1932 Ford Lo-Boy Rear End Mounting Kit
Solid Axle Rear Suspension Type, Parallel Leaf Trailing Arm Style, Leaf Spring Spring Type
Build Your KitYou're almost there! This kit has an option or two for you to select. Let us know which options you want for your new kit.
This kit links your rear axle to the '32 Lo-Boy frame mounts using quarter elliptic springs, upper radius rods & a Panhard bar. Quarter elliptic springs not included in kit (sold separately). Builder can cut their own springs from a pair of factory leaves as well. For maximum performance, use Composite Quarter Elliptic Mono-Leaf Springs 974-49934.
See Notes tab for complete kit list.
- Large Panhard bar/right shock mounting bracket
- Left shock mounting bracket
- (2) Radius rod mouting brackets
- (4) Spring mounting brackets
- Spring clamp plates
- (2) Rear radius rods, 21" (cut length)
- Panhard bar, 22.5" (cut length)
- (3) Spherical rod ends, 5/8" right side standard male
- (3) Jam nuts, 5/8" right side
- (3) Spherica rod ends, 5/8" left side standard male
- (3) Jam nuts, 5/8" left side
- (2) Bolts, 5/8" UNF x 5"
- (4) Bolts, 5/8" UNF x 2"
- (6) Lock nuts, 5/8" UNF
- Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
- This item 97449932 is made to order. It will be shipped from our warehouse when it is produced.
What's In The Kit
Standard Steel Heim Joint Rod Ends, 5/8-18 RH MalePart # 1750106Qty x 3
Steel Jam Nut, 5/8-18 RHPart # 1750246Qty x 3
Standard Steel Heim Joint Rod Ends, 5/8-18 LH MalePart # 1750306Qty x 3
Steel Jam Nut, 5/8-18 LHPart # 1750446Qty x 3
24 Inch Plain Steel Hod Rod Tie Rod/Drag Link Sleeve for 5/8-18 EndsPart # 91631-24Qty x 2
32 Inch Plain Steel Hod Rod Tie Rod/Drag Link Sleeve for 5/8-18 EndsPart # 91631-32Qty x 1
Hardware Package LoBoy Rear M TPart # 97449932-1Qty x 1
