#3257581
Edelbrock 7581 RPM Air Gap Intake Manifold, Ford 351W
$468.95
each
In Stock
Add to a list
Share
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
351W, Carbureted Fuel System Type, Aluminum, Natural
See more details
Key Specs
MFG. Part # | 7581 |
Brand | Edelbrock |
Intake Manifold Type | Dual Plane |
RPM Range | 1,500-6,500 |
Material Type | Aluminum |
See more specs
Need To Know
This Product Will Ship Free
Shipping Policies & FAQsNeed help?
855.313.9176Quick and Easy Returns
Return PolicyEdelbrock 7581 Details
Edelbrock 7581 Details
Based on performer RPM-series with unique air gap. Air gap cooler and denser mixture for more power. Designed for 1500 to 6500 RPM. Improve performance on the street or race track.
Larger cross-sectional area and taller carb flange. Compatibility with large displacement 351W based engines. For 4 bbl carbs. Available in cast finish.
- Based on Performer RPM-Series with Unique Air Gap
- Air Gap Cooler and Denser Mixture for More Power
- Designed For 1500 To 6500 RPM
- Designed For Street And High Performance
- Larger Cross Sectional Area
- Taller Carb Flange
- Compatibility w/Large Displacement 351W Based Eng.
Charts
Guides & Documents
CARB Warning
Follow EPA, CARB, and state regulations for engine changes
CARB Warning
Follow EPA, CARB, and state regulations for engine changes
Emissions warning: this part is for vehicle engine changes, not direct oem engine replacements. In California, engine changes are legal when done in compliance with California bureau of automotive repairs (bar) engine change policy. For assistance, call bar referee at: (800) 622-7733. And see https://bar.Ca.Gov/consumer/smog_check_program/engine_changes. All customers must comply with federal epa mobile source enforcement memorandum no. 1a (and addendum) and all applicable state regulations when conducting engine changes. Improper installation and/or use of this part in California may subject the installer and/or owner to a $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and laws of all states for use of this engine change part on makes or models of vehicles that render them noncompliant with applicable state and/or federal emission laws with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine
Edelbrock 7581 Specifications
Edelbrock 7581 Specifications
KEY SPECS | |
---|---|
MFG. Part # | 7581 |
Brand | Edelbrock |
Intake Manifold Type | Dual Plane |
RPM Range | 1,500-6,500 |
Material Type | Aluminum |
GENERAL | |
Speedway Motors Catalog Part # | 325-7581 |
Fuel System Type | Carbureted |
Carburetor Quantity | One |
Carburetor Flange Type | 4-Barrel Square Bore |
Finish | Natural |
EGR | No |
Intake Section Included | Complete |
Gaskets Included | No |
Overall Height | 5.75" |
Bolt Hole Pattern | 5.160" x 5.625" |
Sold in Quantity | Each |
Notes | No provisions for exhaust-heated chokes. No exhaust crossover. Includes nitrous bosses. May require small base diameter distributors to clear certain thermostat housings. |
GTIN Code | 085347075812 |
