Product Summary

70-78 Chevy Camaro, Analog Gauge Series, Black, Black

  • Specifically designed to fit the 70-78 Camaro platform
  • Will replace the OE gauge carrier fitting behind the original dash bezel for a factory-installed look
  • There is absolutely no cutting or modification required for the install
  • You simply remove factory bezel and carrier, bolt new assembly in place, adjust as needed and wire it up
  • The panel is designed with adjustability to adapt to variations in different build tolerances

Key Specs

MFG. Part #01670-03
BrandNew Vintage USA
Gauge SeriesAnalog
Gauge StyleElectric
Gauge Set DesignDash Cluster

Need To Know

This Product Will Ship Free

Shipping Policies & FAQs

Quick and Easy Returns

Return Policy

Details

Gauge packages for Gen II Camaros takes a new direction in how to install aftermarket gauges into the

dash. These packages replace the OE gauge carrier fitting behind the original dash bezel for a factory-installed

look, no cutting or modifications required. Simply remove factory bezel and carrier, bolt new assembly in place, adjust as needed and wire it up. Panel is designed with adjustability to adapt to variations in different build tolerances. Kits also incorporate our exclusive indicator panel with turn signals, hi beam, check engine, brake and warning lamps.

Performance Series instruments feature perimeter lit dials with incandescent bulbs, programmable speedometer and short sweep Bi-Torq(TM) minor gauges.

INCLUDED IN EACH KIT:

Mounting bracket

Center mount indicator

Speedometer

Tachometer

Water temperature gauge

Oil pressure gauge

Voltmeter

Fuel level gauge 0-90 match

Temperature sender

Pressure sender

Sender bushings

*speed sender may be required check your application

For all technical/repair/warranty product questions or needs, please contact New Vintage directly. For all other inquiries regarding shipping and delivery information, please contact the Speedway Motors Customer Experience Center.

For all technical/repair/warranty product questions or needs, please contact New Vintage directly. For all other inquiries regarding shipping and delivery information, please contact the Speedway Motors Customer Experience Center.

Charts

Specifications

KEY SPECS
MFG. Part #01670-03
BrandNew Vintage USA
Gauge SeriesAnalog
Gauge StyleElectric
Gauge Set DesignDash Cluster
GENERAL
Gauge Face ColorBlack
Bezel FinishBlack
Needle ColorRed
Lettering ColorWhite
Includes Mounting Bracket(s)Yes
Fuel Sender IncludedNo
Speed Sender IncludedNo
Oil Pressure Sender IncludedYes
Turn Signals IncludedYes
Includes Wire HarnessNo
Bezel IncludedYes
Gauge TypeAnalog
Lens StyleFlat
Temperature Sensor Bung IncludedYes
GTIN Code689860950832
