#213S7G6565
Bilstein F4-BE3-C241-H0 Shock w/Ends-7 Inch-Comp 6.5/Reb 6.5
$152.09
each
In Stock
Order soon, only 3 left in stock!
Add to a list
Share
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Micro Sprint, Midget, Modified, Mono Tube Shock Type
See more details
Key Specs
| Shock Type | Mono Tube |
| Shock Body Material | Steel |
| Body Diameter | 1.55" |
| Shock Body Type | Smooth |
| Shock Body Size | Small Body |
See more specs
Need To Know
This Product Will Ship Free
Shipping Policies & FAQsNeed help?
855.313.9176Quick and Easy Returns
Return PolicyBilstein S7G6565 Details
Bilstein S7G6565 Details
Bilstein SG Series S7G mono-tube gas shocks feature the latest development in shock valving technology; digressive valving. This delivers a new level of control by damping slow suspension movements more effectively while not allowing the chassis to be upset by sharp bumps. Bilstein has set the standard for years in Winston Cup, Indy Car and Formula 1. Now it's setting the standard for Modifieds, Late Models and Open Wheel.
- Use on the front of Modifieds and Sprints
- Also suitable for Midgets, TQ's, Dwarf Cars, etc.
- Monotube gas pressure construction
- Economy price
- Lightweight
- Low rod pressure
- Bilstein's famous consistent, fade-free performance
- Features one bearing end and one welded end
- 1-5/8" steel body
- 7" stroke
- Comp. Length: 12"
- Extended Length: 20"
Bilstein S7G6565 Specifications
Bilstein S7G6565 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | S7G6565 |
| Brand | Bilstein |
| Shock Type | Mono Tube |
| Shock Body Material | Steel |
| Body Diameter | 1.55" |
| Shock Body Type | Smooth |
| Shock Body Size | Small Body |
| Shock Stroke Range | 7.00" to 7.99" |
| Compression Valving | 65 |
| Rebound Valving | 65 |
| Extended Length Range | 20.00" to 20.99" |
| Extended Length | 20" |
| Compressed Length Range | 13.00" to 13.99" |
| Compressed Length | 13" |
| Finish | Powder Coated |
| GENERAL | |
| Shock Stroke | 7.00 |
| Upper Shock Mount | 1/2" Spherical Rod End |
| Lower Shock Mount | 1/2" Spherical Rod End |
| Coil-Over Compatible | Yes |
| Valve Positions | 65 compression - 65 rebound |
| Bushing Material | Steel |
| Sold in Quantity | Each |
| Inside Diameter | 36 mm |
| Shock Eyelet Width | .625" |
| Bolt Hole Circle | .500" |
| Hardware Included | No |
| GTIN Code | 651860489438 |
