All American Billet FDS-LSBF-751 Serpentine Kit, LS F-Body, OP
- All American Billet Black Anodized Serpentine Kit
- LS Budget Engines for F-Body Trucks with AC and Power Steering (On-Board Reservoir)
- Original pulleys (with the triangular cutouts)
$2,125.00
/set
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Mid Depth Water Pump Style, 160 amp Alternator Amperage
- All American Billet Black Anodized Serpentine Kit
- LS Budget Engines for F-Body Trucks with AC and Power Steering (On-Board Reservoir)
- Original pulleys (with the triangular cutouts)
- 6061-T6 Aluminum Construction With Machined Finish
- Includes spacer(s) and hardware
Key Specs
| Water Pump Style | Mid Depth |
| Pulley Style | Serpentine |
| Crankshaft Pulley Included | No |
| Water Pump Pulley Included | No |
| Power Steering Pump Bracket Finish | Black Anodized |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyAll American Billet FDS-LSBF-751 Details
All American Billet FDS-LSBF-751 Details
All American Billet LS Budget Serpentine Kits are an affordable option for those with either truck or F-Body engines with OEM water pump and crank pulley/damper. These kits will bolt onto either engine without having to change the water pump and crank pulley. These kits take the guess work out of your engine swap in one convenient, cost effective package. Our kits come with the option of two different pulley styles, Classic Pulleys (no holes or cutouts) or our original pulleys (with the triangular cutouts), at no additional charge. Each LS Budget Serpentine kit includes: Sanden peanut-style A/C compressor, 160 amp alternator, GM Type II power steering pump with on-board reservoir, 6061 aluminum brackets, pulleys and spacers, belt tensioner, stainless steel mounting hardware and instructions. Available in Black Anodized.
- All American Billet Black Anodized Serpentine Kit
- LS Budget Engines for F-Body Trucks with AC and Power Steering (On-Board Reservoir)
- Original Pulleys (with the triangular cutouts)
- 6061-T6 Aluminum Construction With Machined Finish
- Includes spacer(s) and hardware
- Lifetime Warranty
Guides & Documents
All American Billet FDS-LSBF-751 Specifications
All American Billet FDS-LSBF-751 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | FDS-LSBF-751 |
| Brand | All American Billet |
| Water Pump Style | Mid Depth |
| Pulley Style | Serpentine |
| Crankshaft Pulley Included | No |
| Water Pump Pulley Included | No |
| Power Steering Pump Bracket Finish | Black Anodized |
| Power Steering Pump Brackets Included | Yes |
| Power Steering Pump Bracket Material | Billet Aluminum |
| Power Steering Pump Finish | Black |
| Power Steering Pump Reservoir Finish | Black |
| Power Steering Pump Reservoir Included | Yes |
| Power Steering Pump Reservoir Material | Plastic |
| Power Steering Pump Reservoir Style | Attached |
| Power Steering Pump Style | GM Type 2 |
| Power Steering Pulley Attachment | Press Fit |
| Power Steering Pulley Finish | Black Anodized |
| Power Steering Pulley Grooves | 6-groove, serpentine |
| Power Steering Pulley Included | Yes |
| Power Steering Pulley Material | Billet Aluminum |
| Alternator Material | Cast Aluminum |
| Alternator Finish | Black |
| Alternator Amperage | 160 amp |
| One Wire Alternator | Yes |
| Alternator Pulley Finish | Black |
| Alternator Pulley Grooves | 6-groove, Serpentine |
| Alternator Pulley Included | Yes |
| Alternator Pulley Material | Billet Aluminum |
| Alternator Bracket Finish | Black |
| Alternator Bracket Material | Billet Aluminum |
| Alternator Brackets Included | Yes |
| A/C Compressor Finish | Black |
| A/C Compressor Type | Sanden SD-7 |
| A/C Pulley Finish | Black |
| A/C Pulley Grooves | 6-groove, Serpentine |
| A/C Pulley Included | Yes |
| A/C Pulley Material | Billet Aluminum |
| A/C Bracket Finish | Black |
| A/C Bracket Included | Yes |
| A/C Bracket Material | Billet Aluminum |
| Idler Brackets Included | No |
| Idler Included | No |
| Tensioner Included | Yes |
| Tensioner Style | Spring-loaded |
| Tensioner Cover Finish | Black |
| Tensioner Cover Included | Yes |
| Tensioner Cover Material | Billet Aluminum |
| Hardware Included | Yes |
| GENERAL | |
| Tensioner Pulley Finish | Black |
| Alternator Fan Included | No |
| Belt Included | Yes |
| Notes | Includes Original Pulleys (with Triangular Cutouts) |
| Sold in Quantity | Kit |
Ratings & Reviews
Ratings & Reviews
Questions & Answers
Questions & Answers
Be the first to ask a question.
Fitment
Fitment
1998-2002 Chevy Camaro
GM LS1
1997-2004 Chevy Corvette
GM LS1
1998-2002 Pontiac Firebird
GM LS1
2004 Pontiac GTO
GM LS1
