Key Specs

MFG. Part #5075
BrandQA1
Shock TypeTwin Tube
Shock Body MaterialSteel

Need To Know

Free Shipping on Orders Over $149

Quick and Easy Returns

Details

Removable bearing mount allows installation of rubber bumpers or shock extensions. Can also be used with coil-over mount kits - slight drilling of upper spring mount required.

  • Racer Revalveable & Rebuildable
  • No Valving Overlap
  • Precision Machined Piston with P.T.F.E. Piston Band
  • 15mm Centerless Ground, Hard Chrome Plated, Solid Piston Rod
  • Deflective Disc Valving
  • Twin Tube Design
  • 2" O.D. Steel Body
  • Can Be Run Upside Down
  • Use Large Body Tuning Kit # TK01 For Valve Combination Changes Between 0-13

QA1 Bearing End Shock Chart (GIF)

Specifications

KEY SPECS
MFG. Part #5075
BrandQA1
Shock TypeTwin Tube
Shock Body MaterialSteel
GENERAL
Shock Stroke Range7.00" to 7.99"
Compression Valving5
Rebound Valving5
Shock Stroke7.00
Upper Shock Mount1/2" Spherical Rod End
Lower Shock Mount1/2" Spherical Rod End
Extended Length Range20.00" to 20.99"
Extended Length20"
Compressed Length Range13.00" to 13.99"
Compressed Length13"
FinishPowder Coated
Coil-Over CompatibleYes
Body Diameter2.00"
Valve Positions5 compression - 5 rebound
Bushing MaterialSteel
Sold in QuantityEach
Shock Eyelet Width.625"
Bolt Hole Circle.500"
Hardware IncludedNo
