1967-79 Mustang Tie Rod and Steering Components
Outer tie rod and inner extension fits left or right, attaches steering rack to spindles. Fits both manual Mustang II and 1982-1988 T-Bird power racks.
Outer tie rod fits left or right, attaches steering rack to spindles. Fits both manual Mustang II and 1982-1988 T-Bird power racks. Measures 1.5" longer than stock outer tie rod end.
1964-66 Mustang Tie Rod and Steering Components.
Inner tie rod extensions for Mustang II/Thunderbird-style steering racks. Includes boots and bands.
This 2" drop steel steering arm fits '37-'48 Ford style spindles. It is tapered to accept an 11/16" tie rod end. Designed for use on upper spindle mount in "traditional steering" set-ups using a reversed Corvair, '48-'56 Ford pickup, or '68-'73 Mustang steering box.
91002909Degree of Taper7 degreeStud Length1.750" (1 3/4")Stud Diameter0.630"Shank Diameter0.680"Shank Length2.420"ThreadsRH MaleThread Pitch11/16"-18Thread Length2.130"Material TypeSteelFinishNaturalSold in QuantityEachNotes1" from center of threaded shaft to the bottom of the taper. Includes boot, castle nut, and cotter pin.
91002919Degree of Taper7 degreeStud Length1.750" (1 3/4")Stud Diameter0.630"Shank Diameter0.680"Shank Length2.420"ThreadsLH MaleThread Pitch11/16-18Thread Length2.130"Material TypeSteelFinishNaturalSold in QuantityEachNotes1" from center of threaded shaft to the bottom of the taper. Includes boot, castle nut, and cotter pin.
Outer tie rods andadjustment sleeves for 1975-1981 Camaro/Firebird. See Application tab to ensure this part fits your vehicle.
91032362Overall Length4.000"ThreadsLH MaleThread Pitch9/16"-18Thread Length2.250" (2 1/4")Material TypeSteelFinishNaturalSold in QuantityEach
Tech Tip: When assembling a tube, each heim end adds approximately 2" to the overall length (assuming the heim is screwed into the tube half way.) If you have a heim on each end of the tube, the working length from eye to eye will be approximately 4" longer overall than the tube. As a rule, your tube length will need to be 4" shorter than your working eye to eye length requirement.
Aluminum tie rod and drag link has a 1-1/8" O.D., 0.156 wall 6061 aluminum. 5/8" NF thread. Available in lengths of 13.5", 16", 17", 17.5", 18", 18.5", 19", 21", 21.5", 22", 22.5", 23", 23.5", 24", 27", 27.5", 28", 29.5", 31", 35", 36", 38", 39", 40", 41", 42", 43", 45", 45.75", 46", 47", 48", 49", 50".
Hex head 9/16"-18 fine thread nuts for use with Mustang II rack & piniontie rod ends.
910353-45-CHROverall Length45.000"Outside Diameter1.130"ColorSilverMaterial TypeChromolyFinishPowder CoatSold in QuantityEachNotesFinished with a "chrome" appearing powder coat.910353-45-PLNOverall Length45.000"Outside Diameter1.130"Material TypeChromolyFinishNaturalSold in QuantityEach910353-46-CHROverall Length46.000"Outside Diameter1.130"ColorSilverMaterial TypeChromolyFinishPowder CoatSold in QuantityEachNotesFinished with a "chrome" appearing powder coat.910353-46-PLNOverall Length46.000"Outside Diameter1.130"Material TypeChromolyFinishNaturalSold in QuantityEach910353-47-CHROverall ...
Finally a bolt-on power rack and pinion for 1955-57 Chevy cars. Simply remove the original steering box, idler arm and tie rod assembly and bolt this unit back in using the original mounting holes. Includes tie rod ends, special steering arms, and a pair of banjo fittings to adapt to AN6 fluid lines. Can be used with most GM steering pumps.
Includes tie rod ends and special fittings that accept AN hoses. Can be used with most GM steering pumps. Must use chassis headers and a stock type pan sump for clearance. Includes special steering arms and a pair of banjo fittings to adapt to AN6 fluid lines. Steering u-joint #910-32255 is required.
