Hi-Tech Deluxe Turn Signal Module

SAME DAY SHIPPING! Order within the next 3 hours 55 minutes and receive same day shipping

Specs
Overall Height:
.625
Overall Width:
1.625
Overall Length:
2.250
Sold in Quantity:
Each
Voltage:
12
Notes
Allows use of 1 dual filament bulb per tail light, or the use of front turn signals and rear turn/tail lights.
Hi-Tech Deluxe Turn Signal Module
Hi-Tech Deluxe Turn Signal Module
Hi-Tech Deluxe Turn Signal Module

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

This module combines all of the functions of the Self-Canceling Turn Signal Module and the Tri-Star Module. Engineered for the custom builder or to retro-fit motorcycles not equipped with self-canceling turn signals. Designed for use with individual momentary type turn signal switches mounted on the left and right handle bars.

  • Has 3 timing modes: self canceling, hazard mode, non-self canceling
  • Adds brake light function to turn signals
  • Non-load dependent flash duration: all three modes are flash time constant whether using incandescent or LED lighting
  • Dependable solid-state electronic components
  • Weather proof - potted with soft cell technology to prevent wire chaffing and damage
  • Requires only one taillight bulb per side

910-64070 Instructions (PDF)

Notes

  • Voltage: 12 VDC, negative ground
  • Max Load Capacity: 6 amps per left or right channel
  • Mounting: Secure to flat surface with double sided VHB tape
  • Unit must be mounted at least 12" away from the ignition coil(s)

Here's how it works:

  • Press the appropriate button for 1 second and the turn signal light will flash for 7 seconds, then self cancel.
  • Press for 2 seconds and it will flash for 20 seconds, then self cancel.
  • Press for 4 seconds and it will flash for 75 seconds, then self cancel.
  • Press the same button a second time to manually cancel.
  • To activate the hazard flashers, press both buttons at once. To disengage, press again. (They will flash until disengaged).

Item Details

One taillight bulb per side

Customer Reviews

Rated 4.5 out of 5 by 10 reviewers.
RATING BREAKDOWN
10 reviews
5 Stars
6
4 Stars
3
3 Stars
1
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

Highcrest1
Verified Purchaser
central florida
Product Rating

Outstanding product

March 23, 2015
I am not easily impressed but feel I must give credit when it's due. This product is very simple to wire and works exactly as described. Took longer to figure out a creative way to hide and mount the momentary switches than it did to install the whole system. Works perfectly with both conventional bulbs and LED's, no additional flashers required. Follow the easy to use instructions that are listed on line or on the shipping box. I installed this unit on a "29 roadster project, it was a great inexpensive solution for flashers and turn signals where space was limited and tight. If you are using a column without a built in turn signal system it a solid solution. I will be using this on a '49 pick up and a friends '35 sedan.
Pros:
  • easy to use just as discribed
Cons:
  • None
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

ScottDes
Torrance, CA, USA
Product Rating

great unit for a hot rod

September 30, 2013
didnt want to run a turn signal switch and also running LEDs and this module allows you to accomplish that very clean and simple Great product
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

writeon
Pa
Product Rating

Fantastic Product

September 04, 2013
This is a great product . I have two of these units installed in my vehicles and they work great. I am using LED lights and there is no need for resistors. Hides out of the way nicely. I would recommend this to anyone building a street rod.
Pros:
  • Easy to read instructions
  • WORK GREAT
  • Easy Installation
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

rickertracing
ft worth, texas
Product Rating

coolest thing ever

July 04, 2010
if you are wiring a street legal hot rod, sand rail, or anything else, it doesn't get any easier to wire up brake lights and turn signals. easiy save a couple hours of doing it the old way with trailer converters and flashers. worth every penny. works perfect.
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

46Tbucket23
Dickinson,Texas
Product Rating

I would buy it again

June 09, 2010
It gets the turn lever out of the way the instructions could be a little clearer about where to connect the third brake light and indicator lights if you want them
Pros:
  • Works Great
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Jerry
Broomfield Colorado
Product Rating

Works as advertised

June 07, 2010
Less than an hour to install
Pros:
  • Easy To Install
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Bonzo
Verified Purchaser
L.I. New York
Product Rating

Good solution !

July 19, 2011
This was a good solution for a street rod I wanted to put signals on, but needed the signal switch to be hidden. Module performs well and I liked the fact that it had a brake light input so that I could use the exsisting tail lights for brakes and signals without adding additional lights or modifying light sockets.
Pros:
  • Small and compact
  • Easy To Install
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Bamabucket
Birmingham, AL
Product Rating

Great product!

