Champion 802 V63C 14mm Spark Plug .46 In Reach 5/8 Inch Hex Hotter Gas

Write a Review

Ask a Question

Discontinued
This is a new item in sealed packaging that we no longer carry or is an older version of a product

Out of Stock

This item is currently not available

Shop all Spark Plugs

Product Summary

Universal Fit, Tapered Spark Plug Seat Style

Discontinued
This is a new item in sealed packaging that we no longer carry or is an older version of a product

See more details

Need To Know

Need help?

855.313.9176

View the Help Center

Ineligible for Return

Contains items that cannot be returned

Installation Details

Spark Plugs Instruction Sheet (271V63C)

Installation Tips

While 5/8" (16mm) and 13/16" are the two most common plug hex sizes, plugs can have a hex as small as 8mm or larger than 1".

If you're a tuner or engine builder in search of the perfect spark plug for your current project, pay special attention to the hex size required. Remember to take into consideration not only the diameter of the cylinder head, but also the added thickness of the plug socket needed for installation.

A spark plugs reach is calculated by the length of the threads. It is measured from the seat of the plug to the end of the threads.

It should be noted that the reach does not include the electrodes, or an extended metal shell. When custom-selecting a spark plug, the electrode length and projection should be included in the calculation when taking into consideration the clearance in the combustion chamber.

WARNING: Spark plugs with different seat types are NOT interchangeable.

Spark plugs with a flat seat must be used in engines designed for a gasket seal.
Spark plugs with a tapered seat must be used in engines designed for a tapered seal.

Use of an improper plug in an engine will result in engine damage.

Have a Question?

Talk with one of our experts!

Call Us - 1.855.313.9176

Details

Garage Sale Product

This is Garage Sale priced because it has been discontinued.

NO WARRANTY, NO RETURNS ON GARAGE SALE ITEMS

Champion Racing Series plugs include all the features of their conventional plugs, but are built with extreme engine conditions and durability in mind. For GM & Ford cast iron cylinder heads and some OE design aluminum heads. Will not fit GT40 heads.

Nickel Alloy Ground and Center Electrodes
Copper Core Center Electrode Allows for Increased Conductivity and Heat Control
Peanut Plug
14mm, .460" reach, 5/8" hex
Projected Tip
Heat Range: Hotter (63)

Item Details

14mm, .460" Reach, 5/8" Hex

Application

Spark Plug Application Chart

Charts

Spark Plug Gapping Instructions (GIF)

Champion Spark Plug Guide (JPG)

Champion Heat Range Guide (JPG)

Champion Conversion Chart (JPG)

Autolite, Champion, NGK Cross Reference Chart (PDF)

Guides & Documents

Spark Plugs Instruction Sheet (271V63C)

Spark Plugs Guide/Document (271V63C)
