Slim Line Heat/Air Unit

SAME DAY SHIPPING! Order within the next 4 hours 47 minutes and receive same day shipping

Free Shipping Free Shipping
Notes
Heater core bibs take 5/8" I.D. hose.
Slim Line Heat/Air Unit

Click image to enlarge

Details

Reviews

Q & A

What's in the Box

This low profile under the dash mount heat/cool unit is 26.25" wide 5.25" tall and 12" deep. Features a three speed blower, heat/cool adjustment, defroster duct hook-ups, and three 1" x 5" front adjusting vents. Easy to install with mounting slots on the sides of the unit all plumbing and wiring done from the back side of the unit. Will handle 18,000 BTU's based on a Sanden or Sankyo 508 compressor at 60 MPH. The blower motor is capable of 240 CFM. Minimum condenser dimensions would be 12"X18" but would prefer a 14"X20" sized condenser, or 280 sq. in.

Customer Reviews

Rated 5 out of 5 by 2 reviewers.
RATING BREAKDOWN
2 reviews
5 Stars
2
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0
RECOMMEND THIS PRODUCT:

Mooseman
Verified Purchaser

Great

September 15, 2014
Looks good under the dash and is putting out 51 degree air. Also the hook-up allows me to now have warm air to the wind shield to defrost if needed.
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Ricardoo
Verified Purchaser
Vermont

Slim Line Heat/Air Unit

July 01, 2014
The Slim Line Heat/Air Unit is an excellent addition to the ROVER P5 rally car I am building. The one modification will be to put a figured- walnut face on it to match the dashboard.
Pros:
  • works for me
Yes, I recommend this product.
Full Size Image

Was this review helpful? 0 0

Page 1 of 1

Product Q&A

7 questions : 8 answers

1 answers

does this unit have the expansion valve

papaw
Lewisville, TX, USA
February 06, 2014

does this unit have the expansion valve

Answers

February 07, 2014
EricM
Yes this unit does have the expansion valve installed.
1 answers

Can I use the 89 Ford compressor I already have installed in my 50 F1? Thanks, Vern

Vern
Saratoga, CA, USA
November 26, 2012

Can I use the 89 Ford compressor I already have installed in my 50 F1? Thanks, Vern

Answers

November 27, 2012
Jason
BTU ratings were quoted with a Sankyo 508 compressor so cooling output may vary slightly but with the proper plumbing the Ford compressor should give satisfactory results in your 50 Ford pickup.
2 answers

Does this unit have a heater core built in?

Tom
Elbridge NY
September 17, 2012

Does this unit have a heater core built in?

Answers

April 30, 2015
charles
is the heater core and evaporator installed in this unit
September 19, 2012
John
Yes, this unit has the heater core built. It will require plumbing to the engine for the hot water source.
1 answers

can i use this unit in a 72 chevyvan 20.

beanyo
pomona,ca
January 22, 2012

can i use this unit in a 72 chevyvan 20.

Answers

January 24, 2012
John
Part number 91000466 This unit can be used in any vehicle capable of accommodating the dimensions listed. It does not include the A/C compressor, drier, lines, etc. as well as any plumbing for the heat or air. Dimensions are 26.5” wide, 5.25” tall, and 12” deep. Plus you will need additional room for the plumbing requirements.
1 answers

HI Speedway How many BTU's of Heat and Cold will this unit put out "average"? How many CFM's will the blower produce"avarage"? What is the minimum size for the condenser? Thank you Steve

1934 Chevy PU
Livermore, CA
April 20, 2011

HI Speedway How many BTU's of Heat and Cold will this unit put out "average"? How many CFM's will the blower produce"avarage"? What is the minimum size for the condenser? Thank you Steve

Answers

April 22, 2011
Thomas
P/N 91000466, SLIM LINE HEAT/AIR will handle 18,000 BTU's (1 1/2 Ton) based on a Sanden or Sankyo 508 compressor @ 60 MPH. The blower is capable of 240 CFM. Minimum condenser dimensions would be 12"X18", but would prefer a 14"X20" sized condenser, or 280 sq. in.
1 answers

Does this unit have a defroster port?

Bill
Olympia Wa.
April 19, 2011

Does this unit have a defroster port?

Answers

April 20, 2011
Tech Support
This kit also includes tubing to connect to the customer's defroster ducts, a moisture drain hose, and mounting hardware.
1 answers

Does this unit contain its own condenser,compressor,heater core? if not, what existing a/c and heating components is needed to operate this unit.

July 06, 2011

Does this unit contain its own condenser,compressor,heater core? if not, what existing a/c and heating components is needed to operate this unit.

Answers

July 07, 2011
John
This unit comes as shown in the photo and for operation you will still need everything from the firewall forward plus the correct hoses, lines, and fittings. We offer a Sanden A/C compressor under part number 42813459 and a black A/C hose kit number 42810100 and you will have to obtain correct brackets for your application. We have two sizes of condensers such as part number 42815242 and 42815215. Dryer with safety switch number 42891003 will be needed and the necessary hoses and fitting to plumb the heater.
Page 1 of 1
