Product Summary

Universal Fit, 2.06" Body Diameter, Electric Gauge Type

  • Modern LED through-the-dial lighting provides clear visibility during nighttime use
  • Works with most 1965 to 1997 Chevrolet/GM senders
  • 12 and 16 volt compatible, well-suited with nearly every street car or race car electrical system
  • Gauge kit includes mounting hardware and detailed instructions for installation
  • AutoMeter’s race proven air-core electric instruments provide quick and accurate readings

Key Specs

MFG. Part #2013
BrandAutoMeter

Need To Know

Free Shipping on Orders Over $149

Shipping Policies & FAQs

Quick and Easy Returns

Return Policy

Details

One of the most necessary gauges in a dashboard, Auto Meter makes it easy by offering 5 different resistance range configuration to match your existing fuel sending unit. Available in 0-90 ohm (GM mid 60's to mid 90's), 0-30 ohm (early GM), 73-10 ohm (pre 90's Ford and Chrysler), 16-158 ohm (later model Fords) and 240-33 ohm (aftermarket senders such as the Auto Meter 3262). Our patented air core meter movement receives extra dampening to help combat the effects fuel slosh in non-baffled tanks.
  • Features Hi-Def through-the-dial amber LED lighting
  • Works with most 1965 to 1997 Chevrolet/GM senders
  • Features Air-Core meter movement
  • Includes gauge mounting hardware and installation instructions

Ships with the following AutoMeter products:

Mounting Hardware:  2230

Ships with the following AutoMeter products:

Mounting Hardware:  2230

Charts

Specifications

KEY SPECS
MFG. Part #2013
BrandAutoMeter
GENERAL
Overall Diameter2-1/16"
Body Diameter2.06"
Ohm Range0 ohms empty, 90 ohms full
Gauge TypeElectric
Gauge RangeEmpty/Full
LightedYes
Gauge Face ColorBeige
Needle ColorBlack
Bezel FinishChrome
Sold in QuantityEach
NotesGauge, Fuel Level, 2 1/16", 0OE to 90OF, Elec, Prestige Antq. Ivory
Lighting TypeLED
Light ColorYellow/Amber
Includes Mounting Bracket(s)Yes
GTIN Code046074020131
Mount Hole Size2.0625"
