AutoMeter 1108 Fuel Level Gauge, 2 1/16 Inch, Cruiser Ad

Rebate

#1821108

AutoMeter 1108 Fuel Level Gauge, 2 1/16 Inch, Cruiser Ad

Modern white LED through-the-dial lighting provides clear visibility during nighttime use
Gauge kit includes 20 ft. wiring harness, mounting hardware, and detailed instructions for installation
Adjustable Scale w/ 7 preset ranges for common vehicle types (73E/10F, 16E/158F, 0E/30F, 0E/90F, 240E/33F, 107.5E/7F, 131E/12F)

Type:

Fuel Level

5- Gauge SetTachometer Speedometer Water Temperature Oil Pressure

$174.99

/each

Factory Shipped

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Universal Fit, 2-1/16" Gauge Diameter, Lighted, White

Modern white LED through-the-dial lighting provides clear visibility during nighttime use
Gauge kit includes 20 ft. wiring harness, mounting hardware, and detailed instructions for installation
Adjustable Scale w/ 7 preset ranges for common vehicle types (73E/10F, 16E/158F, 0E/30F, 0E/90F, 240E/33F, 107.5E/7F, 131E/12F)
User definable resistance setting programmable anywhere between 0-280 ohms
12 and 16 volt compatible, compatible with nearly every street car or race car electrical system

Rebates Available

See rebate details

See more details

Key Specs

MFG. Part #	1108
Brand	AutoMeter

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

AutoMeter 1108 Details

Traditionally, paring the proper fuel level level gauge to the application could be a more difficult task than it needed to be. The AutoMeter Digital Stepper Motor Fuel Level Gauge drastically simplifies the process with it's easily configurable resistance range. With 7 common configurations stored in memory from the factory, the vast majority of all applications are covered. In the instance your fuel level sender is not included in these preconfigured ranges, an innovative custom calibration mode allows any sending unit that operates between 0 and 280 ohms, empty or full, to be easily paired. Our "snapshot" programming method will allow you to capture the empty and full readings and the gauge does the rest. No matter your application, there simply isn't an easier solution for fuel level monitoring available on the market. A direct plug in wiring harness is included for ease of installation.

Feature Points

Modern white LED through-the-dial lighting provides clear visibility during nighttime use
Gauge kit includes 20 ft. wiring harness, mounting hardware, and detailed instructions for installation
Adjustable Scale w/ 7 preset ranges for common vehicle types (73E/10F, 16E/158F, 0E/30F, 0E/90F, 240E/33F, 107.5E/7F, 131E/12F)
User definable resistance setting programmable anywhere between 0-280 ohms
12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
AutoMeter's race proven digital stepper motor electric instruments provide unmatched accuracy which is further increased by utilizing a self calibration sequence during power up
Domed Lens

Ships With

2230

Rebates

AutoMeter Hod Holidays Up To $150 MIR Select Parts

Purchase $100 or more in eligible AutoMeter products between November 1 and December 31, 2026 and receive a mail-in rebate ranging from $10 to $150, depending on your total qualifying purchase amount. Eligible brands include AutoMeter, Auto Gage, Dedenbear, Marine, Pro-Cycle, Spek-Pro, STACK, and AutoMeter Test Equipment products. To qualify, submit a completed rebate form, your original sales receipt or invoice, and the original UPC/barcode labels cut from each product box. All rebate requests must be postmarked by January 31, 2027. One rebate per household per rebate period; offer cannot be combined with other promotions and is valid only on new qualifying purchases. Incomplete, late, illegible, or non-compliant submissions will be rejected. Rebate requests are subject to verification and approval by AutoMeter Products, Inc., valid for U.S. customers only, and may take up to 12 weeks to process.

Guides & Documents

Fuel Level Gauges Installation Instructions (1821108)

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

AutoMeter 1108 Specifications

KEY SPECS
MFG. Part #	1108
Brand	AutoMeter

GENERAL
Gauge Diameter	2-1/16"
Gauge Style	Analog
Overall Diameter	2-1/16"
Body Diameter	2.06"
Ohm Range	0 to 280 ohms adjustable
Gauge Type	Electric
Gauge Sweep	Full Sweep
Gauge Range	Empty-full
Lighted	Yes
Liquid Filled	No
Gauge Face Color	Ivory/Black
Needle Color	White
Bezel Finish	Chrome
Sold in Quantity	Each
Notes	Has 7 preset ranges for common vehicle types. Stepper motor movement. Includes 16 ft. harness.
Lighting Type	LED
Light Color	White
Sending Unit Included	No
Includes Wire Harness	Yes
Includes Mounting Bracket(s)	Yes
GTIN Code	046074011085
Pointer Color	White
Mount Hole Size	2.0625"
Gauge Number Color	Black
Shape	Round
Memory Storage	No
Playback	No
Sending Unit	Electrical
