#9109266
Flo-Tek 102505 Assembled SBC Aluminum Cylinder Heads/Install Kit
- Budget-conscious, yet proven, cylinder head assembly kits for bolt-on performance gains
- 64cc fast-burn combustion chambers deliver big power
- Designed for 4" bore small block Chevy engines (302/327/350/383)
$1,119.99
/kit
On Backorder
$1,136.96
Save $16.97
This part is Backordered. We currently do not have an estimate when this item will ship.
Quantity
Need Help? Call to Order
Add to a list
Select an engine to verify Fitment
Select Engine
Product Summary
Assembled Cylinder Head Style, Aluminum, Natural
- Budget-conscious, yet proven, cylinder head assembly kits for bolt-on performance gains
- 64cc fast-burn combustion chambers deliver big power
- Designed for 4" bore small block Chevy engines (302/327/350/383)
- Pre-flattened copper wire ring gaskets will not brinell aluminum heads
- Includes: Cylinder Heads, Intake Gaskets, Head Gaskets, Head Bolts and Washers
Comes as a Kit
View Kit Components
Key Specs
| Cylinder Head Style | Assembled |
| Material Type | Aluminum |
| Finish | Natural |
| Combustion Chamber Volume | 64cc |
| Intake Runner Volume | 180cc |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyDetails
Details
Breathe new life into your small block Chevy with a set of FloTek aluminum cylinder heads from Speedway Motors. If you're looking for a budget-conscious, yet proven, cylinder head for bolt-on performance gains, check out these completely assembled cylinder heads from FloTek.
Kit Includes:
- (2) Flo-Tek 102505 Assembled S/B Chevy Aluminum Heads, Straight Plug
- (2) ARP 134-3601 Small Block Chevy Head Bolts
- (1) ARP 134-3601 Head Bolt Washers
- (1) Speedway Small Block Chevy Intake Gasket Set, 1205 Style, Standard
- (2) Fel-Pro P1010 S/B Chevy 265-400 Copper Ring Head Gaskets, 4.166 In. Bore
Flo-Tek 102505 Assembled S/B Chevy Aluminum Heads
- Standard port location for use with most intake and exhaust manifolds
- 180cc intake port volume
- 62cc exhaust port volume
- 64cc fast-burn combustion chambers deliver big power
- 2.02” intake/1.60” exhaust valves
- 3-angle valve job enhances flow at low-to-mid lifts
- Swirl polished & undercut stainless steel valves
- Intake flows 232 CFM @ .500” lift
- Exhaust flows 173 CFM @ .500” lift
- Accepts both perimeter and center bolt valve covers
- Single 1.46” diameter valve springs w/ inner damper
- Suitable for flat tappet camshafts up to .550” lift
- 7 degree lightweight chromoly retainers and keepers
- Hardened steel spring cups for durability
- High nickel powdered metal valve seats provide optimum heat transfer and wear characteristics
- Manganese bronze valve guides reduce friction
- Valve guides are compatible with all common valve materials and fuels
- Viton positive valve seals
- 2-piece hardened steel pushrod guide plates for use with hardened pushrods
- 3/8” chromoly screw-in rocker arm studs included
- Blocked exhaust heat riser manifold crossover port
- 3/8” NPT coolant temperature probe port
- Designed for 4" bore small block Chevy engines (302/327/350/383)
Manley 42171 Small Block Chevy Head Bolts
- Heavy duty design, longer than stock, for use with head bolt washers
- 180,000 PSI material
- Improved wrenchability with 1/2" hex head
Manley 42102 Head Bolt Washers
- Hardened steel 7/16" washers ensure proper torque readings
- Pack of 34 pieces outfits one Small Block Chevy engine
Small Block Chevy Intake Gasket Set
- High-performance intake manifold gaskets for 265-400 SB Chevy V8 engines
- No end seals - use silicone gasket maker
- Heat crossover port is blocked
- Compare to Fel-Pro
- 1205 style, 1.28" x 2.09" Stock/Small Race
Fel-Pro P1010 S/B Chevy 265-400 Copper Ring Head Gaskets
- Pre-flattened steel wire ring gaskets have the strength of steel wire sealing with minimum brinelling of aluminum heads
- Pre-flattened copper wire ring gaskets will not brinell aluminum heads
- Offers superior heat dissipation
- Nominal compression thickness: .039"
- Compressed volume: 8.9 cc
- Recommended for 86-91 Corvette aluminum heads. Max 4.155" bore.
