Edelbrock 1152 94 Two-Barrel Secondary Carburetor
Edelbrock 1152 94 Two-Barrel Secondary Carburetor

Edelbrock 1152 94 Two-Barrel Secondary Carburetor

2 Reviews | 1 Answered Question
Out of Stock
STORE PICKUP
Availability
Store Pickup Availability
X
Lincoln, NE -
Phoenix, AZ -
Select your vehicle to verify fitment.
Select Vehicle
Edelbrock 1152 94 Two-Barrel Secondary Carburetor
Edelbrock 1152 94 Two-Barrel Secondary Carburetor
Edelbrock 1152 94 Two-Barrel Secondary Carburetor
Edelbrock 1152 94 Two-Barrel Secondary Carburetor
X
Edelbrock 1152 94 Two-Barrel Secondary Carburetor
Edelbrock 1152 94 Two-Barrel Secondary Carburetor
Zoomed In Image
Part # 3251152
Call to Order
Add to Buildlist
Compare
Details
Reviews
Q&A
Videos & Articles

Details

Info

Garage Sale Clearance!

In 1938, when Henry Ford needed a more efficient carburetor for his new 24-stud Flathead V8 engine, he contracted development to the Chandler-Groves Company and the 94 two-barrel carburetor was born, fueling Ford engines until production ceased in 1953. Flash-forward to today and the 94 is once again available!

Built around Edelbrock's reputation of bolt-on performance carburetors, the Edelbrock 94 two-barrel carburetor provides nostalgic and period correct hot rods and restorations with the most accurate and best performing carburetor on the market. The Edelbrock 94 features a die-cast bowl and air horn with an aluminum 3-bolt base. These secondary versions of this carburetor feature no choke, making it a must have for multiple carb setups. They both feature an extended throttle shaft to make it easier to install dual and triple carburetor combinations, especially when used with Edelbrock's exclusive progressive linkage. The throttle shaft has also been knurled to prevent the linkage arm from slipping. Extensive testing, both on the road and in our state-of-the-art engine dynamometer facility has allowed Edelbrock to offer a power valve and jetting combination that delivers a wide calibration band for smooth and strong performance in various applications.

  • Machined and assembled by Edelbrock in the U.S.A
  • Features a 3-bolt flange and cast aluminum base
  • Includes calibration instructions for Flathead and small cubic inch V8 engines
  • Match with an Edelbrock intake manifold, cylinder heads, linkage, fuel blocks and Classic series accessories for the complete classic look of the early hot rod era
  • Fits any standard 3-bolt intake manifold

NO WARRANTY, NO RETURNS ON GARAGE SALE ITEMS



Notes

Edelbrock '94 Factory Specifications:

  • Main Jet: .053", #1164
  • Power Valve: 5.5", #1171
  • Float Level: 1-11/32"
  • Fuel Pressure: 3.0-3.5 psi (regulator required)
  • Finish: Zinc-Dichromate

Manufacturer Recommendations:

  • Carb Stud, Nut and Washer Kit - (5/16"-18 x 1-1/4"), #8006
  • Fuel Pressure Regulator with Chrome Finish (1 to 4 PSI), #1789

3251152 '94 Carb Dimensions (PDF)

Multiple Carburetor Tech Tip (Link)

Important Messages:

  • This product is discontinued.
  • This item ships directly from the manufacturer. It may take an additional business days for Edelbrock to ship this item.
  • Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
  • This item ships via Ground Shipping only. Expedited and Air shipping options are not available.
  • This item 3251152 is made to order. It will be shipped from our warehouse when it is produced.
Some parts are not legal for use in California or other states with similar laws/regulations
