All American Billet FDS-LS-253-E-CP Serpentine Kit GM Gen3 LS, CP
All American Billet FDS-LS-253-E-CP Serpentine Kit GM Gen3 LS, CP
All American Billet

|

#38802149

All American Billet FDS-LS-253-E-CP Serpentine Kit GM Gen3 LS, CP

  • All American Billet Silverline Series Serpentine Kit
  • For GM/Chevy Gen III LS Engines with No AC and Power Steering (On-Board Reservoir - Edelbrock water pump)
  • Classic Pulleys (no holes or cutouts)
See More

Configuration Type / Pulley Type / Water Pump Brand:

No A/C & W/ P/S / Solid / Edelbrock

No A/C & W/ P/S / Slotted / EdelbrockNo A/C & W/ P/S / Slotted / Tuff StuffNo A/C & W/ P/S / Solid / Tuff StuffW/ A/C & P/S / Slotted / EdelbrockW/ A/C & P/S / Solid / EdelbrockW/ A/C & P/S / Solid / Tuff Stuff

$3,195.00

/set

Factory Shipped


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Three Crankshaft Pulley Bolt Hole Quantity, Machined

  • All American Billet Silverline Series Serpentine Kit
  • For GM/Chevy Gen III LS Engines with No AC and Power Steering (On-Board Reservoir - Edelbrock water pump)
  • Classic Pulleys (no holes or cutouts)
  • 6061-T6 Aluminum Construction With Machined Finish
  • Includes spacer(s) and hardware
See more details

Key Specs

Pulley StyleSerpentine
Crankshaft Pulley IncludedYes
Crankshaft Pulley MaterialBillet Aluminum
Crankshaft Pulley FinishBlack Anodized
Crankshaft Pulley Grooves6-groove, serpentine
See more specs

Need To Know

Need help?

855.313.9176
View the Help Center

Quick and Easy Returns

Return Policy

All American Billet FDS-LS-253-E-CP Details

All American Billet Serpentine Kits are a great way to clean up any engine compartment. Our kits are available with Tuff Stuff Performance or Edelbrock water pumps and are Lifetime Warranty Brackets that are made from 6061-T6 aluminum, and come in Silverline Series finish.

  • All American Billet Silverline Series Serpentine Kit
  • For GM/Chevy Gen III LS Engines with No AC and Power Steering (On-Board Reservoir - Tuff-Stuff water pump)
  • Original Pulleys (with the triangular cutouts)
  • 6061-T6 Aluminum Construction With Machined Finish
  • Includes spacer(s) and hardware
  • Made in the U.S.A.

All American Billet FDS-LS-253-E-CP Specifications

KEY SPECS
MFG. Part #FDS-LS-253-E-CP
BrandAll American Billet
Pulley StyleSerpentine
Crankshaft Pulley IncludedYes
Crankshaft Pulley MaterialBillet Aluminum
Crankshaft Pulley FinishBlack Anodized
Crankshaft Pulley Grooves6-groove, serpentine
Water Pump MaterialCast Aluminum
Water Pump FinishNatural
Water Pump Pulley IncludedYes
Water Pump Pulley MaterialBillet Aluminum
Water Pump Pulley GroovesNon-ribbed
Power Steering Pump Bracket FinishBlack Anodized
Power Steering Pump Brackets IncludedYes
Power Steering Pump Bracket MaterialBillet Aluminum
Power Steering Pump FinishBlack
Power Steering Pump Reservoir FinishBlack
Power Steering Pump Reservoir IncludedYes
Power Steering Pump Reservoir MaterialPlastic
Power Steering Pump Reservoir StyleAttached
Power Steering Pump StyleGM Type 2
Power Steering Pulley AttachmentBolt on
Power Steering Pulley FinishBlack Anodized
Power Steering Pulley Grooves6-groove, serpentine
Power Steering Pulley IncludedYes
Power Steering Pulley MaterialBillet Aluminum
Alternator MaterialCast Aluminum
Alternator FinishBlack
Alternator Amperage160 amp
One Wire AlternatorYes
Alternator Pulley FinishBlack
Alternator Pulley Grooves6-groove, Serpentine
Alternator Pulley IncludedYes
Alternator Pulley MaterialBillet Aluminum
Alternator Bracket FinishBlack
Alternator Bracket MaterialBillet Aluminum
Alternator Brackets IncludedYes
A/C Pulley IncludedNo
A/C Bracket IncludedNo
Idler Brackets IncludedNo
Idler IncludedNo
Tensioner IncludedYes
Tensioner StyleSpring-loaded
Tensioner Cover FinishBlack
Tensioner Cover IncludedYes
Tensioner Cover MaterialBillet Aluminum
Hardware IncludedYes
GENERAL
Crankshaft Pulley Bolt Hole QuantityThree
Water Pump Pulley FinishBlack Anodized
Tensioner Pulley FinishMachined
Alternator Fan IncludedYes
Belt IncludedYes
NotesIncludes Original Pulleys (with Triangular Cutouts). Does not fit LS7. Features Edelbrock water pump. Requires 2004 and later 2-piece thermostat housing. Does not fit VVT engines without removing VVT system.
Sold in QuantityKit

