Product Summary

Universal Fit, One Wire Alternator, V-Belt Belt Type

  • Alternator produces max 90 amps at max rpm (68 amps at turn on 1600 RPM)
  • Its compact and lightweight design allows for installation in the tightest spaces
  • Features a 1 wire installation and is 12V compatible
  • Has an internal regulator and includes a V-style pulley
  • Available in a plain or black finish to better suit your style

Key Specs

MFG. Part #
BrandSpeedway Motors

Need To Know

Free Shipping on Orders Over $149

Shipping Policies & FAQs

Quick and Easy Returns

Return Policy

Details

Speedway Motors mini alternators are a great addition to your engine, whether it’s for the great look or the reliable high-amperage output. This alternator produces max 90 amps at max rpm (68 amps at turn on 1600 RPM), which will generally meet the demand of a hot rod or race application. Its compact and lightweight design allows for installation in the tightest spaces.

Specifications:

  • Alternator Style: Nippondenso
  • Maximum Amperage Output: 90 Amps (68 amps @ turn on 1600 RPM)
  • Voltage Compatibility: 12 Volts
  • One-Wire Capable: Yes
  • Regulator Style: Internal
  • Regulator Included: Yes
  • Pulley Included: Yes
  • Pulley Style: V-belt
  • Finish: Choose Satin or Black



Specifications

KEY SPECS
MFG. Part #
BrandSpeedway Motors
GENERAL
One Wire AlternatorYes
Belt TypeV-Belt
Alternator Case StyleNippondenso
Alternator Amperage90 amp
RegulatorInternal
Alternator FinishSatin
ColorBlack
Alternator Pulley IncludedYes
Alternator Pulley Grooves1 V-groove
Pulley Diameter2.50"
Alternator Pulley MaterialSteel
Alternator Pulley FinishBlack Painted
Belt Width.67"
Alternator Fan IncludedNo
Alternator Brackets IncludedNo
Outside Diameter5.0"
Overall Length5.75"
Centerline of Holes6.25"
Sold in QuantityEach
Notes
Pulley StyleV-belt
Regulator IncludedYes