- 4.166" bore gaskets can be used on 400 race engines with up to 4.155" max bore with minimal chamfer.
- When using aluminum heads, we recommend gaskets with soft copper wire rings (such as 344-1010). This ensures that the aluminum head is not "scarred" by the combustion seal. Shim style 344-1094 will also work well with aluminum heads.
- Multi-layer steel gaskets offer current leading-edge technology and provide a long-term, leakproof seal called Perma Torque MLS
Flo-Tek 102505 Assembled S/B Chevy Aluminum Heads (more details)
Features like fast-burn combustion chambers, high-velocity ports, large diameter valve springs, and rugged construction make these heads the obvious performance upgrade for small block engines.
FloTek cylinder heads are designed for optimal airflow and performance on SBC engines with a 4.0" bore. Large 180cc intake runners, with an improved short-side radius, provide a rush of air into the cylinders, increasing torque. The key ingredient for big power, however, is the 64cc fast-burn combustion chambers. Air flows in and out of these chambers via a 3-angle valve job. A 62cc exhaust runner gets the spent gasses out. All told, these heads will flow 232 CFM @ .500" lift on the intake and 173 CFM @ .500" lift on the exhaust.
FloTek aluminum cylinder heads arrive packed full of standout features at an incredible value. At 20 lbs. apiece, the state-of-the-art aluminum alloy casting is a great base for any mild SBC build. FloTek cylinder heads are built with bronze valve guides, high nickel valve seats, milled and drilled ends for accessory bracket mounting, and are available in straight or angle spark plug configurations. Assembled heads add stainless valves, 1.46" diameter springs, chromoly retainers, Viton seals, pushrod guide plates, and 3/8" screw-in rocker studs - for a complete bolt-on performance package!
Maybe you are a bit more involved in your engine build - no problem! Pick up a set of bare FloTek heads, also available with straight or angled plugs, to build out with the valves, springs, and hardware of your choice.
Application
These fully assembled heads are ready to run and are a great match to flat tappet camshafts. They're compatible with solid (mechanical) flat tappet or hydraulic flat tappet cams with up to .550” lift. The valve springs (single with flat wire inner damper) have a seat pressure of 120 lbs. Valves are +.100" long and must be used in conjunction with aftermarket aluminum roller rocker arms to clear valve springs used which are 1.46" diameter. The valve springs have 120 lbs. @ 1.800" installed height and 290 lbs. of open pressure at 1.20” (coil bind is at 1.160”).
Charts
Specifications
Specifications
| KEY SPECS | |
|---|---|
| Brand | Flo-Tek |
| Cylinder Head Style | Assembled |
| Material Type | Aluminum |
| Finish | Natural |
| Combustion Chamber Volume | 64cc |
| Intake Runner Volume | 180cc |
| GENERAL | |
| Exhaust Runner Volume | 62cc |
| Combustion Chamber Volume Range | 60cc - 69cc |
| Intake Runner Volume Range | 180cc - 189cc |
| Exhaust Runner Volume Range | 60cc - 69cc |
| Spark Plug Style | Straight |
| Intake Port Shape | Rectangle |
| Exhaust Port Shape | Square |
| Intake Valve Diameter | 2.02" |
| Exhaust Valve Diameter | 1.6" |
| Spring Diameter | 1.45" |
| Stud Diameter | 0.38" |
| Notes | Center to centers for passenger side are 4.80" and 5.45". Driver's side is 1.98" and 3.63" |
| Sold in Quantity | Kit |
Ratings & Reviews
4.9
16 Reviews
Customers consistently praised the quality and efficiency of our product, specifically mentioning the high-grade material of Flo-Tek heads. Several customers shared their positive experiences using our product in various motor builds, highlighting the suitability of the product for 6500rpm street motors and the convenience of easy assembly without any need for tweaks. Customers appreciated the product's great value for money, underlining the solid quality of the product compared to its cost. Many customers stated they would definitely repurchase, and they recommend our product for those looking for reliable and high-performance engine parts. The product stands out for its immediate fit and practicality in different engines.
