Product Summary

Universal Fit, Digital Gauge Series, Black, Black

  • Monitor oil pressure, water temperature, and voltage in one single gauge
  • 2-1/16-inch gauge size mounts directly in dash or in gauge mounting cup
  • Scrolls through each gauge reading or can be set to display just one
  • Matt black gauge face and bezel goes with any interior
  • Simple four wire connection with easy to read white LED display

Key Specs

MFG. Part #911-30305
BrandSpeedway Motors
Gauge SeriesDigital
Gauge StyleElectric
Gauge Set Design3-In-One

Need To Know

Free Shipping on Orders Over $149

Shipping Policies & FAQs

Quick and Easy Returns

Return Policy

Details

  • Standard under dash triple gauge set function in a single gauge form factor
  • 2-1/16-inch gauge provides display of oil pressure, water temperature, and volts
  • Matte black face and bezel go with any interior
  • Simple four wire connection provides all three readings
  • Auto cycle through gauge display or lock the display on a single reading
  • OLED display with white readout and gauge name at bottom
  • Mounts directly in dash or via a gauge mounting cup to dash or steering column

Traditional Triple Gauge Monitoring in A Compact Single Gauge Form Factor

When it comes to gauges for cars, we’ve all seen the traditional triple gauge set panel under 1,000s of dashboards over the years. Heck, one of your rides may even be running aftermarket gauges in a panel like that. The chrome or black panel with aftermarket car gauges, usually oil pressure, water temperature, and voltage gauges, has been a staple of hot rodding for decades, helping owners monitor their performance engines because the stock dash either had only warning lights or, quite frankly, they didn’t work.

The one down side to these classic triple gauge set gauges for cars is the amount of room they would take up. Depending upon your dash’s bottom edge design there may be limited space to mount said panel, and we know of more than a few friends that have bashed their knees into one of these triple gauge set panels too. They’ve become a necessary evil if you will in hot rods, muscle cars, and classic trucks. We know monitoring engine oil pressure and water temperature, along with your charging system voltage, is pertinent to ensure you’re not about to have a bad day, but what if we could combine all three aftermarket car gauges into one simple standard 2-1/16-inch dash gauge for easy monitoring?

No longer do you have to find suitable under-dash real estate and hope you don’t hit it with your knee or fist while shifting or take your eyes off the road because your aftermarket gauges are mounted in a panel all the way at the bottom of your dash or console. With our modern OLED display you can easily monitor oil pressure, water temperature, and voltage in a scrolling pattern, or lock one of the three readings to your screen if you’re more worried about water temperature for example. You can either direct mount into any 2-1/16-inch hole your dash or use a universal gauge pod to mount on your steering column or dash pad.

Wiring is simple, with just four wires to connect for switched 12-volts (red), ground (black), oil pressure sensor (orange), and water temperature sensor (blue). We offer the necessary Oil pressure sending unit and water temperature sending unit separately to get your new “triple gauge set” combo gauge up and running in no time.

Monitor your engine’s vitals without struggling to find enough dash real estate to mount a traditional three gauge set panel with our LED all-in-one single gauge solution.

Specifications

KEY SPECS
MFG. Part #911-30305
BrandSpeedway Motors
Gauge SeriesDigital
Gauge StyleElectric
Gauge Set Design3-In-One
GENERAL
Number of Gauge Housings1
Auxiliary Gauge Diameter2-1/16 Inch
Gauge Face ColorBlack
Bezel FinishBlack
Liquid FilledNo
LightedYes
Lighting TypeDigital LED
Light ColorWhite
Lettering ColorWhite
Mount TypeClamp On
Speedometer IncludedNo
Tachometer IncludedNo
Oil Pressure Gauge IncludedYes
Oil Temperature Gauge IncludedNo
Water Pressure Gauge IncludedNo
Water Temperature Gauge IncludedYes
Fuel Pressure Gauge IncludedNo
Fuel Level Gauge IncludedNo
Vacuum Gauge IncludedNo
Volt Gauge IncludedYes
Ammeter Gauge IncludedNo
Boost/Pyrometer Gauge IncludedNo
Exhaust Pressure Gauge IncludedNo
Odometer Gauge IncludedNo
Overall Diameter2.25"
Overall Length1.125"
Body Diameter2.065"
Includes Mounting Bracket(s)Yes
Hardware IncludedYes
Clock IncludedNo
Oil Pressure Sender IncludedNo
Bezel IncludedYes
Lens StyleFlat
Temperature Sensor Bung IncludedNo
Sending Unit IncludedNo
Sold in QuantityEach
