Baer Brakes 4302577R 11.65" Classic Series Rear Brake Kit
- Wheel Bolt Pattern: 5x5.0/5.5
- Fits GM C1500 Trucks 88-98
- Stainless Braided Brake Hoses
$808.95
/kit
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Rear Position, 11.65 Inch Rotor Diameter
- Wheel Bolt Pattern: 5x5.0/5.5
- Fits GM C1500 Trucks 88-98
- Stainless Braided Brake Hoses
- Uses Common FMSI D0627 Brake Pad
- Modern Brakes for Small Wheels at an Economical Price
Key Specs
| MFG. Part # | 4302577R |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 5x5 in. | 5x5.5 in. |
| Wheel Bolt Pattern (mm) | 5x127 mm | 5x139.7 mm |
| Rotor Diameter | 11.65 Inch |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyBaer Brakes 4302577R Details
Baer Brakes 4302577R Details
This Baer Classic system features a single piston floating caliper mounted to an 11.65" 1-piece slot, drill, zinc plated rotor. The Classic system includes calipers, rotors, brackets, hardware, stainless braided brake hoses and fittings. The Classic Series is the most cost effective, full feature drum to disc conversions available. The 11.65" Classic system fits some 15" and most 16" or larger wheels. Fits 1988-98 Chevrolet/GMC C1500 2WD Trucks, 92-99 Chevrolet/GMC C1500 2WD SUV's w/OE C-clip (BIH) Rear End & 10" Rear Drums
Formed as Baer, Inc. (Baer Brake Systems) in 1994, founder Hal Baer established the company from a racing background in the Corvette and World Challenge Series by identifying a gap in offerings for his own race cars. By using popular (at the time) PBR and Alcon calipers, he adapted and built complete systems (hose and fittings, etc.) for many popular domestic muscle cars.
Through their early relationships with high-profile OE prototype manufacturers and builders (such as Chrysler, General Motors, Roush, Shelby, Foose, Mark Steilow, Big Red, etc.), Baer became known as the premier domestic brake company which would later translate to being the face of the 'Pro-Touring' market segment. In the early 2000’s, Baer produced their first in-house caliper, the forged Monoblock 6S, which was soon followed by the extruded and machined 2-pc, 6P caliper. By doing this, it greatly reduced Baer's outside caliper dependencies and allowed them to focus even more on developing and manufacturing other components as well and transition from a systems integrator to full brake system builder. Baer Brakes was the official brake of the Overhaulin' TV show and in 2007, Baer was recognized by Hot Rod Magazine as "One of Twenty Companies that Changed the World and today they remain the brake system of choice for many top builders such as Roadster Shop, Ring Brothers, Goolsby Customs, etc., just to name a few. Bear’s success caught the attention of Holley Performance Brands and in 2021, Baer was acquired by them, solidifying Baer’s continued growth as an innovative leader in their space.
Guides & Documents
Baer Brakes 4302577R Specifications
Baer Brakes 4302577R Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 4302577R |
| Brand | Baer Brakes |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 5x5 in. | 5x5.5 in. |
| Wheel Bolt Pattern (mm) | 5x127 mm | 5x139.7 mm |
| Rotor Diameter | 11.65 Inch |
| Minimum Recommended Wheel Diameter | 15 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Front Rotor Included | No |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Rear Rotor Included | Yes |
| GENERAL | |
| GTIN Code | 090127965092 |
Ratings & Reviews
Ratings & Reviews
Fitment
Fitment
1988-1998 Chevy C1500
