1959 Cadillac Blue Dot Tail/Stop Light Kit with Frenching Buckets
DeVille, Eldorado, Series 60 Fleetwood, Commercial Chassis, Series 62, Series 75 Fleetwood
- 12 Volt kit features a plastic tail light lens, chrome steel base unit, and a 1157 dual filament bulb.
- Cone diameter: 2-7/8", cone length: 5-3/8", diameter of the base: 2.84", overall Length w/ Base: 6"
- Bare steel buckets allow you to 'French' your 1959 Cadillac tail lights into the body
- Welding & bodywork required
- Both sold as a pair
Build Your KitYou're almost there! This kit has an option or two for you to select. Let us know which options you want for your new kit.
A true classic! This 12-volt kit features a blue dot plastic tail light lens, chrome steel base unit, and an 1157 dual filament bulb. This kit also includes all-steel buckets that allow you to "French" your taillights into the body. Welding & bodywork are required.
- 1157 dual filament bulb
- Blue dot plastic tail light lens
- Sold as a pair
1959 Cadillac Taillight Specs:
- Cone Diameter: 2-7/8"
- Cone Length: 5-3/8"
- Diameter of the base: 2.84"
- Overall Length w/ Base: 6"
Frenching Buckets Specs:
- 3.75" diameter, flat on the base end and a slash-cut on the other
- 9.5" long on the "long" side
- 3.75" long on the "short" side
- 1" diameter center hole (for wires and base of bulb)
- Stock Cadillac 3-bolt pattern on the flat end
- Also have three each 1/4" holes on a 1.75" circle
- 18 gauge, bare, mild steel
- Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
What's In The Kit
1959 Cadillac Tail Light Frenching BucketsPart # 91137059Qty x 1
1959 Cadillac/Caddy Blue Dot Tail Lamp Kit-12V-Chrome Steel Base UnitPart # 91062154-BLUQty x 2
