Sweet Mfg. Double Steering U-Joint, 5/8 36-Spline to 3/4 DD, Vega/Corvair/GM



                                                        3/4" heim for steering shaft.  Has .757 ball hole. Slides right over standard 3/4" steering shaft. 3/4" NF right hand threads. Jam nut sold separately.









This 3/4" O.D. DD shaft has a 1.00" long "D" design on each end. Made from 1018 steel, weld-on. Excellent for steering shafts or other uses. Order desired length.
NOTE: This DD shaft is only milled with flats on both ends for 1" of length of the shaft. It is not milled the entire length of the shaft and therefore, can not be cut to length unless it is going to be welded to a 3/4" round or has new flats milled into the end. Please see Flaming River DD shaft if fully machined DD shaft is required.






                                                        These solid steering shafts are made for you to cut to fit. 3/4" O.D. 1018 solid steel shaft. Available in 24", 36", 48", 60" and 72" lengths.
Steer Shaft Application Chart








Sometimes you need just a little bit more clearance than a standard steering u-joint can give you. Our double u-joints allow up to 70 degrees of angle or 1" of offset for just those occasions. Made of forged vanadium steel and real needle bearing joints.  5-5/8" overall length.
Overall length is 5-1/2”
O.D. at ends is 1.12”
O.D. in the middle is 1.476”
O.D. at caps is 1.350”
O.D. at cap retainer screws is 1.545”
Length of center section is 2-3/4”
Spline Size (Link)
Steering Box/Rack/Spline Chart (Link)








These polished stainless steel U-joints look great and use a pinch bolt on each end for easy installation.
The OD is 1.650" (41.90mm)
 3-3/4" in total length
This size of spline works with Unisteer's Cross Steer Rack & Pinion,  Prostock Rack, and Manual Camaro Rack & Pinion and is  also the size of manual Mustang Style Rack & Pinions.
Steering U-Joints and Couplers Application Chart (GIF)
Steering Box/Rack/Spline Chart (Link)
Spline Size (Link)
NOTE:  These u-joints contain a safety feature that requires the DD steering shaft to be notched for pinch bolt clearance. Once notched, the pinch bolt MUST be torqued to 45 ft/lbs to ensure a tight fit.






                                                        It's pretty silly to use plain old steel double d shaft with those shiny stainless steel u-joints. We offer this polished stainless steel double D shaft in 18", 22" and 36" cut to fit lengths.





                                                        3/4" heim for steering shaft.  Has .757 ball hole. Slides right over standard 3/4" steering shaft. 3/4" NF right hand threads. Jam nut sold separately.






If you've got spherical rod ends on your vehicle, you'll probably  need  jam nuts. You might also need them for tie-rod ends or other   types of fittings and connectors. Our jam nuts are made from premium   steel (zinc-coated for corrosion prevention), and they're  available  with either right hand or left hand threads.
These steel fine thread jam nuts are for use with rod ends, heim joints, and clevis.
3/4 Inch-16 NF Fine Thread
Sold in bags of six nuts.
Choose left or right thread.







These polished stainless steel U-joints look great and use a pinch bolt on each end for easy installation.
The OD is 1.650" (41.90mm)
 3-3/4" in total length
This U-Joints size is 5/8"-36 count spline by 3/4" DD  Shaft. It is the common size for the Vega style steering box.
Steering U-Joints and Couplers Application Chart (GIF)
Steering Box/Rack/Spline Chart (Link)
Spline Size (Link)
NOTE:  These  u-joints contain a safety feature that requires the DD steering shaft  to be notched for pinch bolt clearance. Once notched, the pinch bolt  MUST be torqued to 45 ft/lbs to ensure a tight fit.







Don't jeopardize your safety with inferior quality steering components. Speedway offers only the finest steering U-joints available. Made by Sweet Manufacturing.
Full compliment bearings
Forged Vanadium steel yokes and u-joint
Highest quality for racing or street
Features needle bearing u-joints
5/8"-36 Spline
Steering U-Joints and Couplers Application Chart (GIF)
Steering Box/Rack/Spline Chart (Link)
Spline Size (Link)
Note:    GM columns measure slightly less than 1"   while IDIDIT and Flaming    River columns measure a true 1".  DO NOT   interchange these u-joints.







Sometimes you need just a little bit more clearance than a standard steering u-joint can give you. Our double u-joints allow up to 70 degrees of angle or 1" of offset for just those occasions. Made of forged vanadium steel and real needle bearing joints.  5-5/8" overall length.
Overall length is 5-1/2”
O.D. at ends is 1.12”
O.D. in the middle is 1.476”
O.D. at caps is 1.350”
O.D. at cap retainer screws is 1.545”
Length of center section is 2-3/4”
Spline Size (Link)
Steering Box/Rack/Spline Chart (Link)
Note:  GM columns measure slightly less than 1"   while IDIDIT and Flaming  River columns measure a true 1".  DO NOT   interchange these u-joints.








Sometimes you need just a little bit more clearance than a standard  steering u-joint can give you. Our double u-joints allow up to 70  degrees of angle or 1" of offset for just those occasions. Made of  forged vanadium steel and real needle bearing joints.
These are 5-3/4" Long
Steering U-Joints and Couplers Application Chart (GIF)
Steering Box/Rack/Spline Chart (Link)
Spline Size (Link)
Note:     GM columns measure slightly less than 1"   while IDIDIT and Flaming     River columns measure a true 1".  DO NOT   interchange these  u-joints.







We now offer ¾” DD shaft machined the entire length of the shaft, making it easier to set up your steering. Carbon steel shaft comes in 22".






                                                        Overall length of 3 1/2 inches long.  Offered with a 3/4 clearances hole for steering heim with a slotted adjustment of 1 7/8 inch long. Bracket is 3/16 thick steel.





                                                        Over all length of 3 1/2 inches long. Offered with a 3/4" clearance hole for steering heim with a slotted adjustment of 1 7/8 inch long angled at a 45 degrees.  Bracket is 3/16 thick steel
