Wilwood 260-4893 Tandem Master Cylinder, 1-1/16 Inch Bore
- Made from durable lightweight aluminum with a large capacity plastic reservoir and dual outlet bores
- Has a 1-1/16" bore with 9/16"-20 inverted flare and 1/2"-20 inverted flare outlets
- Includes two 3/16" brake line fittings
$144.92
/each
In Stock
$156.51
Save $11.59
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Universal Fit, Firewall Position, Tandem Outlet Count
- Made from durable lightweight aluminum with a large capacity plastic reservoir and dual outlet bores
- Has a 1-1/16" bore with 9/16"-20 inverted flare and 1/2"-20 inverted flare outlets
- Includes two 3/16" brake line fittings
- Mounting bolt holes can be adapted to racing pedal assemblies with an optional mounting adapter bracket
- Mount bolt center to center spacing is 3.20"
Key Specs
| MFG. Part # | 260-4893 |
| Brand | Wilwood |
| Master Cylinder Bore Size | 1-1/16 Inch |
| Master Cylinder Material | Aluminum |
| Finish | Anodized |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyWilwood 260-4893 Details
Wilwood 260-4893 Details
Made from durable lightweight aluminum with a large capacity plastic reservoir and dual outlet bores, this Chrysler-style master cylinder utilizes standard O.E.M. internal components. Standard factory mounting bolt holes can be adapted to racing pedal assemblies with an optional mounting adapter bracket 250-3677. This lightweight (2.5 lbs.) reliable master cylinder is used for drag racing, late model stock cars, street rod and off road applications.
Has a 1-1/16" bore with 9/16"-20 inverted flare and 1/2"-20 inverted flare outlets. Included are two 3/16" brake line fittings that will require you to cut and reflare your brake line.
Learn more about selecting the proper master cylinder for your vehicle by reading our tech article.Brake System Selection.
Charts
Specs
- Mount bolt center to center spacing is 3.20"
- Length (mount surface to end of MC) is 8.14"
- Width (reservoir) is 3.61"
- Overall height is 4.83"
- 1-1/16" bore
Guides & Documents
Wilwood 260-4893 Specifications
Wilwood 260-4893 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 260-4893 |
| Brand | Wilwood |
| Master Cylinder Bore Size | 1-1/16 Inch |
| Master Cylinder Material | Aluminum |
| Finish | Anodized |
| GENERAL | |
| Position | Firewall |
| Brake System Type | Disc |
| Outlet Count | Tandem |
| Reservoir Type | Integral |
| Stroke | 1.35" |
| Color | Black |
| Reservoir Included | Yes |
| Number of Mounting Holes | 2 |
| Reservoir Material | ABS Plastic |
| Area | 0.88 sq. in. |
| Weight | 2.5 lbs. |
| Outlet Fitting | 1/2"-20 IFF |
| Outlet Fitting 2 | 9/16"-18 IFF |
| Overall Length | 12.42" |
| Overall Width | 3.61" |
| Overall Height | 4.83" |
| Mounted Length | 8.14" |
| Centerline of Holes | 3.2" |
| Sold in Quantity | Each |
| GTIN Code | 889545067682 |
