AutoMeter 1205 American Muscle Air-Core Quad Gauge

  • Modern white LED through-the-dial lighting provides clear visibility during nighttime use
  • Kit includes fuel level sender (240E/33F), oil pressure sender, water temperature sender, 2-wire hall-effect speed sender that is compatible with GM/Chrysler applications (7/8" - 18THD), sending unit adapters (1/4", 3/8”, and 1/2" NPT adapters), mounting hardware, and detailed instructions for installation.
See More

$794.99

/each

Factory Shipped


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Universal Fit, Silver, Chrome, White, Fluorescent Red

  • Modern white LED through-the-dial lighting provides clear visibility during nighttime use
  • Kit includes fuel level sender (240E/33F), oil pressure sender, water temperature sender, 2-wire hall-effect speed sender that is compatible with GM/Chrysler applications (7/8" - 18THD), sending unit adapters (1/4", 3/8”, and 1/2" NPT adapters), mounting hardware, and detailed instructions for installation.
  • AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
  • 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
  • Speedometer has a simple push button, 2 mile drive calibration. No dip switches and can be reprogramed at any time to accommodate changes in gear ratio or wheel and tire combination.
See more details

Key Specs

MFG. Part #1205
BrandAutoMeter
Gauge Face ColorSilver
Bezel FinishChrome
See more specs

Need To Know

Need help?

855.313.9176
View the Help Center

Quick and Easy Returns

Return Policy

AutoMeter 1205 Details

Sometimes space is limited. The Auto Meter Quad Gauge provides a solution to limited dashboard space while providing a clean look. Individual Auto Meter air core meter movements for each function provide the accuracy and durability required by even the most demanding applications. Includes a single wire 1/8" NPT temperature sender and a 1/8" NPT oil pressure sender. The voltmeter reads from 8-18v on negative ground electrical systems and fuel level resistance range is 240 ohms empty to 33 ohms full (compatible with Auto Meter's 3262 fuel level sender).
  • Features Hi-Def through-the-dial white LED lighting

Ships with the following AutoMeter products:

Sending Unit(s):  Fuel Sender 3262 - Oil Sender 2242 - Water Sender 2258 - VSS Sensor
Adapters/Fittings:  1/8" NPT Male to 1/8" compression fitting, 1/8" NPT Female to 1/8" compression fitting, 1/8" NPT to 1/4" NPT bushing, 3/8" NPT and 1/2" NPT adapter fittings.
Mounting Hardware:  Brackets Included

Ships with the following AutoMeter products:

Sending Unit(s):  Fuel Sender 3262 - Oil Sender 2242 - Water Sender 2258 - VSS Sensor
Adapters/Fittings:  1/8" NPT Male to 1/8" compression fitting, 1/8" NPT Female to 1/8" compression fitting, 1/8" NPT to 1/4" NPT bushing, 3/8" NPT and 1/2" NPT adapter fittings.
Mounting Hardware:  Brackets Included

Charts

AutoMeter 1205 Specifications

KEY SPECS
MFG. Part #1205
BrandAutoMeter
Gauge Face ColorSilver
Bezel FinishChrome
GENERAL
Sold in QuantityKit
NotesGauge Kit, 2 pc., Quad & Tach/Speedo, 5", American Muscle
GTIN Code046074012051
Lighting TypeLED
Light ColorWhite
Needle ColorFluorescent Red
Bezel StyleSuper Bezel
Gauge Range8K RPM/120 MPH/100 PSI/100-250 °F/8-18V/240OE-33OF
Overall Diameter5"
Included Adapter/Fitting1/8" NPT Male to 1/8" compression fitting, 1/8" NPT Female to 1/8" compression fitting, 1/8" NPT to 1/4" NPT bushing, 3/8" NPT and 1/2" NPT adapter fittings.
Includes Mounting Bracket(s)Yes
Sending Unit IncludedYes

Questions & Answers

1 Question • 1 Answer

Are these guages the correct specifications to fit in the factory in dash housing on a 69 GTO? (My car has 3 - 5" guage openings, it would be nice to have a 3 guage package)

by D

• 10 years ago

1 answer

View Answer

1 of 1 questions shown
