Product Summary

Universal Fit, 2-5/8" Overall Diameter, Black

  • Traditional incandescent lighting illuminates around the perimeter of the dial
  • Gauge kit includes custom tuned .1 AFR Resolution Bosch LSU4.2 Sensor, 8ft. wiring harness, 304 stainless steel weld-in bung, bulb and socket assembly, red and green bulb covers, mounting hardware, and detailed instructions for installation
  • AutoMeter’s race proven digital stepper motor electric instruments provide unmatched accuracy which is further increased by utilizing a self calibration sequence during power up
  • Display range of 8:1 to 18:1
  • Suitable for use with gasoline powered engines

Rebates Available

Key Specs

MFG. Part #3579
BrandAutoMeter

Need To Know

This Product Will Ship Free

Shipping Policies & FAQs

Quick and Easy Returns

Return Policy

AutoMeter 3579 Details

Mirroring the functions of Auto Meter's Street Wideband, the Digital Stepper Motor Wideband provides the most important functions necessary to make sure you're extracting the most power possible, safely. An analog needle display integrates seamlessly with other gauges and easily illustrates rate of change as well as the actual value. Our advanced auto calibration system automatically calibrates your gauge on every startup to assure you of the highest degree of accuracy over the entire lifespan of your sensor (no free air calibration is ever necessary). Designed for gasoline applications, this wideband gauge provides the same degree of accuracy and response as the Pro version, but at a reduced cost. Data logging output is included for one wire or two wire systems. Our specially designed O2 sensor and wiring harness are included for ease of installation.
  • Includes bulb and socket assembly with red and green bulb covers
  • Includes 8ft. Wiring Harness
  • Includes custom tuned .1 AFR Resolution Bosch LSU4.2 Sensor
  • Full sweep precision digital stepper motor meter movement.
  • Display range of 8:1 to 18:1
  • Suitable for use with gasoline powered engines

Ships with the following AutoMeter products:

Sending Unit(s):  2243
Adapters/Fittings:  M18X1.5 Fitting and Plug
Wire Harness:  5298
Bulb & Socket:  3220
Light Covers:  Red 3214 & Green 3215
Mounting Hardware:  3245

Ships with the following AutoMeter products:

Sending Unit(s):  2243
Adapters/Fittings:  M18X1.5 Fitting and Plug
Wire Harness:  5298
Bulb & Socket:  3220
Light Covers:  Red 3214 & Green 3215
Mounting Hardware:  3245

Charts

Rebates

AutoMeter Cash for your Dash Rebate - 6/1 to 7/31

2023 Autometer Rebate Banner

AutoMeter Cash for your Dash Rebate. Purchase Must be made between June 1, 2023 and July 31, 2023. Rebate request must be postmarked by August 31,2023. May not be combined with any other offer. No used, second hand, or reconditioned products qualify for this rebate. This rebate is limited to consumers. No dealer or distributor purchases qualify. Ebay and Custom Shop are not eligible. Limit one rebate request per household, per rebate period. All material becomes the property of AutoMeter Products, Inc. AutoMeter Products, Inc. is not responsiblee for incomplete forms or late, lost, illegible, stolen, delayed, un-postmarked, postage due, misdirected mail, or counterfeit products. Rebate requests that, in the sole discretion of AutoMeter Products, Inc., do not strictly comply with the terms and conditions of this offer, including any fraudulent requests, are invalid. Rebate will be in the form of a check in USD funds. Please allow up to 12 weeks for processing.

Rebate Form

AutoMeter 3579 Specifications

KEY SPECS
MFG. Part #3579
BrandAutoMeter
GENERAL
Speedway Motors Catalog Part #182-3579
Overall Diameter2-5/8
Sold in QuantityEach
Gauge TypeElectric
Gauge Range8:1-18:1 AFR
Gauge Face ColorBlack
Bezel FinishBrushed Aluminum
Sending Unit IncludedYes
Lighting TypeIncandescent
Needle ColorFluorescent Red
AFR Gauge TypeWideband
Includes Wire HarnessYes
Includes Mounting Bracket(s)Yes
GTIN Code046074035791
