Normally used with Chevy spindles. For use with flat steel steering arms. Can be used with stock type arms if drilled out to 5/8".
These tie rod/drag link kits are pre-cut and tapped lengths of 78" O.D. tubing availablemultiple lengths. Kits come complete with 11/16" traditional 7 tie rod ends and jam nuts. Adjustable from 1/2" shorter to 3/4" longer.Always use anti-seize during final installation.
Tapered Arm Illustration
These tie rod or drag link kits are pre-cut and tapped lengths of 78" O.D. tubing availablemultiple lengths. Kits come complete with 11/16" traditional 7 tie rod ends and jam nuts. Adjustable from 1/2" shorter to 3/4" longer.All lengths measured eye to eye. Tapped right-hand & left-hand threads.
One nut tie rod/drag link kit available as titanium or steel. 12 piece kit.
535AK35Degree of Taper7 degreeOverall Length3.250" (3 1/4")Shank Diameter0.500" (1/2")Shank Length0.600"Thread Pitch1/2"-20Material TypeSteelFinishZincSold in QuantityPair
We make it easy to order replacement parts for your Chevy Camaro. This one part number includes:
We make it easy to order replacement parts for your muscle car. This kit includes:
Normally used with '49-'54 Chevy stylespindles andflat steel steering arms. Can be used with stock type Ford arms if drilled out to 5/8".
These tie rod or drag link kits are pre-cut and tapped lengths of 78" O.D. tubing availablemultiple lengths. Kits come complete with 11/16" traditional 7 tie rod ends and jam nuts. Adjustable from 1/2" shorter to 3/4" longer.All lengths measured eye to eye. Tapped right-hand & left-hand threads. Always use anti-seize during final installation.
We make it easy to order replacement parts for your GM A-Body. This one part number includes:
We make it easy to order replacement parts for your GM A-Body and G-Body. This one part number includes:
These unpolished stainless steel tie rod/drag link kits are pre-cut and tapped lengths of 7/8" O.D. tubing available inmultiplelengths.Each kit comes complete with 5/8" heim joint rod ends and jam nuts. Adjustable 1/4" shorter to 1/2" longer. Always use anti-seize during final installation.
These tie rod or drag link kits are pre-cut and tapped lengths of brushed stainless 78" O.D. tubing available multiple lengths. Kits come complete with 11/16" traditional 7 tie rod ends and jam nuts. Adjustable from 1/2" shorter to 3/4" longer. All lengths measured eye to eye. Tapped right-hand & left-hand threads.
Normally used with '49-'54 Chevy style spindles and flat steel steering arms. Can be used with stock type Ford arms if drilled out to 5/8".
These tie rod or drag link kits are pre-cut and tapped lengths of 78" O.D. tubing available multiple lengths. Kits come complete with 11/16" traditional 7 tie rod ends and jam nuts. Adjustable from 1/2" shorter to 3/4" longer. All lengths measured eye to eye. Tapped right-hand & left-hand threads.
We make it easy to order replacement parts for your GM F-Body. This one part number includes:
This button allen head drag link tie rod kit is available in titanium.
These unpolished stainless steel tie rod/drag link kits are pre-cut and tapped lengths of 7/8" O.D. tubing available inmultiplelengths.Each kit comes complete with 5/8" heim joint rod ends and jam nuts. Adjustable 1/4" shorter to 1/2" longer. All lengths measured eye to eye. Tapped right-hand & left-hand threads. Always use anti-seize during final installation.
These tie rod or drag link kits are pre-cut and tapped lengths of brushed stainless 78" O.D. tubing available in a custom length. Kits come complete with 11/16" traditional 7 tie rod ends and jam nuts. Adjustable from 1/2" shorter to 3/4" longer. All lengths measured eye to eye. Tapped right-hand & left-hand threads. Always use anti-seize during final installation.
5/8" threadedUsed in AFCO tie rod assemblyMost popular tie rod end; fits most rack & pinion cars
To get that traditional look you need to have split wishbones. This kit includes 11/16" weld-in bungs for the wishbones, jam nuts and 11/16" tie rod ends.
91002939Overall Length4.000"Center Hole to End of Shank3Stud Length0.750" (3/4")Stud Diameter0.500" (1/2")ThreadsRH FemaleThread Pitch11/16"-18Thread Length2.000"Material TypeStainless SteelFinishPolishedSold in QuantityEachNotesFit closer to tapered hole compared to our 91002919 which is.150" shorter. 1-1/8" from center of threaded shaft to the bottom of the taper.
This little adjustable tie rod adapter stud allows you to use 5/8" rod ends instead of OEM tie rods. It also allows you to adjust steering geometry.
Hex head 9/16"-18 fine thread nuts for use with Mustang II rack & piniontie rod ends.
91002909Degree of Taper7 degreeStud Length1.750" (1 3/4")Stud Diameter0.630"Shank Diameter0.680"Shank Length2.420"ThreadsRH MaleThread Pitch11/16"-18Thread Length2.130"Material TypeSteelFinishNaturalSold in QuantityEachNotes1" from center of threaded shaft to the bottom of the taper. Includes boot, castle nut, and cotter pin.
91002919Degree of Taper7 degreeStud Length1.750" (1 3/4")Stud Diameter0.630"Shank Diameter0.680"Shank Length2.420"ThreadsLH MaleThread Pitch11/16-18Thread Length2.130"Material TypeSteelFinishNaturalSold in QuantityEachNotes1" from center of threaded shaft to the bottom of the taper. Includes boot, castle nut, and cotter pin.
Tru-Lite's one nut radius rod plus drag link and tie rod kit will fit most Sprints. Kit includes 36 pieces.
"-##" at end of part number indicates length.
Tech Tip: When assembling a tube, each heim end adds approximately 2" to the overall length (assuming the heim is screwed into the tube half way.) If you have a heim on each end of the tube, the working length from eye to eye will be approximately 4" longer overall than the tube. As a rule, your tube length will need to be 4" shorter than your working eye to eye length requirement.
91032218Overall Length4.625" (4 5/8")Overall Width2.000"Diameter0.910"Thread Pitch5/8Sold in QuantityEachNotesMOOG ES2032S
91032214-4Overall Length4.750" (4 3/4")Thread Pitch11/16"Material TypeSteelFinishZincSold in QuantityEachNotesMOOG ES2004S
