Bilstein S7Z-2060 2 In Shock-7 In Stroke w/Ends-Comp 6/Reb 2
Bilstein S7Z-2060 2 In Shock-7 In Stroke w/Ends-Comp 6/Reb 2
Bilstein

|

#213S7Z2060

Bilstein S7Z-2060 2 In Shock-7 In Stroke w/Ends-Comp 6/Reb 2

$170.50

/each

In Stock


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Dirt Late Model, Modified, Stock Car, Front Position

    See more details

    Key Specs

    Shock TypeMono Tube
    Shock AdjustabilityNon-Adjustable
    Shock Body MaterialSteel
    Body Diameter2.00"
    Shock Body TypeSmooth
    See more specs

    Need To Know

    Made to Order

    This custom item will ship when completed

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Bilstein S7Z2060 Details

    These Bilstein mono tube gas shocks feature digressive valving. This delivers a new level of control by damping slow suspension movements more effectively while not allowing the chassis to be upset by sharp bumps.

    Bilstein has set the standard for years in Sprint Cup, Indy Car and Formula 1. Now it is setting the standard for Modifieds, Late Models and Open Wheel cars with these SZ Series S7Z shocks.

    • Comp. Length: 13.14"
    • Ext. Length: 20"
    • Body Dia.: 2"

    Charts

    Bilstein S7Z2060 Specifications

    KEY SPECS
    MFG. Part #S7Z2060
    BrandBilstein
    Shock TypeMono Tube
    Shock AdjustabilityNon-Adjustable
    Shock Body MaterialSteel
    Body Diameter2.00"
    Shock Body TypeSmooth
    Shock Body SizeLarge Body
    Shock Stroke Range7.00" to 7.99"
    PositionFront
    Stroke7"
    Compression Valving6
    Rebound Valving2
    Mount PositionAny
    Upper Shock Mount1/2" Spherical Rod End
    Lower Shock Mount1/2" Spherical Rod End
    Extended Length Range20.00" to 20.99"
    Extended Length20"
    Compressed Length Range13.00" to 13.99"
    FinishZinc Plated
    Compressed Length13.14"
    Gas ChargedYes
    GENERAL
    RebuildableYes
    Schrader ValveNo
    Shock Stroke7.00
    Coil-Over CompatibleYes
    Valve Positions60 compression - 20 rebound
    Bushing MaterialSteel
    Inside Diameter46 mm
    Shock Eyelet Width.630"
    Bolt Hole Circle.500"
    Hardware IncludedNo
    ColorNatural
    Shock Piston TypeDigressive
    Sold in QuantityEach
    GTIN Code651860744568
