Part # 91628907

GM 2.8/3.4 V6 TH350/2004R/700R4/4L60 Transmission Adapter Plate

by

|

  • Mates 60° Chevy V6 to Chevy Turbo 350 transmission
  • Approximately 1/8” thick
  • For TH350 transmission application

$77.99

each

In Stock


Quantity

Select a vehicle to verify Fitment

Product Summary

Chevy 60-Degree V6, Pontiac Iron Duke Inline Four

  • Mates 60° Chevy V6 to Chevy Turbo 350 transmission
  • Approximately 1/8” thick
  • For TH350 transmission application
  • Constructed of the finest steel material and will seal where most gaskets fail

Key Specs

MFG. Part #91628907

Need To Know

Free Shipping on Orders Over $99

Need help? Call 800.979.0122

Quick and Easy Returns

Details

Mates 60° Chevy V6 to Chevy Turbo 350 transmission. Approximately 1/8” thick. For TH350 transmission application.

Application

The "T" or mushroom shaped adapter is the converter adapter. The small end presses into the rear of the V6 crank and the larger I.D. then serves as the pilot for the center hub of the 350 torque converter.

GM used 2 bolt circles for their torque converters (10.75" and 11.5") and most V8 flywheels are double drilled to accept either bolt pattern. Some heavy duty applications, like TH400 big block trucks, used the larger bolt pattern. The V6 flywheel should share the standard small bolt circle of the TH350 converter.

On some applications it may be necessary to drill new (or slot the existing) holes in the V6 flywheel to match the torque converter used. The pilot adapter keeps the converter centered in the rear of the crankshaft, the bolts do not perform that function. It is not a difficult operation, and can be accomplished at home with a drill press, or by any competent machinist. Instructions are included.

The small round machined piece is the center adapter for the torque converter pilot hub. The fastener pictured is a special flush head bolt which must be used on the lower passenger side corner of the adapter for clearance in the dowel pin area.
