#9109684
Mustang II IFS, Tube Arms, Stock Spring/Spindle,Power Rack, 4-3/4
- Our Mustang II spindles are constructed from 1045 heat-treated alloy steel. Retains absolute stock factory geometry and uses all stock rotors, bearings, calipers, etc., making it easy to install.
- For unmatched ride quality for the street and strip
- New power rack modeled from the 1982-88 T-bird design which will work with aftermarket Mustang II crossmembers. Bushings included
$1,416.99
/kit
In Stock
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Universal Fit, IFS Front Suspension Type, Natural
- Our Mustang II spindles are constructed from 1045 heat-treated alloy steel. Retains absolute stock factory geometry and uses all stock rotors, bearings, calipers, etc., making it easy to install.
- For unmatched ride quality for the street and strip
- New power rack modeled from the 1982-88 T-bird design which will work with aftermarket Mustang II crossmembers. Bushings included
- Outer tie rod and inner extension fits left or right, attaches steering rack to spindles
- Speedway Mustang II Tubular Control Arms
Comes as a Kit
View Kit Components
Key Specs
| MFG. Part # | 9109684 |
| Front Suspension Type | IFS |
| Suspension Height Adjustment | Lowered |
| Control Arm Style | Tubular |
| Spring Type | Coil Spring |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicySpeedway Motors 9109684 Details
Speedway Motors 9109684 Details
Kit Includes:
- (2) Speedway Mustang II Steel Spindles
- (2) Mustang II Suspension Front Springs
- (2) Monroe 32118 Monro-Matic Plus Mustang II Front Shocks
- (2) QA1 Pin Cross 0.750" O.D.
- (1) Mustang II Power Rack & Pinion
- (2) Speedway Mustang II Steering Rack & Pinion Mounting Bushing
- (2) Mustang II Outer Tie Rod End, Manual Version
- (1) Pinto-Mustang II Spindle Nut & Washer Kit
- (1) GM Metric Caliper Bracket Set for Mustang II Spindle
- (2) 1978-Up GM Metric Brake Calipers
- (1) Speedway Soft Street Brake Pads, GM Metric 1978-Up D154
- (2) Speedway 1974-80 Ford 11 Inch Front Disc Brake Rotors
- (1) Bearing-Seal Kit for Two Mustang II Brake Rotors
- (2) Speedway Mustang II Tubular Lower A-Arms for Coilovers, No Strut Rod
- (4) Speedway Mustang II Upper Control Arm T-Bolts
- (1) Mustang II Manual Rack Bolt Kit
- (1) 9/16 Inch Fine Thread Tie Rod Nuts
- (1) Speedway Mustang II Coil Spring Rubber Isolator Cushion
- (1) Mustang II Power Rack Bolt Kit
- (2) Mustang II Rack Spacer, 3/4 Inch
- (2) Speedway Mustang II Tubular Upper Control Arms, Stock Width
- (1) Front Disc Brake Hardware Kit
With our complete Mustang II Independent Front Suspension kit you get brand new tubular steel upper and lower control arms with polyurethane bushings, steel spindles, Rubber Brake Lines, new coilovers, new power rack & pinion with bushings or remanufactured power rack & pinion with bushings and an 11" brake kit featuring GM Metric-style calipers.
Charts
Guides & Documents
Speedway Motors 9109684 Specifications
Speedway Motors 9109684 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 9109684 |
| Brand | Speedway Motors |
| Front Suspension Type | IFS |
| Suspension Height Adjustment | Lowered |
| Control Arm Style | Tubular |
| Spring Type | Coil Spring |
| Spring Rate | 350 lbs. |
| Bolt Pattern | 5 on 4.75" |
| Spindle Style | Ford Custom |
| Dropped Spindles | No |
| Spindles Included | Yes |
| Brakes Included | Yes |
| Steering Included | Yes |
| Caliper Pistons | Single |
| Caliper Finish | Natural |
| Hardware Included | Yes |
| Welding Required | Yes |
| GENERAL | |
| Sold in Quantity | Kit |
Ratings & Reviews
5
2 Reviews
Customers highly recommend our product for its easy installation, detail-oriented design, and high-quality, beautifully machined parts. Not only does it fit well in various setups, but customers express an interest in repurchasing. They appreciate the convenience it offers for different projects. Some suggested an improvement - more detailed instructions, particularly on earlier steps. This notwithstanding, the product outperforms competitors with its usability and material quality.
Ratings & Reviews
5
2 Reviews
Customers highly recommend our product for its easy installation, detail-oriented design, and high-quality, beautifully machined parts. Not only does it fit well in various setups, but customers express an interest in repurchasing. They appreciate the convenience it offers for different projects. Some suggested an improvement - more detailed instructions, particularly on earlier steps. This notwithstanding, the product outperforms competitors with its usability and material quality.
5
2 reviews
5
2
4
0
3
0
2
0
1
0
Filter by Ratings
I would buy this kit again for another project.
5.0
2 years ago
blackabird
colorado
Verified
easy installation, beautiful machined parts, great installations.
Would Recommend
I really like the setup on this
5.0
2 years ago
Djm
Salina KS
Verified
It fits very well I would buy it again if I was going to do it again The instructions could be a little more in detail like bolting on motor mounts before you get everything else done
Would Recommend
Showing 2 of 2 reviews
Questions & Answers
Questions & Answers
1 Question • 1 Answer
Hi, is this a bolt-in kit, does it lower the ride height, can I get a manual rack instead of one with power, if it does not lower the ride height do you offer a kit with drop spindles? thanks, frank
by FRANK
• 4 months ago
1 answer
View Answer
1 of 1 questions shown
