 0.44" |
| Stud Length | 0.8" |
| Thread Pitch | 7/16"-20 |
| Centerline of Holes | 7" |
| Rotor Material Type | Cast Iron |
4.9
27 Reviews
Customers appreciate the disc brake kit for its value, including its completeness and reasonable price. Easy installation and good component fit add to its practical qualities. However, it's noted that the kit modifies the track width, potentially causing tire rubbing. Despite this, many would buy this item repeatedly due to a well-liked variety of parts and excellent technical assistance, distinguishing our product from competitors.
4.9
27 reviews
5
24
4
3
3
0
2
0
1
0
Filter by Ratings
Tubular control arms & front disc upgrade
5.0
11 days ago
Badtemper
Carrier Mills
Verified
67 Pontiac Tempest. The A-Premium control arms and front disc brake kit with new spindles all fit perfect! Highly recommended for a classic car. This made a world of difference.
Would Recommend
I highly recommend this company
5.0
20 days ago
Jr
New Jersey
Verified
This is a great conversion kit to change from drum brakes everything you need to complete the conversion not to mention at a fantastic price along with quality parts
Would Recommend
Great complete kit
5.0
a month ago
DD
Iowa
Verified
Easy install
Would Recommend
I would buy again.
5.0
2 months ago
Ebmgs
Toledo, ohio
Verified
This kit was great worked exactly like it should, easy to install. I would recommend for any level working on their car.
Would Recommend
Brake conversion kit worked great
5.0
3 months ago
Jay
Denver, NC
Verified
All parts for needed for conversion were in kit. Completed install using brief instruction sheet. Parts all seemed like good quality. Brakes performed well on my 1970 cutlass.
Would Recommend
69 Camaro front disc conversion
5.0
5 months ago
Mike
Easton,MA
Verified
I wanted a near oem conversion and this kit worked out well. Everything fit perfectly. No issues. Operates well. As close to oem as possible for reasonable money. Great product.
Would Recommend
Yes
4.0
5 months ago
Scott
Adam's country Ohio
Verified
Once I got the right parts ( I ordered the wrong ones at first) the right parts fit right on my 51 Chevy with the 68 front suspension. Wish it come with alittle better instructions.
Would Recommend
if needed i would buy again
5.0
5 months ago
the diy man
Lincoln Ne
Verified
was an easy and great conversation kit for my wife's nova
Would Recommend
I would purchase again if needed
5.0
6 months ago
Mitch f
Lincoln
Verified
Upgrade on my wife's nova
Would Recommend
Like
4.0
6 months ago
Jim, everybody knows Jim
Michigan
Verified
Everything for well. The only issue was the hoses don't seem right. They are a little too long and don't lock into the caliper normally. It does work though
Would Recommend
Showing 10 of 27 reviews
3 Questions • 3 Answers
If I have a power booster in my 67 chevelle do I need to replace my power booster and proportion valve that came stock in this car and buy this kit or do I have to chance and buy kit with new master proportion valve and booster
by Pete
• 2 years ago
1 answer
View Answer
will this item fit a 1968 oldsmobile cutlass supreme?
by slim
• 2 years ago
1 answer
View Answer
will this product fit on a 1967 impala/caprice
by chris
• 4 years ago
1 answer
View Answer
3 of 3 questions shown
1967-1969 Chevy Camaro
1964-1973 Chevy Chevelle
1968 Chevy Chevy II
1964-1974 Chevy El Camino
1973-1974 Chevy Laguna
1964-1974 Chevy Malibu
1969-1974 Chevy Nova
1964-1971 Oldsmobile 442
1964-1974 Oldsmobile Cutlass
1967-1974 Oldsmobile Cutlass Supreme
1964-1972 Oldsmobile F85
1967-1969 Pontiac Firebird
1964-1973 Pontiac GTO
1964-1974 Pontiac LeMans
1964-1970 Pontiac Tempest
