Flaming River FR1500 Vega Steering Box
Flaming River FR1500 Vega Steering Box

Flaming River FR1500 Vega Steering Box

Universal Fit, Manual Steering Box Type, Rear Steer Steering Box Orientation, Steel, Painted

14 Reviews | 10 Answered Questions
In Stock
Ships FREE
STORE PICKUP
Availability
Store Pickup Availability
X
Lincoln, NE -
Phoenix, AZ -
Select your vehicle to verify fitment.
Select Vehicle
Flaming River FR1500 Vega Steering Box
Flaming River FR1500 Vega Steering Box
Flaming River FR1500 Vega Steering Box
X
Flaming River FR1500 Vega Steering Box
Zoomed In Image
Part # 91032200
$432.99
each
Call to Order
Add to Buildlist
Compare
Details
Reviews
Q&A
Videos & Articles
  • Features all-new castings and components
  • This box is 30% stronger than the OEM box
  • It is manufactured from aircraft steel alloy
  • It uses a needle bearing design to far outlast the original bushing design of the 70's
  • The durable cast iron and machined steel construction will give years of high-mileage service

Details

Steering Box Type:
Manual
Steering Box Orientation:
Rear Steer
Steering System Type:
Cross-Steer
Steering Ratio:
20:1
Turns Lock to Lock:
5 Turns
Material Type:
Steel
Finish:
Painted
Input Shaft Spline Count:
36
Input Shaft Diameter:
0.625"
Weight:
14 lbs.
Sold in Quantity:
Each
MFG. Part #:
FR1500
Notes:
Not recommended for vehicles over 2,000 lbs.

Info

The Flaming River Performance Vega Steering Box is an all new unit designed specifically for street rods. This box is 30% stronger than the OEM box, and it uses a needle bearing design to far outlast the original bushing design of the 70's. The Vega Steering Box features new castings and components. A faithful reproduction of size, shape and mounting hole locations and no core charge.

  • Manufactured from aircraft steel alloy
  • Durable cast iron and machined steel construction will give years of high-mileage service
  • New needle bearing design
  • Crowned sector provides higher torque at center position reduces vibration and provides for more natural return of steering wheel
  • 30% stronger worm and nut
  • 30% stronger sector
  • Bigger gears
  • Chrome cap
  • Bolts up to all normal Vega-type brackets
  • Accepts Vega-spline u-joints, pitman arms and accessories
  • 5/8"-36 spline input shaft

Must use Vega Pitman Arm # 702-2924

Cross Steering Guide (GIF)

Application

This steering box will bolt to and can be utilized with the following steering box mounts:

  • 916-32005 Model T-1934 Ford Frame - Steering Box Mount
  • 916-32003 1935-41 Ford Frame -  Steering Box Mount
  • 916-32004 1941-48 Ford Frame Saginaw Steering Box Mount

Notes

  1. The Vega-style box is preferred by most builders due to the steering geometry of straight axle equipped cars.
  2. Not Recommended for Vehicles over 3,000 lbs.

Specs

  • Output shaft is 1" outside diameter
  • Splined area tapers from .934" to .997"
  • Threaded area takes a 3/4" nut and lock washer
