#54727014
MSD 27014 Atomic Airforce LS7 Intake Manifold, Gray
Discontinued
This item is currently not available
Shop all Intake Manifolds
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyMSD 27014 Details
MSD 27014 Details
The MSD Atomic AirForce intake manifold delivers improved airflow and distribution to improve the performance of stock and modified engines.The unique bell-mouthed runner entrances maximize airflow and minimize shrouding - all while optimizing the available plenum volume for an unobstructed flow path over opposing runners. The polymer molded 2-piece design allows for easy access to the runners for porting.Atomic AirForce accepts an OEM or 103mm throttle body as well as stock or aftermarket fuel rails*. The intake bolts on and is supplied with new gaskets and hardware for a direct bolt-on package.
- CARB Approved, 50 State Legal EO# D-722-3
- Designed using Computational Fluid Dynamic Modeling to create optimal plenum volume and efficient air flow paths
- The two-piece manifold design provide convenient access to the runners for porting
- Direct flow path runner design promotes maximum airflow
- 103mm Throttle bore allows the use of large throttle bodies for greater air flow
- Polymer material resists heat soak and minimizes weight
- Allows for the use of stock, and aftermarket fuel rails
- Available with Red, Black or Gray logos
Charts
Guides & Documents
MSD 27014 Specifications
MSD 27014 Specifications
D-722-3
| KEY SPECS | |
|---|---|
| MFG. Part # | 27014 |
| Brand | MSD |
| CARB EO# | |
| GENERAL | |
| Injection Style | Multi-port |
| EGR | No |
| Throttle Body Bore Size | 103mm |
| Intake Section Included | Complete |
| Plenum Material | Polymer |
| Plenum Finish | Black |
| Base Finish | Black |
| Base Material | Polymer |
| Throttle Body Included | No |
| Injectors Included | No |
| Aftermarket Fuel Rail Required | Yes |
| Fuel Rails Included | No |
| Runners Included | Yes |
| Runners Removable | Yes |
| Supplemental Bosses Cast-In | Yes |
| Supplemental Bosses Machined | Yes |
| Supplemental Boss Quantity | 8 |
| Sold in Quantity | Each |
| GTIN Code | 085132270149 |
