Product Summary

97-04 Dodge, 67 GPH / 255 LPH Free Flow Rate

    See more details

    Key Specs

    MFG. Part #12-323
    BrandHolley
    Free Flow Rate67 GPH / 255 LPH
    Voltage12 volts
    See more specs

    Need To Know

    Quick and Easy Returns

    Return Policy

    Holley 12-323 Details

    Update the fuel system in your Dodge truck with a high performance in-tank EFI fuel pump module. These fuel modules fit inside the factory tank And feature a billet aluminum flange, Hydramat®, fuel sending unit, and high performance pump. Choose from 255 or 450 LPH (liters per hour) fuel flow And return style or returnless design.The amazing HydraMat® is Holley's patent pending design that solves the problems associated with traditional fuel pick-ups in stock fuel tanks as well as racing fuel cells. During hard cornering, acceleration, stopping, inclines, and low fuel conditions fuel runs away from the fuel pick up which introduces air into the system resulting in poor engine performance and even stalling. HydraMat is the solution!Direct Fit in the following Vehicles:1997-2004 Dodge Dakota (2WD And 4WD)1998 Dodge B1500/B2500/B3500 (Full Size Vans)1999-2003 Dodge Ram 1500 Van/Ram 2500 Van/Ram 3500 Van (Full Size Vans)1998-2003 Dodge Ram 1500/Ram 2500/Ram 3500 (2WD And 4WD Full Size Pickups)1999-2001 Dodge Ramcharger (2WD And 4WD - Mexico Only)1998-2003 Dodge Durango (2WD And 4WD)

    Features:

  • High Performance In-Tank EFI Fuel Pump Modules for 1991-2004 Dodge Trucks
  • Billet Aluminum Flange, Clamp And Fuel Level Sender
  • Black Anodized Finish
  • Choose from 255 or 450 LPH (liters per hour) Pump
  • Adjustable for Tank Depth
  • Choose from Return Style or Returnless Fuel Module
  • Provisions for EVAP (Evaporative Emission Control System) – See the Installation Notes
  • Inlets And Outlet Ports: -8 AN O-Ring Boss
  • New Fuel Level Sender Included
  • Optional Fill Vent Built Into Billet Aluminum Top – See the Installation Notes
  • Includes Hydramat® - 3” x 15”
  • Fits in Stock Factory Fuel Tanks
  • Ideal for Use In Gen III Hemi Engine Swaps
  • Holley 12-323 Specifications

    KEY SPECS
    MFG. Part #12-323
    BrandHolley
    Free Flow Rate67 GPH / 255 LPH
    Voltage12 volts
    GENERAL
    Fuel Pressure Regulator IncludedNo
    Sending Unit IncludedYes
    Gasket(s) IncludedYes
    Wiring Harness IncludedYes
    Mounting Bracket IncludedNo
    Mounting Hardware IncludedNo
    Sold in QuantityKit
    Notes18 amp draw, returnless style pump.
    GTIN Code090127107324
    Fuel Pump Inlet Size-8 AN O-ring
    Fuel Pump TypeElectric In-tank
    Inlet AttachmentFemale O-ring
    Outlet Quantity1
    Pulley IncludedNo
    Fuel Pump Outlet Size-8 AN
    Outlet AttachmentFemale O-ring