June 25, 2011
The module is very compact, which made it a good choice for my T-bucket. I didn't have turn signals until I installed the module as part a a major re-wire project. It's small size makes it ideal for vehicles with limited space for electrical components and it is very easy to install. The only thing you need to add is two momentary switches. It doesn't use a thermal flasher, so you can use any type or bulb and the flash rate doesn't change. I am very happy that I installed this unit and don't of anything about it that isn't good.
Pros:
  • Easy To Install
No, I would not recommend this product.
Full Size Image

Was this review helpful? 0 0

Mark
New Berlin, WI
Product Rating

Quality product

January 24, 2010
Quality product and easy to install
Pros:
  • Easy To Install
  • Good directions
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Wheels
Verified Purchaser
Holiday City, Ohio
Product Rating

Deluxe turn signal module

December 05, 2010
I bought a pair of them for a sand rail and cobra project im working on. really worked out pretty well so far. I had a problem with one of the units and the manufacturer replaced it no questions asked.
Pros:
  • Compact Size
  • No need for a flasher
  • Easy to wire up
  • Sealed unit
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

5 questions : 5 answers

Brake pressure switch Ok it's one wire to the brake switch , but there are only two pole brake switches " which creates a path" ?? So what I'm asking is what type of brake switch to use, because it's only one wire to the switch and the brake travels through the left & right turn signal wires , Do I just connect to one pole on a two pole brake switch ???

1 answers
Billy61
us
April 14, 2013

Brake pressure switch Ok it's one wire to the brake switch , but there are only two pole brake switches " which creates a path" ?? So what I'm asking is what type of brake switch to use, because it's only one wire to the switch and the brake travels through the left & right turn signal wires , Do I just connect to one pole on a two pole brake switch ???

Answers

April 15, 2013
Jason
The brake light switch has two poles of which one is hot from the battery and the other goes to the turn signal switch. In the case of the switch number 91064070 if the turn signals are not actuated then when you step on the brake the power goes out of the switch to each rear brake light. If the turn signal is actuated it cycles the power to the front and rear on the side initiated. If the brake light is applied at the same time the switch cycles the lights on the side that the turn signals are actuated. Full instructions are included and also on our website in the purple print PDF instruction file that you are welcome to open.

Do you have the push buttons required to operate this and if so what are the part numbers?

1 answers
Steve
Boone,IA
March 18, 2012

Do you have the push buttons required to operate this and if so what are the part numbers?

Answers

March 21, 2012
John
For the Speedway turn signal modules you can use the basic push button momentary switch from a local electronics store or we offer the starter switch button part number 91364381.

Do you need a flasher unit or is the flasher built into the 91064070?

1 answers
Clem
February 22, 2012

Do you need a flasher unit or is the flasher built into the 91064070?

Answers

February 27, 2012
John
Part number 91064070 This timed module does not require the normal flashers and is self contained and also not automatic canceling. * Press the appropriate button for 1 second and the turn signal light will flash for 7 seconds, then self cancel. * Press for 2 seconds and it will flash for 20 seconds, then self cancel. * Press for 4 seconds and it will flash for 75 seconds, then self cancel. * Press the same button a second time to manually cancel. * To activate the hazard flashers, press both buttons at once. To disengage, press again. (They will flash until disengaged).

when using this product do you recomend sigle or dual filament bulbs, or led lights for the instalation. I have not purchased the lights yet. My bike has no turn signal, running lights at this time.

1 answers
al35hd
Bronson, MI
November 06, 2011

when using this product do you recomend sigle or dual filament bulbs, or led lights for the instalation. I have not purchased the lights yet. My bike has no turn signal, running lights at this time.

Answers

November 07, 2011
Jason
THIS MODULE ALLOWS THE CUSTOMER TO USE ONE DUAL FILAMENT BULB PER REAR TAILLIGHT TO OPERATE THE STOPLIGHT,TURN- SIGNAL, AND TAILLIGHT. ( 1 MODULE PER CAR NEEDED )

Does this product replace the flasher unit

1 answers
May 19, 2011

Does this product replace the flasher unit

Answers

May 23, 2011
John
This is an electronic turn signal module designed to be used where space limitations or customer preference desires. No turn signal lever is required and small momentary switches are used to turn on the module. There are optional modes for time the turn signals stay on, non canceling, and stop light also function. No flasher is required. This part number is for single dual filament bulbs and works in conjunction with the brake light switch.
