BendPak 5175548 M7K 7,000-LB Capacity Portable Two-Post Lift

Ships FREE!

#9105175548

BendPak 5175548 M7K 7,000-LB Capacity Portable Two-Post Lift

7,000 lb. portable two-post lift - fully stowable
Flush-mounted floor anchors; no trip hazard when stored
Max height 50.5"; 7 lock positions; min pad height 5.5"

Type:

1) Standard

$5,195.00

/each

Factory Shipped

Quantity

Need Help? Call to Order

Add to a list

Product Summary

7000 lbs. Lifting Capacity, 88.5" Overall Height

7,000 lb. portable two-post lift - fully stowable
Flush-mounted floor anchors; no trip hazard when stored
Max height 50.5"; 7 lock positions; min pad height 5.5"
110V, 1.5 HP; for low-ceiling garages
Arm reach 26"-40"; overall height 89.5"

See more details

Key Specs

MFG. Part #	5175548
Brand	BendPak
Lifting Capacity	7000 lbs.
Overall Height	88.5"

See more specs

Need To Know

Truck Shipment

Truck shipments must be pre-paid with a credit card, certified check or money order

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

BendPak 5175548 Details

The BendPak MaxJax M7K is the higher-capacity version of BendPak's patented portable stowable two-post lift, delivering 7,000 lbs. of lifting capability with the same minimal footprint. Internally threaded recessed drop-in floor anchors are flush when not in use — no trip hazard, no permanent hardware in the way. Quick-connect/disconnect hydraulic couplers allow fast setup and teardown, effectively creating a pop-up lift bay on demand.

Low-pressure HVLP direct-drive cylinders eliminate chains and screw mechanisms for smooth, reliable operation. A robust gear-type flow divider ensures consistent, equalized lifting. Each anchor generates up to 16,500 lbs. of tensile strength. Ideal for shops and garages with limited ceiling height where full-size permanent lifts won't fit. 110V, 1.5 HP.

Capacity: 7,000 lbs.; Power: 110V, 1.5 HP
Max height: 50.5\; 7 lock positions; Min pad height: 5.5"
Arm reach: 26"–40"; Overall height: 89.5"
Fully portable and stowable

Whats Included:

1 M7K-110V Two Post Lift
1 Power Unit and Stand
1 M7K-110V Parts Box
4 MaxJax Arms

Specs:

Front Arm Reach Range: 26" - 40"
Height Range: 88.484"
Length Range: 138
Width Range: 105-135
Drive Thru Width Range Comb Units: 74.13" - 104"
Drive Thru Width Standard Configuration Comb Units: 74.13" / 1883 mm
Fully Lowered Comb Units: 4.63" / 119 mm
Height Overall Comb Units: 88.5" / 2247 mm
Max Lifting Height plus Pads and Extensions Top Lock Comb Units: 54" / 1372 mm
Max Lifting Height with Low Adapter Top Lock Comb Units: 48.25" / 1226 mm
Max Lifting Height with Med Adapter Top Lock Comb Units: 48.5" / 1232 mm
Max Lifting Height with Pad Top Lock Comb Units: 45.75" / 1162 mm
Overall Length Comb Units: 26.5" / 673 mm
Overall Width Max Comb Units: 135" / 3429 mm
Amps: 11
Watts: 1210
Motor: 115-230V, 50-60Hz, 1-Ph.
Voltage: 115-230V

Guides & Documents

Technical Information (BendPak)

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

BendPak 5175548 Specifications

KEY SPECS
MFG. Part #	5175548
Brand	BendPak
Lifting Capacity	7000 lbs.
Overall Height	88.5"

GENERAL
Sold in Quantity	Each
Overall Width	105"
Max Lifting Height	50.5"
Locking Positions	7
