Product Summary

335 GPH / 1,268 LPH Free Flow Rate, 12 volts Voltage

    See more details

    Key Specs

    MFG. Part #12-767
    BrandHolley
    Free Flow Rate335 GPH / 1,268 LPH
    Voltage12 volts
    Fuel Pressure130 psi
    See more specs

    Need To Know

    Quick and Easy Returns

    Return Policy

    Holley 12-767 Details

    Holley has raised the bar again with the introduction of the VR1 Brushless Fuel Pump Quick Kits. The kits will allow you to build your own fuel system tailored to your combination. The 12-767 kit includes a fuel pump, harness, and a 2 -step controller. The 12-768 includes the same plus an additional 26-163 Bulkhead harness to help you build your system.Featuring brushless pump technology and a twin screw rotor design, the VR1 fuel pumps are capable of high pressures and flows while maintaining a low amperage draw and quiet performance. Designed to work on high boosted race cars as well as your daily Driven weekend endurance car, these pumps work with gasoline, methanol, and E-85* (Compatible for methanol and E85 for competitive drag race use only- when draining and flushing after each race event) and can maintain pressures of 130 PSI and up to 335 GPH flow**.The pumps include a 2 step controller for pump speed control. The pumps can be ran in one of two different speeds. A low speed control for low fuel consumption requirements or at full speed for high fuel consumption requirements. The VR2 includes (2) controllers for precise control of both pumps independently of each other. Both the VR1 and VR2 pumps are proven for 18.5V compatibility. Fueled by TI Automotive**At 13.8V

    Features:

  • Capable of 130 PSI while providing significant flow for forced induction applications where Belt Driven pumps are normally used.
  • Unlike other pumps, the VR Series are built for continuous duty if needed.
  • High flow and high pressure with low amperage draw
  • Designed to be submerged in your fuel cell for a clean installation
  • Maximum amp draw of the VR1 is 19 AMPS and 38 AMPS for the VR2
  • Holley also offers a complete line of fuel filters and fuel pressure regulators that are designed to work as a system with these pumps
  • Holley 12-767 Specifications

    KEY SPECS
    MFG. Part #12-767
    BrandHolley
    Free Flow Rate335 GPH / 1,268 LPH
    Voltage12 volts
    Fuel Pressure130 psi
    GENERAL
    Fuel Pressure Regulator IncludedNo
    Sending Unit IncludedNo
    Gasket(s) IncludedNo
    Wiring Harness IncludedYes
    Mounting Bracket IncludedNo
    Mounting Hardware IncludedNo
    Sold in QuantityEach
    NotesIncludes a pump and 2-step fuel controller.
    GTIN Code090127050217
    Fuel Pump TypeElectric In-tank
    Outlet Quantity1
    Pulley IncludedNo
    Fuel Pump Outlet Size-10 AN
    Outlet AttachmentFemale O-ring
