Speedway Clamp-On Leaf Spring Pad

SAME DAY SHIPPING! Most orders ship within 24 hours.

Speedway Clamp-On Leaf Spring Pad

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

Steel clamp-on style leaf spring pads for 3" O.D. axle tubes. Designed for 2-1/2" wide leaf springs.

Sold each.

Customer Reviews

This product has no reviews.

Product Q&A

4 questions : 6 answers

2 answers

would this work on a mopar 8.3/4 rear axle not facing any racing abuse just street

halojumper
Ocala, FL, USA
February 22, 2014

would this work on a mopar 8.3/4 rear axle not facing any racing abuse just street

Answers

March 22, 2014
plainsman
These are fine for a street application.The U bolts you will also be using provide additional support and locating force.
February 24, 2014
EricM
This clamp on spring pad will only work with 3" OD axle tubes. Measure your axle tubes to be sure this will fit. If your tubes are of a different size you will need to use a weld on spring pad.
2 answers

WILL THIS CLAMP ON SPRING PAD TAKE THE TORQUE OF STREET RACING OR SHOULD IT BE WELDED ONCE IN PLACE.

MOUNTAIN EAGLE
FREDERICK, MARYLAND
February 12, 2011

WILL THIS CLAMP ON SPRING PAD TAKE THE TORQUE OF STREET RACING OR SHOULD IT BE WELDED ONCE IN PLACE.

Answers

February 15, 2011
Mike
Thanks for the inquiry on the spring pads, as in any form of racing including circle track we will clamp the pad in proper location and tach weld it to keep the clamp from spinning. I hope this helps. Thanks
February 15, 2011
Mike
Thanks for the inquiry on the spring pads, as in any form of racing including circle track we will clamp the pad in proper location and tach weld it to keep the clamp from spinning. I hope this helps. Thanks
1 answers

Will these clamp on types work on a 97 Chevy s10

Josh
Medford OR.
May 05, 2015

Will these clamp on types work on a 97 Chevy s10

Answers

May 06, 2015
Eric
Expert
This is a universal leaf spring pad. As long as the 2 1/2" width of this pad is compatible with your springs as well as your rear end must have a 3" OD axle tube then this will work.
1 answers

Do you have - or could these be adapted for use with a 2" leaf spring?

AL
Kaslo, BC, Canada
June 28, 2015

Do you have - or could these be adapted for use with a 2" leaf spring?

Answers

June 29, 2015
Eric
Expert
Sorry we do not offer these for 2" wide springs. The issue with using these on narrower springs like that is your U bolts will be spread out wider than is recommended for a proper installation.
Page 1 of 1
