#3441094
Fel-Pro 1094 S/B Chevy 265-350 Head Gasket, Embossed Ring, 4.100 Bore
- Has a 4.100" gasket bore and a nominal compression thickness of .015"
- The pre-flattened copper wire ring gaskets will not brinell aluminum heads
- These head gaskets are specifically designed to fit the 265-350 Small Block Chevy engine
$29.99
each
In Stock
$30.99
Save $1.00
Quantity
Need Help? Call to Order
Add to a list
Select an engine to verify Fitment
Select Engine
Product Summary
0.015" Overall Thickness, 4.100" Gasket Bore, Steel
- Has a 4.100" gasket bore and a nominal compression thickness of .015"
- The pre-flattened copper wire ring gaskets will not brinell aluminum heads
- These head gaskets are specifically designed to fit the 265-350 Small Block Chevy engine
- Gaskets have the strength of steel wire sealing with minimum brinelling of aluminum heads
- Manufactured to offer superior heat dissipation and will work with both cast iron and aluminum heads
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyFel-Pro 1094 Details
Fel-Pro 1094 Details
These Fel-Pro gaskets work with both cast iron and aluminum heads. Pre-flattened steel wire ring gaskets have the strength of steel wire sealing with minimum brinelling of aluminum heads. Pre-flattened copper wire ring gaskets will not brinell aluminum heads. They offer superior heat dissipation. Multi-layer steel gaskets offer current leading-edge technology and provide a long-term, leakproof seal called Perma Torque MLS.
- Gaskets are sold each
- Embossed shim
- 4.100" gasket bore
- Nominal compression thickness: .015"
- Compressed volume: 3.2 cc
- Not for use with small block 400. Extra thin to increase compression.
- When using aluminum heads, we recommend gaskets with soft copper wire rings (such as 344-1010). This ensures that the aluminum head is not "scarred" by the combustion seal. Shim style 344-1094 will also work well with aluminum heads.
(JPEG)
Item Details
4.100" bore, .015" thick, 3.2 cc volumeCharts
Guides & Documents
Fel-Pro 1094 Specifications
Fel-Pro 1094 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 1094 |
| Brand | Fel-Pro |
| GENERAL | |
| Sold in Quantity | Each |
| Overall Thickness | 0.015" |
| Gasket Bore | 4.100" |
| Material Type | Steel |
| Notes | Not for use on 400 smallblocks or aluminum blocks with iron linders. Works well with aluminum heads, no brinelling(galling) of the head. |
| GTIN Code | 084113010941 |
Ratings & Reviews
4.5
10 Reviews
Customers appreciate the high quality and practicality of our product, particularly noting its success in engine assembly and classic car restoration. The head gasket's benefit to compression ratings is highlighted, with one user attributing their improved performance to this feature. Our shim gaskets are reportedly the best for enhancing engine power, and are recommended for their thin size and functionality. The customizability, offering specific dimensions, is also commended. The product's evident superiority outshines any negative critiques related to non-product issues, creating an overall satisfied customer experience.
Ratings & Reviews
4.5
10 Reviews
Customers appreciate the high quality and practicality of our product, particularly noting its success in engine assembly and classic car restoration. The head gasket's benefit to compression ratings is highlighted, with one user attributing their improved performance to this feature. Our shim gaskets are reportedly the best for enhancing engine power, and are recommended for their thin size and functionality. The customizability, offering specific dimensions, is also commended. The product's evident superiority outshines any negative critiques related to non-product issues, creating an overall satisfied customer experience.
4.5
10 reviews
5
8
4
1
3
0
2
0
1
1
Most Liked Positive Review
5.0
Needed a special gasket and got it!
Shim head gaskets are not popular. But offer advantages to the engine builder because they are thin. One can obtain minimum quench with minimum decking and of course they can be shacked. I needed a specific dimension and the folks at Speedway gladly researched the gasket and emailed me back promptly. great experience and I have my part.
Most Liked Negative Review
1.0
A great product
One star rating due to shipping catastrophe. They used a box which was too short to accommodate the head gasket length so they simply folded the steel shim gasket as to fit the box. Not good for proper head gasket sealing to have fold marks in the gasketing metal. Returned product for refund
Filter by Ratings
Yes I would buy this again
4.0
a year ago
53K
Wichita, Ks
Verified
Putting a new set of heads on. I have always had good luck with Felpro gaskets
Would Recommend
Re-torquing is a MUST!!!
5.0
a year ago
Dboy
Fredericksburg, Virginia
Verified
Head gaskets worked good. The only thing one will need to remember is to re-torque the head bolts after the first heat cycle!! I re-torqued my head bolts for a 3rd time just to be safe!!
Would Recommend
Yes
5.0
a year ago
Southside
Xenia oh
Verified
On my 355 sbc
Would Recommend
A great product
1.0
3 years ago
Hydrocarbonjunkie
Sidney, Michigan
Verified
One star rating due to shipping catastrophe. They used a box which was too short to accommodate the head gasket length so they simply folded the steel shim gasket as to fit the box. Not good for proper head gasket sealing to have fold marks in the gasketing metal. Returned product for refund
Would Recommend
Yes
5.0
4 years ago
Ike
Wichita kansas
Verified
Engine assembly. Quality product.
Would Recommend
Showing 5 of 10 reviews
