AFCO 9850-6021 Straight Vane Brake Rotor, 11.75 x .81 Inch

-16%

#10698506021

AFCO 9850-6021 Straight Vane Brake Rotor, 11.75 x .81 Inch

Name: AFCO 9850-6021 Straight Vane Brake Rotor, 11.75 x .81 Inch
Brand: AFCO
SKU: 10698506021
Price: 83.99 USD
Availability: InStock
Rating: 5 (1 reviews)

1 Review

Ask a Question

Manufactured from premium grade alloys for superb thermal shock stability
It is machined and blanchard ground to assure precise flatness
Features precise vane placement for high volume cooling

Outside Diameter / Thickness:

11.75" x 0.810"

11.75" x 1.25"

$83.99

/each

In Stock

$99.99

Save $16.00

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Universal Fit, Rear Position, Round Rotor Shape, Plain

Manufactured from premium grade alloys for superb thermal shock stability
It is machined and blanchard ground to assure precise flatness
Features precise vane placement for high volume cooling
The extensive lab and track testing have yielded a superior brake rotor
Rotor has a 11.75" diameter and has a 8 x 7.00" rotor hat pattern

See more details

Key Specs

Rotor Diameter	11.75 Inch
Rotor Style	Plain Face
Rotor Material Type	Cast Iron
Rotor Thickness	0.81"
Rotor Hat Bolt Pattern	8 x 7.00"

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

Installation Details

Brake Rotors Installation Instructions (10698506021)

Installation Tips

Proper Break-In Procedure for Steel or Cast Iron Rotors

New steel/iron rotors should be bedded in before being used in racing conditions. Proper bedding will prepare the rotor surface, prolong the rotor's life, and make it more resistant to thermal checking or cracking under severe braking conditions. The following procedures should be performed when bedding in both steel and cast iron rotors. It is best to bed in a new rotor using a used set of pads, preferably ones which will not create heat rapidly. Generating heat too rapidly will thermal shock the rotors. Likewise, when bedding in a new set of brake pads it is best to perform the process on a used rotor. This new/used bedding process permits controlled bedding of each individual component.

Make sure rotor surfaces are free from oils, grease, and brake fluid. Run vehicle up to a moderate speed and make several medium deceleration stops to heat up the rotor slowly. This will help reduce the chance of thermal shock caused by uneven heating of the rotor. Pull into the pits and allow the rotor to cool to ambient air temperature. Care should be taken not to ride the brakes into the pits as this may hot spot the rotor causing premature wear to the surface or structural damage.

Have a Question?

Call one of our U.S.-based customer service professionals.

Tech Support - Opens at NaNpm (UTC)

AFCO 9850-6021 Details

AFCOs disc brake rotors set the pace for design, quality and performance. Special designed materials, enhanced computer imagery and design, as well as extensive lab and track testing have yielded a superior brake rotor. All AFCO rotors have been optimized for strength, weight, and heat dissipation ability to meet the demands of the serious racer.

Premium grade alloys for superb thermal shock stability
Machined and blanchard ground to assure precise flatness
Precise vane placement for high volume cooling

Item Details

8 on 7" Thru
8.30 lbs.

IMCA Approved.

Charts

Instructions (PDF)

Guides & Documents

Brake Rotors Installation Instructions (10698506021)

Warranty Information

Speedway Motors cannot facilitate the return of defective Afco products as they have requested to handle these directly with the consumer. For defective product support and Return Authorization, please contact Afco at +1 (800)-632-2320.

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

AFCO 9850-6021 Specifications

KEY SPECS
MFG. Part #	9850-6021
Brand	AFCO
Rotor Diameter	11.75 Inch
Rotor Style	Plain Face
Rotor Material Type	Cast Iron
Rotor Thickness	0.81"
Rotor Hat Bolt Pattern	8 x 7.00"

GENERAL
Position	Rear
Rotor Shape	Round
Rotor Type	Vented
Rotor Finish	Plain
Weight	8.3 lbs.
Sold in Quantity	Each
