$2,199.99

Light Forged SB Chevy Rotating Assem., 350 Flat Top, 6 In Rods

350 Chevy Small Block V8, 350 mains Main Journal Style, 3.480" Engine Stroke

3 Reviews | 2 Answered Questions

In Stock

Ships FREE

Select your vehicle to verify fitment.

Select a vehicle to verify fitment.

Select Vehicle

Part # 9153010

$2,199.99

kit

Call to Order

Add to Buildlist

Click to Login

Compare

Details

What's In The Kit

Reviews

Q&A

Videos & Articles

Important Messages:

Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
This item 9153010 is made to order. It will be shipped from our warehouse when it is produced.

Build Your Kit

You're almost there! This kit has an option or two for you to select. Let us know which options you want for your new kit.

Item 1 of 1

MAHLE Forged Flat Top Pistons, SBC

Quantity: 1

Bore

030 040 060

Details

Main Journal Style:

350 mains

Engine Stroke:

3.480"

Connecting Rod Type:

I-Beam

Connecting Rod Length:

6.000"

Connecting Rod Material:

Forged 4340 Steel

Connecting Rod Weight:

605 grams

Connecting Rod Bolt Diameter:

7/16"

Piston Style:

Flat Top

Piston Material:

Forged Aluminum

Piston Weight:

429 grams

Piston Ring Style:

Crankshaft Material:

Forged 4340 Steel

Rear Main Seal Style:

2-piece

Wrist Pin Diameter:

.9272"

Main Journal Diameter:

2.448"

Rod Journal Diameter:

2.10"

Bearing Construction:

Bi-metal

Bearing Undersize:

Standard

Narrowed Bearing:

Yes

Coated Bearing:

MFG. Part #:

9153010

Sold in Quantity:

Kit

Info

Our lightweight forged rotating assembly engine rebuild kits include a 44-45 lb. Scat Superlight 4340 forged 2-pc rear main seal crankshaft, Scat 4340 forged I-beam connecting rods and Mahle pistons complete with wrist pins, locks and rings. Rod and main bearings included. Standard size journals.

All balancing is done with our state-of-the-art Hines balancer by race mechanics with over 30 years of experience. Kit when purchased with the included balance job will ship in 24-48 hours.

Item Details

Flat top, 429 g
Comp. 64cc: 10.6
Ring Style: E

Notes

Kit includes:

Scat 4340 Lightweight Forged Steel Crankshaft
- Standard size journals
- Profiled aero-wing counterweights
- Pendulum cut to reduce rotating mass
- Straight shot and chamfered oil holes
- Nitride hardened and shot peened
- Lightening holes in all rod throws
- Large radius on all journals
Scat Pro Comp 4340 I-Beam Rods
- Stroker clearanced
- ARP 7/16" cap screw bolts
- Bushed pin
- Set of 8 rods
- 6.0" rod: 629 grams
- Crank pin: 2.100"
- Wrist pin: .927"
- B.E. width: .940"
Mahle PowerPak Forged Pistons
- Lightweight slipper skirt design
- Phosphate coated
- Grafel anti-friction skirt coating
- 4.000" bore pistons available in standard, .030, .040, or .060 sizes
- 4.125" bore pistons available in standard, .030 or .040 sizes
- Set of 8 pistons
- Includes low drag rings, lightweight wrist pins and round wire locks
King HP Series Main & Rod Bearings
- 0.015" thick top layer for superior macro particle embedability and conformability
- 40 Vickers hardness to resist overlay migration and extrusion
- 450°F heat threshold for superior protection against friction and overheating
- Mains are 3/4 grooved for improved oiling to the rod journals
- Bi-metal aluminum silicon alloy featuring fine micro-bore finish

Some parts are not legal for use in California or other states with similar laws/regulations

What's In The Kit

Each kit from Speedway Motors is carefully packaged and delivered right to your door. Below is a list of all the items you should expect to receive when you order this kit. Some of these items may also be available for sale individually if you're here looking for replacement parts.

Scat 435032LW F43 S/B Chevy Crankshaft-3.50 Stroke-350 Main-2.10 Rod

Part # 91515225

Qty x 1
Scat 26000716 Small Block Chevy 4340 I-Beam Rods, 6.0 Inch, Bushed Pin

Part # 91015232

Qty x 1
King HP Series Chevy 350/400 Large Journal Engine Rod Bearings, Std

Part # 910807HP-STD

Qty x 1
King HP Series Chevy 350 Large Journal Engine Main Bearings-Standard

Part # 910557HP-STD

Qty x 1
Labor-Balance Rotating Assy

Part # 91600016

Qty x 1
MAHLE Forged Flat Top Pistons, SBC

Part # 5032003

Qty x 1