Ratings & Reviews
4.9
16 Reviews
Customers consistently praised the quality and efficiency of our product, specifically mentioning the high-grade material of Flo-Tek heads. Several customers shared their positive experiences using our product in various motor builds, highlighting the suitability of the product for 6500rpm street motors and the convenience of easy assembly without any need for tweaks. Customers appreciated the product's great value for money, underlining the solid quality of the product compared to its cost. Many customers stated they would definitely repurchase, and they recommend our product for those looking for reliable and high-performance engine parts. The product stands out for its immediate fit and practicality in different engines.
4.9
16 reviews
5
14
4
2
3
0
2
0
1
0
Filter by Ratings
Get verified at a machine shop
4.0
a month ago
TP
Boise,Idaho
Verified
Even though they were advertised as having an installed spring height of 1.75, I had my machine shop do a vacuum test and verify the spring specs, and they came out to be 1.42. Had to change out the keepers. the 250 was worth saving the money I would have lost wiping a cam. Other than that the kit is wonderful, and the heads look attractive even when painted. Have yet to fire up the 327 they are on but the kit is worth it for what you get. They are insanely lighter than a cast iron head .
Would Recommend
Yes would buy again
5.0
a month ago
Dan
Clinton iowa
Verified
On a 1968 327 working great
Would Recommend
Very nice!
5.0
a month ago
Retrobird89
Oklahoma
Verified
350 SBC with the TPI in my Firebird needed a little help, these worked out great. On the factory ECU they still ran great and definitely very noticeable. I can tell you they are indeed budget heads there is lots to do as far as porting and all the other things but they are night and day. For a quick head swap, these are great. I had to get a different intake for the standard bolt pattern vs the old TPI specific pattern and that allowed me to get some more power from the intake upgrade. The .550" valve lift limit is right above my cam specs with my 1.6 rockers.
Would Recommend
FlowTek 180cc intake port, flat tappet hydraulic cam
5.0
2 months ago
Duke
Manhattan KS.
Verified
Mounted heads on my SBC 357 CI. All parts in the kit fit as it should. Had to order longer pushrods + 0.100 after checking pushrod lenght.
Would Recommend
Flotek 180cc Heads for Hydraulic Flat Tappet
5.0
2 months ago
Duke
Manhattan KS.
Verified
Installed kit and I am waiting for the weather to break to finish installation of engine.
Would Recommend
Decent budget SBC Cylinder heads
4.0
3 months ago
Iam Brad
Raleigh NC
Verified
These are pretty nice heads for the price. They are not perfect but considering the price they are decent enough. I also like that this kit came with the head gaskets and head bolts included.
Would Recommend
yesthe fit was perfect
5.0
5 months ago
frank nova
orange ma
Verified
nice product and kit with gaskets decent price
I would definitely recommend getting this Flow Tec kit
5.0
a year ago
Goyo
Eloy Az.
Verified
This Flow Tec kit worked perfectly on my 383 stroked engine . Everything was included to do the top end. Cranked it up,fired on the first go. Opened up the breathability and definitely woke up the cam!! I wouldn't hesitate to tell people to purchase this product.
Would Recommend
I like these aluminum heads
5.0
a year ago
68 vette
Humboldt ks
Verified
Kit contained parts to change from iron head to aluminum. Needed to buy roller rocker arms. All parts fit and finish were great. Engine seems to perform better.
Would Recommend
Good weight reduction
5.0
a year ago
Corvette Tom
Oklahoma City OK
Verified
Good quality heads with good components, only issue was because of the slightly different dimensions the accessory holes were located slightly different and the A/C mount on the head needed to be modified to mount up to compressor.