Fitment

  • GM LM4

  • GM LS6

  • GM LS2

  • GM LSA

  • GM LM7

  • GM LQ9

  • 6.2 Chevy LS V8

  • GM L9H

  • GM L94

  • GM LM7

  • GM LQ9

  • 6.2 Chevy LS V8

  • GM L9H

  • GM L94

  • GM LM7

  • GM LQ9

  • 6.2 Chevy LS V8

  • GM L9H

  • GM L76

  • GM LC9

  • GM LMG

  • GM LY5

  • GM LY5

  • GM LM7

  • 4.8 Chevy LS V8

  • GM LM7

  • GM LQ4

  • GM LS1

  • GM LS3

  • GM LS1

  • GM LS1

  • GM LS6

  • GM LS2

  • GM LS3

  • GM LS4

  • GM LS4

  • 4.8 Chevy LS V8

  • GM LM7

  • 4.8 Chevy LS V8

  • GM L20

  • GM LM7

  • GM LY2

  • 4.8 Chevy LS V8

  • GM LM7

  • GM LQ4

  • GM LQ4

  • GM LQ4

  • GM LQ9

  • GM LQ4

  • GM L98

  • GM LM7

  • GM LQ4

  • GM L98

  • GM LQ9

  • GM L98

  • GM LQ4

  • GM L98

  • GM LQ4

  • GM LQ4

  • GM L98

  • GM L98

  • GM LQ4

  • GM LQ4

  • GM L98

  • GM LZ1

  • GM LS3

  • GM LM4

  • GM L77

  • GM LMG

  • GM LY5

  • GM LM7

  • GM L59

  • GM LM7

  • GM LC9

  • GM LMG

  • GM LY5

  • GM LC9

  • GM LMG

  • GM LMG

  • GM LY5

  • GM LQ4

  • GM L96

  • GM LMG

  • GM LY5

  • 4.8 Chevy LS V8

  • GM L59

  • GM LM7

  • 4.8 Chevy LS V8

  • GM LMG

  • GM LY5

  • 6.2 Chevy LS V8

  • GM L9H

  • GM LC9

  • GM LMG

  • GM LZ1

  • GM L9H

  • GM LC9

  • GM LMG

  • GM LZ1

  • GM LC9

  • GM LMG

  • GM LZ1

  • GM LMG

  • GM LY5

  • GM LH6

  • GM LS2

  • GM LM4

  • GM LM4

  • GM LM4

  • 4.8 Chevy LS V8

  • GM LM7

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM L33

  • GM L94

  • GM LM7

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM L33

  • GM L94

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM LM7

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM L33

  • GM L94

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM LM7

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM L33

  • GM L94

  • GM LQ4

  • GM L20

  • GM L9H

  • GM LC9

  • GM LMG

  • GM LZ1

  • GM L33

  • GM L59

  • GM LM7

  • GM LQ4

  • GM LQ4

  • GM LQ4

  • GM LM7

  • GM LQ4

  • GM LQ4

  • GM LQ4

  • GM L96

  • GM LQ4

  • GM LQ4

  • GM L96

  • GM LQ4

  • GM L96

  • GM L96

  • GM LQ4

  • 4.8 Chevy LS V8

  • GM L20

  • GM LM7

  • GM LY2

  • 4.8 Chevy LS V8

  • GM L20

  • GM L94

  • GM LM7

  • GM LY2

  • GM LZ1

  • GM L94

  • GM LC9

  • GM LMG

  • GM LZ1

  • GM LM7

  • GM L59

  • GM LM7

  • GM LQ4

  • GM L96

  • GM LQ4

  • GM L96

  • GM LQ4

  • 6.2 Chevy LS V8

  • GM LH8

  • GM LH9

  • GM LH8

  • GM LH9

  • GM LS1

  • GM LS3

  • GM LS1

  • GM LS2
