Emergency Brake Replacement Rotor

Specs
Material Type:
Steel
Weight:
2.40
Sold in Quantity:
Each
Finish:
Natural
Bolt Hole Pattern:
2.00" x 3.50"
Rotor Diameter:
8.75
MFG. Part #:
BP15112
Rotor Thickness:
0.19
Rotor Construction:
Solid
Garage Sale:
No
Rotor Location:
Rear
Rotor Shape:
Round
Drilled:
No
Slotted:
No
Emergency Brake Replacement Rotor

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

Emergency brake replacement rotor for kit 715-3250. Bolts behind the driveshaft yoke.

  • 3/16" thick steel
  • 8-3/4" O.D.

Customer Reviews

Rated 4 out of 5 by 1 reviewers.
RATING BREAKDOWN
1 reviews
5 Stars
0
4 Stars
1
3 Stars
0
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

Greg
Verified Purchaser
Salem, NH

Basic, get the job done part

July 12, 2011
I'm building a transfer case mounted parking brake and this rotor fits the bill. My only complaint is that it is plain and not slotted or cross drilled, but that is purely cosmetic. I've already spiffed it up and drilled my own holes.
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

1 questions : 1 answers

1 answers

WHAT ARE THE BOLT HOLE SPACING ? I WOULD LIKE TO USE THIS ON A JAGUAR XJ-6 REAR SUSPENSION FOR A T-BUCKET . THANKS FOR ANY HELP

ORLANDO , FLORIDA
November 14, 2011

WHAT ARE THE BOLT HOLE SPACING ? I WOULD LIKE TO USE THIS ON A JAGUAR XJ-6 REAR SUSPENSION FOR A T-BUCKET . THANKS FOR ANY HELP

Answers

November 15, 2011
Jason
THIS IS A STEEL ROTOR 3/16" THICK, 8-3/4"O.D. AND IT BOLTS BEHIND THE DRIVESHAFT YOKE. The rectangle pattern in the center measures 4.07" x 2.76" and the 4-bolt mount pattern measures center on center 3.47" x 2.0" and uses a hole dia. of 0.328"
Page 1 of 1

You may also be interested in:

Pinion Mounted 9 Inch Ford Emergency Brake
(Part #7153250)


Speedway now offers the stand alone emergency brake system you asked for. Kit includes a 3/16" steel rotor, special pinion adapter, aluminum U-joint girdle, Wilwood mechanical spot caliper, and all hardware.

  • Lightweight aluminum cam-actuated caliper (black anodized)
  • Steel rotor bolts behind the driveshaft yoke
  • U-joint girdle design provides more surface area for the bearing cap for increased strength
  • Girdle manufactured from 7075-T6 aluminum with anodized finish
  • Made in the USA
  • Application specific to Spicer 1310 series u-joint yoke configuration

Ford 9 Inch E-Brake Instructions (PDF)

Lokar EC-8000TP Emergency Brake Cable For Pinion Brake
(Part #49180TP)
                        Required cable for pinion mounted emergency brake # 715-3250.

U-Joint Girdle
(Part #7158580)


Use aluminum girdles for added strength or replacement for 715-3250. Fits Ford 9" small yoke rear axles.

  • Bolts are 1/4" x 2"
  • Measures 1-1/2" center to center
  • Fits 1-1/16" diameter U-joint caps
Wilwood 120-1360 Mechanical Spot Caliper, 1.62 Inch Bore / .25 Disc
(Part #8351201360)


Wilwood caliper for use with mechanical pinion mounted emergency brake. Features a 2-position cam-actuated lever, aluminum construction, and a black anodized finish.

  • Max Rotor Width:  0.25"
  • Min Rotor Width:  0.18"
  • Max Rotor Diameter:  13"
  • Min Rotor Diameter:  6"
  • Mount Type:  Floating
  • Pad Area (in2):  0.9"
  • Pad Volume (in3):  0.31"
  • Caliper Mount Center:  2.95"
  • Caliper Weight:  1.2 lbs.
  • Caliper Dimension (Link)
  • Pad Dimensions (Link)
Note: This spot caliper is a cam driven caliper to allow it to function from either left or right side. If the caliper is assembled at Wilwood with the arm pointing down, you can simply tap out the pin and install the arm in the opposite direction and reinstall the pin.
