Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor

Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor

Two Caliper Pistons, 1.04" Rotor Thickness, Aluminum, Powder Coated, 1.25" Bore Size, Red

0 Reviews | 0 Answered Questions
Factory Shipped
Ships FREE
Select your vehicle to verify fitment.
Select Vehicle
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
X
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
Wilwood 140-11293-R D52 Rear Brake Kit, 1.25 / 1.25 Piston,1.04 Rotor
Zoomed In Image
We estimate this item will ship on or before December 17th.
Part # 83514011293R
Save 5%
$383.32
$404.99
each
Call to Order
Add to Buildlist
Compare
Details
Reviews
Q&A
Videos & Articles

Important Messages:

  • This item ships directly from the manufacturer. It may take an additional 7 business days for Wilwood to ship this item.
  • Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
  • This item ships via Ground Shipping only. Expedited and Air shipping options are not available.

Details

Caliper Pistons:
Two
Rotor Thickness:
1.04"
Material Type:
Aluminum
Finish:
Powder Coated
Bore Size:
1.25"
Color:
Red
Total Piston Area:
2.46 sq. in.
Pad Area:
10.00 sq. in.
Pad Volume:
3.90 cu. in.
Mount Type:
Floating
Caliper Type:
D52
Caliper Finish:
Powder Coated
Piston Type:
Stainless
Brake Pad Compound:
BP-10
Position:
Rear
MFG. Part #:
140-11293-R
GTIN Code:
889545012613

Info

Wilwood's D52 Rear Caliper Kit offers a matching rear replacement option for our front D52 calipers. It is a direct bolt-on 2-piston replacement for the factory original single piston calipers used on many custom application rears. With the added benefit of smaller rear piston sizing (2.46 sq-inches of area) not normally available in OEM calipers, for correct front and rear bias. Forged billet aluminum bodies, stainless steel pistons, and competition style high-temperature seals put an end to the rust, bore pitting, and seal failures that plague the OE caliper design. D52 calipers provide low-maintenance performance and a huge weight savings with high temperature reliability for the street and track. D52 calipers mount in the stock location over stock rotors, use the original style OE D52 brake pads and an OE 7/16-20 banjo bolt brake line mounting. Calipers can be used with most wheels that clear the OE calipers. Kits contain Wilwoods hardened slide pins and BP-10 high friction pads. Matching rear calipers are also available for custom installations.

Installation Instructions (PDF)

Some parts are not legal for use in California or other states with similar laws/regulations
