Edelbrock 776219 Victor Jr Cylinder Head, Chevy 302,327,350,400
Edelbrock 776219 Victor Jr Cylinder Head, Chevy 302,327,350,400

Edelbrock 776219 Victor Jr Cylinder Head, Chevy 302,327,350,400

Chevy Small Block V8, Assembled Cylinder Head Style, Aluminum, Polished, Angle Spark Plug Style

0 Reviews | 0 Answered Questions
Factory Shipped
Ships FREE
Select your vehicle to verify fitment.
Select Vehicle
Edelbrock 776219 Victor Jr Cylinder Head, Chevy 302,327,350,400
Edelbrock 776219 Victor Jr Cylinder Head, Chevy 302,327,350,400
Zoomed In Image
We estimate this item will ship on or before July 31st.
Part # 325776219
Save 33%
$881.99
$1,328.95
each
Quantity:
Add to Cart
Call to Order
Add to Buildlist
Compare

Details
Reviews
Q&A
Videos & Articles

Important Messages:

  • This item ships directly from the manufacturer. It may take an additional 10 business days for Edelbrock to ship this item.
  • Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
  • This item ships via Ground Shipping only. Expedited and Air shipping options are not available.

Details

Cylinder Head Style:
Assembled
Material Type:
Aluminum
Finish:
Polished
Combustion Chamber Volume:
70cc
Intake Runner Volume:
215cc
Exhaust Runner Volume:
85cc
Combustion Chamber Volume Range:
70cc - 79cc
Intake Runner Volume Range:
210cc - 219cc
Exhaust Runner Volume Range:
80cc - 89cc
CNC-Machined Runners:
No
CNC-Machined Combustion Chamber:
No
Spark Plug Style:
Angle
Intake Port Shape:
Rectangle
Intake Port Location:
Standard
Exhaust Port Shape:
Square
Exhaust Port Location:
Standard
Intake Valve Diameter:
2.08"
Intake Valves Included:
Yes
Intake Valve Angle:
23
Exhaust Valve Diameter:
1.6"
Exhaust Valves Included:
Yes
Valve Spring Included:
Yes
Spring Diameter:
1.55"
Damper Spring Included:
Yes
Number of Springs Per Valve:
Dual
Maximum Lift:
0.65"
Machined for O-Ring:
No
Valve Seat Machine Style:
3-angle
Valve Seats Machined:
Yes
Valve Seat Material:
Ductile Iron
Valve Stem Seals Included:
Yes
Valve Stem Seal Type:
Positive Stop
Valve Guides Included:
Yes
Valve Guide Material:
Manganese bronze
Locks Included:
Yes
Lock Style:
7 Degree
Retainers Included:
No
Retainer Material:
Steel
Guideplates Included:
Yes
Guideplate Pushrod Size:
16-May"
Rocker Arms Included:
No
Rocker Arm Studs Included:
Yes
Rocker Arm Nuts Included:
No
Oiling Style:
Through Pushrod
Heat Crossover:
No
Steam Holes Drilled:
No
Accessory Bolt Holes Drilled:
Yes
Notes:
Uses 14mm spark plugs with 3/4" reach, and flat gasket seals
Sold in Quantity:
Each
GTIN Code:
085347992294

Info

Ready to bolt-on out of the box. Affordable, top quality. 500+ HP potential. High-flow 210cc intake ports. CNC gasket-matched part entries and exits.
  • Ready To Bolt On; Out-Of-The-Box
  • Affordable; Top Quality
  • 500+ hp Potential
  • High-Flow 210cc Intake Ports
  • CNC Gasket-Matched Part Entries/Exits
  • 0.130 in. Raised 75cc Exhaust Parts
  • Stainless Steel Swirl-Polished Valves
  • Phosphor Bronze Valve Guides
Some parts are not legal for use in California or other states with similar laws/regulations
