Product Summary

Chevy Small Block V8, Carbureted Fuel System Type

  • Designed for competition Small Block Chevy V8s
  • Manifold provides excellent mid-range to top-end horsepower
  • Extra material is added for port matching and customizing, square bore carburetor flange, and water crossovers drilled and tapped for temp senders/bypass hole.
  • Intake is completely made of aluminum and features a 4-barrel square bore type flange
  • Port dimensions are 1.9" in height and 1.1" in width

Key Specs

MFG. Part #2999
Fuel System TypeCarbureted
Intake Manifold TypeSingle Plane
Carburetor QuantityOne
Carburetor Flange Type4-Barrel Square Bore

Need To Know

This Product Will Ship Free

Quick and Easy Returns

Details

Designed for competition Small Block Chevy V8s used in all forms of racing, the Victor Jr. Tall intake manifold incorporates Edelbrock's extensive knowledge in induction technology. Victor Jr. Series manifolds provide excellent mid-range to top-end horsepower, resulting in race-winning performance. All Victor Jr. manifolds offer extra material added for port matching and customizing, square bore carburetor flange, and water crossovers drilled and tapped for temp senders/bypass holes.

Use the Victor Jr. Tall for the 3500-8000 RPM range when carburetor spacers are not allowed. This manifold is 1" taller than the regular Victor Jr. (at right) and also provides maximum performance for engines with standard port location, iron and aluminum cylinder heads.

Charts

CARB Warning

For race/ off road use only

Emissions warning: this part only legal for sale or use in California for racing (competition) vehicles which may never be used, registered, or licensed for use upon a public highway. Any other use renders the vehicle tampered and not legal for use on California public highways (any public street or roadway, public dirt road, public park, or publicly maintained right of way open to the use of the public for vehicular travel). Violations subject to $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and the laws of all other states with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine.

Specifications

KEY SPECS
MFG. Part #2999
BrandEdelbrock
Fuel System TypeCarbureted
Intake Manifold TypeSingle Plane
Carburetor QuantityOne
Carburetor Flange Type4-Barrel Square Bore
GENERAL
Material TypeAluminum
FinishNatural
EGRNo
Intake Section IncludedComplete
Gaskets IncludedNo
Overall Height5.58"
Port Height1.90"
Port Width1.10"
Bolt Hole Pattern5.160" x 5.625"
Sold in QuantityEach
GTIN Code085347029990
