This fuel line is intended to connect two Edelbrock (or Carter) four-barrel carbs on a low-rise 2x4 intake. The inlet fitting thread is 3/8" NPT female, and there is a 1/8" NPT hole that can be used for a fuel pressure gauge. The outlets on this adjustable fuel log can be as close together as 6-1/2" and as far apart as 8-1/4". All of this carburetor fuel line is anodized blue, except for the central piece of braided stainless steel hose.
This fuel log supplies fuel to two Edelbrock carbs when used on Edelbrock dual-quad intake manifolds. Adjustable 6-7/16" to 9" center-to-center 1/8" NPT fuel pressure port 3/8" NPT fuel inlet
This fuel line is intended to connect two Edelbrock (or Carter) four-barrel carbs on a low-rise 2x4 intake. The inlet fitting thread is 3/8" NPT female and there is a 1/8" NPT hole that can be used for a fuel pressure gauge. The outlets on thisadjustable fuel logcan be as close together as 6-1/2" and as far apart as 8-1/4". All of this carburetorfuel line is anodized blue except for the central piece of braided stainless steel hose.
This fuel log supplies fuel to two Edelbrock carbs when used on Edelbrock dual-quad intake manifolds. Adjustable 6-7/16" to 9" center-to-center1/8" NPT fuel pressure port3/8" NPT fuel inlet
There is nothing sweeter looking or sounding than a dual quad on a Chevy! This one kit gets you twomanual chokeEdelbrock carbs an Edelbrock unpolished intake manifold fuel line and special progressive linkage. Just add a suggested air cleaner to finish your installation. 1500-6000 RPMWill clear HEI distributorsWill not fit tall-deck truck blocksHas 6-7/16" carb centersOverall Height from the bottom of the intake to the top of the air cleaners below:325-4237: 11.795"325-1235: 11.272"325-4119: 12.965" Height from bottom of intake to carb mounting surface: 4.899" Port exit dimensions: 1.64" ...
There is nothing sweeter looking or sounding than a dual quad on a Chevy! This one kit gets you twomanual chokeEdelbrock carbs an Edelbrock unpolished intake manifold fuel line and special progressive linkage. Just add a suggested air cleaner to finish your installation. 1500-6000 RPMWill clear HEI distributorsWill not fit tall-deck truck blocksHas 6-7/16" carb centersOverall Height from the bottom of the intake to the top of the air cleaners below:325-4237: 11.795"325-1235: 11.272"325-4119: 12.965" Height from bottom of intake to carb mounting surface: 4.899" Port exit dimensions: 1.66" ...
There is nothing sweeter looking or sounding than a dual quad on a Chevy! This one kit gets you twomanual chokeEdelbrock carbs an Edelbrock Vortec style unpolished intake manifold fuel line and special progressive linkage. Just add a suggested air cleaner to finish your installation. Will clear HEI distributors.Fits 1996 and later Vortec (L31) style cylinder headson small block Chevy V8(2) 500 cfm manual choke carbsC-26 Dual-Quad manifold1500-5000 rpmLow profile for hood clearance on most vehicles
There is nothing sweeter looking or sounding than a dual quad on a Chevy! This one kit gets you two manual choke Edelbrock carbs, an Edelbrock Vortec style unpolished intake manifold, fuel line and special progressive linkage. Just add a suggested air cleaner to finish your installation. Will clear HEI distributors. Fits 1996 and later Vortec (L31) style cylinder heads on small block Chevy V8 (2) 500 cfm manual choke carbs C-26 Dual-Quad manifold 1500-5000 rpm Low profile for hood clearance on most vehicles
Performer RPM Dual-Quad intake manifolds are designed to fit 1958-1965 Chevrolet 348/409 "W" Series engines. These manifolds deliver performance improvements in the 1500-6500 rpm range with Edelbrock Performer Series dual-quad carburetors, and they accept Edelbrock dual-quad accessories including fuel lines, throttle linkage, and air cleaners. Includes oil fill tube (not installed) and matching push-in breather cap. Use with dual quad linkage and fuel line at right. Carb center-to-center measurement is 6-7/16". 325-5409 Instructions (PDF)
There is nothing sweeter looking or sounding than a dual quad on a Chevy! This one kit gets you two manual choke Edelbrock carbs, an Edelbrock unpolished intake manifold, fuel line and special progressive linkage. Just add a suggested air cleaner to finish your installation. Will clear HEI distributors. 6-7/16" carb centers. 1957-86 262-400 small block (2) 500 cfm manual choke carbs C-26 Dual-Quad manifold 1500-5000 rpm Low profile for hood clearance on most vehicles
Performer RPM Dual-Quad intake manifolds are designed to fit 1958-1965 Chevrolet 348/409 "W" Series engines. These manifolds deliver performance improvements in the 1500-6500 rpm range with Edelbrock Performer Series dual-quad carburetors, and they accept Edelbrock dual-quad accessories including fuel lines, throttle linkage, and air cleaners. Includes oil fill tube (not installed) and matching push-in breather cap. Use with dual quad linkage and fuel line at right. Carb center-to-center measurement is 6-7/16". 325-5408 Instructions (PDF)
There is nothing sweeter looking or sounding than a dual quad on a Chevy! This one kit gets you two manual choke Edelbrock carbs, an Edelbrock unpolished intake manifold, fuel line and special progressive linkage. Just add a suggested air cleaner to finish your installation. 1500-6000 RPM Will clear HEI distributors Will not fit tall-deck truck blocks Has 6-7/16" carb centers Overall Height from the bottom of the intake to the top of the air cleaners below: 325-4237 : 11.795" 325-1235 : 11.272" 325-4119 : 12.965" Height from bottom of intake to ...
Edelbrock has reintroduced the vintage cast aluminum fuel blocks for dual triple and quad carb applications for your hot rod or custom. This fuel log features a single 3/8" NPT inlet and four 1/4" NPT outlets. Each fuel distribution block has four holes for mounting to a firewall.Polished finish.
Edelbrock has reintroduced the vintage cast aluminum fuel blocks for dual triple and quad carb applications for your hot rod or custom. This fuellog features a single 3/8" NPT inlet and two 1/4" NPT outlets. Each fuel distribution block has four holes for mounting to a firewall.Polished finish.
Stainless throttle cable bracket & spring set. Mounts to rear of Holley Edelbrock AFB Quadrajet Demon and in-line dual quad carburetors. Dual spring design provides a safe reliable throttle return when compared to single spring set-ups.Note: There is no provision in this bracket for an automatic transmission.
