    ATOMIC AIRFORCE LT1 INTAKE MANIFOLD, SILVER

    Performance, polymer intake manifold for GM LT1 engines.

    The MSD Atomic AirForce intake manifold delivers improved airflow and distribution to improve the performance of stock and modified engines.

    The unique bell-mouthed runner entrances maximize airflow and minimize shrouding - all while optimizing the available plenum volume for an unobstructed flow path over opposing runners. The polymer molded 2-piece design allows for easy access to the runners for porting.

    Atomic AirForce accepts an OEM or 103mm throttle body as well as stock or aftermarket fuel rails*. The intake bolts on and is supplied with new gaskets and hardware for a direct bolt-on package.

    Features:

  • CARB Approved, 50 State Legal EO# D-722-3
  • Designed using Computational Fluid Dynamic Modeling to create optimal plenum volume and efficient air flow paths
  • The two-piece manifold design provide convenient access to the runners for porting
  • Direct flow path runner design promotes maximum airflow
  • 103mm Throttle bore allows the use of large throttle bodies for greater air flow
  • Polymer material resists heat soak and minimizes weight
  • Allows for the use of stock, and aftermarket fuel rails
  • Available with Red, Black, or Silver logos
  • Charts

    Specifications

    D-722-3
    KEY SPECS
    MFG. Part #27004
    BrandMSD
    CARB EO#
    GENERAL
    Fuel System TypeEFI
    Injection StyleMulti-port
    Material TypePolymer
    FinishBlack
    ColorBlack
    EGRNo
    Throttle Body Bore Size103mm
    Intake Section IncludedComplete
    Plenum MaterialPolymer
    Plenum FinishBlack
    Base FinishPolymer
    Base MaterialBlack
    Throttle Body IncludedNo
    Injectors IncludedNo
    Aftermarket Fuel Rail RequiredNo
    Fuel Rails IncludedNo
    Hardware IncludedYes
    Runners IncludedYes
    Runners RemovableYes
    Supplemental Bosses Cast-InYes
    Supplemental Bosses MachinedYes
    Supplemental Boss Quantity8
    Emission Code1
    Sold in QuantityEach
    GTIN Code085132270040