Would Recommend
Showing 10 of 16 reviews
Fitment
Fitment
1973-1975 Chevy Bel Air
Gen 1 L48 Small Block Chevy
1972 Chevy Blazer
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1973-1974 Chevy Blazer
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1973-1975 Chevy C10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1976-1982 Chevy C10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983 Chevy C10
2-Piece Rear Main Chevy 350
Gen 1 LG3 Small Block Chevy
1984 Chevy C10
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1985 Chevy C10
2-Piece Rear Main Chevy 350
Gen 1 LG3 Small Block Chevy
1986 Chevy C10
Gen 1 LG3 Small Block Chevy
1972-1975 Chevy C10 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1976-1982 Chevy C10 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983 Chevy C10 Suburban
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1984 Chevy C10 Suburban
2-Piece Rear Main 305 LG4
Gen 1 L48 Small Block Chevy
1985 Chevy C10 Suburban
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1986 Chevy C10 Suburban
2-Piece Rear Main 305 LG4
1982-1987 Chevy C15
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LE9 Small Block Chevy
1972-1976 Chevy C20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1982 Chevy C20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983 Chevy C20
2-Piece Rear Main 305 LG4
1984 Chevy C20
2-Piece Rear Main 305 LG4
Gen 1 L48 Small Block Chevy
1985-1986 Chevy C20
2-Piece Rear Main 305 LG4
1972-1975 Chevy C20 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1976-1978 Chevy C20 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1979-1982 Chevy C20 Suburban
2-Piece Rear Main 305 LG4
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1983 Chevy C20 Suburban
2-Piece Rear Main 305 LG4
1984 Chevy C20 Suburban
2-Piece Rear Main 305 LG4
Gen 1 L82 Small Block Chevy
1985-1986 Chevy C20 Suburban
2-Piece Rear Main 305 LG4
1966 Chevy C30
Gen 1 L79 Small Block Chevy
1972-1977 Chevy C30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1978-1979 Chevy C30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1980-1982 Chevy C30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1984 Chevy C30
Gen 1 L46 Small Block Chevy
1986 Chevy C30
2-Piece Rear Main 305 LG4
1983-1987 Chevy C35
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1968 Chevy Camaro
327 Chevy Small Block V8
1973-1975 Chevy Camaro
Gen 1 L48 Small Block Chevy
1976-1982 Chevy Camaro
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983-1984 Chevy Camaro
2-Piece Rear Main 305 LG4
1985 Chevy Camaro
2-Piece Rear Main 305 LB9
2-Piece Rear Main 305 LG4
Gen 1 L69 Small Block Chevy
1986 Chevy Camaro
2-Piece Rear Main 305 LG4
1973-1976 Chevy Caprice
Gen 1 L48 Small Block Chevy
1977 Chevy Caprice
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1978-1982 Chevy Caprice
2-Piece Rear Main 305 LG4
Gen 1 L48 Small Block Chevy
1983 Chevy Caprice
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1984 Chevy Caprice
2-Piece Rear Main 305 LG4
Gen 1 L48 Small Block Chevy
1985 Chevy Caprice
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1986 Chevy Caprice
2-Piece Rear Main 305 LG4
1964-1968 Chevy Chevelle
Gen 1 L79 Small Block Chevy
1973 Chevy Chevelle
Gen 1 L48 Small Block Chevy
1965-1968 Chevy Chevy II
Gen 1 L79 Small Block Chevy
1962-1963 Chevy Corvette
Gen 1 L76 Small Block Chevy
1964-1968 Chevy Corvette
Gen 1 L79 Small Block Chevy
1973-1974 Chevy Corvette
Gen 1 L48 Small Block Chevy
1980 Chevy Corvette
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1984 Chevy Corvette
Gen 1 L83 Small Block Chevy
1985 Chevy Corvette
2-Piece Rear Main Chevy 350
1964-1969 Chevy El Camino
Gen 1 L79 Small Block Chevy
1973-1975 Chevy El Camino
Gen 1 L48 Small Block Chevy
1976-1977 Chevy El Camino
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1978-1979 Chevy El Camino
2-Piece Rear Main Chevy 350
Gen 1 LG3 Small Block Chevy
1980-1982 Chevy El Camino
Gen 1 LG3 Small Block Chevy
1983 Chevy El Camino
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1984 Chevy El Camino
2-Piece Rear Main 305 LG4
Gen 1 L81 Small Block Chevy
