Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear
Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear

Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear

5 on 4.75" Bolt Pattern, 14 Inch Rotor Diameter, Four Caliper Pistons, Powder Coated

0 Reviews | 0 Answered Questions
Factory Shipped
Ships FREE
Select your vehicle to verify fitment.
Select Vehicle
Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear
Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear
Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear
X
Wilwood 140-14650-CSICR AERO4 WCCB Carbon-Ceramic Big Brake Rear
Zoomed In Image
We estimate this item will ship on or before December 11th.
Part # 83514014650CSICR
$6,937.50
kit
Call to Order
Add to Buildlist
Compare
Details
Reviews
Q&A
Videos & Articles

Important Messages:

  • This item ships directly from the manufacturer. It may take an additional 3 business days for Wilwood to ship this item.
  • Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
  • This item ships via Ground Shipping only. Expedited and Air shipping options are not available.

Details

Bolt Pattern:
5 on 4.75"
Rotor Diameter:
14 Inch
Caliper Pistons:
Four
Caliper Finish:
Powder Coated
MFG. Part #:
140-14650-CSICR
Minimum Recommended Wheel Diameter:
18 Inch
Rotor Thickness:
1.1"
Stud Diameter:
0.52"
Brake Pad Material:
PCM
Mount Type:
Radial
Total Piston Area:
1.98 sq. in.
Piston Type:
Stainless
Rotor Style:
Plain Face
Rotor Finish:
Plain
Rotor Material Type:
C/SiC
Bedded:
No
Balanced:
No
Hat Finish:
Type III Anodize
Hat Bolt Circle 1:
5 x 4.75
Hat Material Type:
Aluminum
Hat Offset Dimension:
0.66"
GTIN Code:
889545082104

Info

AERO4 WCCB Carbon-Ceramic Rotor Rear Brake Kits offer an extreme performance upgrade featuring WCCB Carbon-Ceramic Dynamic Mount Rotors with Wilwood’s exclusive Bobbin Mounting System. AERO4 WCCB kits are engineered to maximize braking capacity inside custom wheels. Rear parking brake kits offer a simple bolt-on installation and are fully compatible with ABS and OE master cylinder output. AERO4 calipers are a competition proven and offer fully detail machined forged caliper body demonstrates superior strength and resistance to deflection and separation under high load. 14.00” WCCB rotors are made from a proprietary blend ceramic matrix composite material commonly known as Carbon-Ceramic and dynamically using Wilwood’s proprietary integrated anti-rattle Bobbin Mounting System. WCCB rotors offer higher thermal conductivity and heat capacity in excess of conventional iron or titanium rotors of similar or even greater weight and have been developed to withstand extreme temperatures with the highest possible degree of resistance against distortion, warping, cracking and wear.

Installation Instructions (PDF)