1985-1986 Chevy El Camino
2-Piece Rear Main 305 LG4
1975-1976 Chevy G10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1982 Chevy G10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983 Chevy G10
2-Piece Rear Main 305 LG4
1984 Chevy G10
2-Piece Rear Main 305 LG4
Gen 1 L82 Small Block Chevy
1985-1986 Chevy G10
2-Piece Rear Main 305 LG4
1970 Chevy G10 Van
2-Piece Rear Main Chevy 350
1972-1974 Chevy G10 Van
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1975-1976 Chevy G20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1982 Chevy G20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983-1986 Chevy G20
2-Piece Rear Main 305 LG4
1972 Chevy G20 Van
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1973-1974 Chevy G20 Van
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L82 Small Block Chevy
1975-1977 Chevy G30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1978-1979 Chevy G30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1980-1981 Chevy G30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1982 Chevy G30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1985 Chevy G30
2-Piece Rear Main 305 LG4
1970 Chevy G30 Van
2-Piece Rear Main Chevy 350
1972-1974 Chevy G30 Van
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1973-1976 Chevy Impala
Gen 1 L48 Small Block Chevy
1977-1982 Chevy Impala
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983 Chevy Impala
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1984 Chevy Impala
2-Piece Rear Main 305 LG4
1985 Chevy Impala
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1972-1976 Chevy K10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1979 Chevy K10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1980 Chevy K10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1981-1982 Chevy K10
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983-1986 Chevy K10
2-Piece Rear Main 305 LG4
1972-1975 Chevy K10 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1976-1982 Chevy K10 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983-1986 Chevy K10 Suburban
2-Piece Rear Main 305 LG4
1972-1976 Chevy K20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1978 Chevy K20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1979 Chevy K20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1980 Chevy K20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1981-1982 Chevy K20
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1985 Chevy K20
2-Piece Rear Main 305 LG4
1972-1976 Chevy K20 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1978 Chevy K20 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1979-1982 Chevy K20 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1985-1986 Chevy K20 Suburban
2-Piece Rear Main 305 LG4
1972-1974 Chevy K30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1982 Chevy K30
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1970-1974 Chevy K5 Blazer
2-Piece Rear Main Chevy 350
1975-1976 Chevy K5 Blazer
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1977-1981 Chevy K5 Blazer
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1982 Chevy K5 Blazer
2-Piece Rear Main 305 LG4
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1983 Chevy K5 Blazer
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1984 Chevy K5 Blazer
2-Piece Rear Main 305 LG4
Gen 1 L48 Small Block Chevy
1985 Chevy K5 Blazer
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1986 Chevy K5 Blazer
2-Piece Rear Main 305 LG4
1973-1975 Chevy Laguna
Gen 1 L48 Small Block Chevy
1976 Chevy Laguna
2-Piece Rear Main Chevy 350
Gen 1 LG3 Small Block Chevy
1964-1967 Chevy Malibu
Gen 1 L79 Small Block Chevy
1973-1975 Chevy Malibu
Gen 1 L48 Small Block Chevy
1976-1982 Chevy Malibu
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1983 Chevy Malibu
2-Piece Rear Main 305 LG4
1970-1971 Chevy Monte Carlo
2-Piece Rear Main Chevy 350
1973-1975 Chevy Monte Carlo
2-Piece Rear Main Chevy 350
1976-1977 Chevy Monte Carlo
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1978-1981 Chevy Monte Carlo
2-Piece Rear Main 305 LG4
1982-1983 Chevy Monte Carlo
2-Piece Rear Main 305 LG4
2-Piece Rear Main Chevy 350
1984-1986 Chevy Monte Carlo
2-Piece Rear Main 305 LG4
1975 Chevy Monza
Gen 1 L48 Small Block Chevy
1976-1979 Chevy Monza
Gen 1 LG3 Small Block Chevy
1973-1974 Chevy Nova
Gen 1 L48 Small Block Chevy
1975 Chevy Nova
2-Piece Rear Main Chevy 350
1976-1979 Chevy Nova
Gen 1 L48 Small Block Chevy
Gen 1 LG3 Small Block Chevy
1975-1979 Chevy P30
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1980-1983 Chevy P30
2-Piece Rear Main Chevy 350
1985 Chevy P30
2-Piece Rear Main Chevy 350
1970 Chevy P30 Van
2-Piece Rear Main Chevy 350
1972 Chevy P30 Van
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1973-1974 Chevy P30 Van
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
1963-1965 GMC 1000 Series
Gen 1 LE9 Small Block Chevy
1967-1968 GMC C15/C1500 Pickup
327 Chevy Small Block V8
1967 GMC C15/C1500 Suburban
2-Piece Rear Main Chevy 350
1968 GMC C15/C1500 Suburban
327 Chevy Small Block V8
1980-1984 GMC C1500
2-Piece Rear Main Chevy 350
1980-1986 GMC C1500 Suburban
2-Piece Rear Main Chevy 350
1967-1972 GMC C25/C2500 Pickup
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1972 GMC C25/C2500 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1974 GMC C35/C3500 Pickup
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1978-1987 GMC Caballero
2-Piece Rear Main Chevy 350
1963-1966 GMC G1000 Series
327 Chevy Small Block V8
1975-1978 GMC G15
2-Piece Rear Main Chevy 350
1967-1974 GMC G15/G1500 Van
2-Piece Rear Main Chevy 350
1964-1966 GMC G1500
327 Chevy Small Block V8
1979-1986 GMC G1500
2-Piece Rear Main Chevy 350
1975-1978 GMC G25
2-Piece Rear Main Chevy 350
1967-1974 GMC G25/G2500 Van
2-Piece Rear Main Chevy 350
1979-1986 GMC G2500
2-Piece Rear Main Chevy 350
1975-1978 GMC G35
2-Piece Rear Main Chevy 350
1967 GMC G35/G3500 Van
2-Piece Rear Main Chevy 350
1970-1974 GMC G35/G3500 Van
2-Piece Rear Main Chevy 350
1979-1986 GMC G3500
2-Piece Rear Main Chevy 350
1964-1966 GMC I1000
327 Chevy Small Block V8
1965-1966 GMC I1500
327 Chevy Small Block V8
1965-1966 GMC I2500
327 Chevy Small Block V8
1966 GMC I3500
327 Chevy Small Block V8
1970-1973 GMC Jimmy
Gen 1 LE9 Small Block Chevy
1974-1977 GMC Jimmy
2-Piece Rear Main Chevy 350
1978-1982 GMC Jimmy
Gen 1 LE9 Small Block Chevy
1983-1984 GMC Jimmy
2-Piece Rear Main Chevy 350
1966 GMC K1000
327 Chevy Small Block V8
1966 GMC K1000 Pickup
327 Chevy Small Block V8
1975-1978 GMC K15
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1975-1978 GMC K15 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1966 GMC K15/K1500 Pickup
327 Chevy Small Block V8
1967-1974 GMC K15/K1500 Pickup
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1974 GMC K15/K1500 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1979-1984 GMC K1500
2-Piece Rear Main Chevy 350
1979-1980 GMC K1500 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1975-1978 GMC K25
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1975-1978 GMC K25 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1974 GMC K25/K2500 Pickup
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1974 GMC K25/K2500 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1979-1984 GMC K2500
2-Piece Rear Main Chevy 350
1979-1986 GMC K2500 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1994-1999 GMC K2500 Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1967-1974 GMC K35/K3500 Pickup
Gen 1 L46 Small Block Chevy
Gen 1 L48 Small Block Chevy
Gen 1 L65 Small Block Chevy
Gen 1 L81 Small Block Chevy
Gen 1 L82 Small Block Chevy
1973-1977 GMC Sprint
Gen 1 LM1 Small Block Chevy
1960-1966 GMC Suburban
Gen 1 L69 Small Block Chevy
Gen 1 L76 Small Block Chevy
1967 GMC Suburban
Gen 1 L46 Small Block Chevy
Gen 1 L76 Small Block Chevy
1987-1991 GMC V1500 Suburban
350 Chevy Small Block V8
1987 GMC V2500
350 Chevy Small Block V8
1987-1991 GMC V2500 Suburban
350 Chevy Small Block V8
1987-1991 GMC V3500
350 Chevy Small Block V8
1975-1977 Oldsmobile Starfire
305 Chevy Small Block V8
1985 Pontiac Firebird
2-Piece Rear Main 305 LB9
2-Piece Rear Main 305 LG4
Gen 1 L69 Small Block Chevy
